2009CCM X-Tr250
26 fields on record
The 2009 CCM X-TR250 is a lightweight supermoto designed for riders seeking nimble urban performance and accessible off-road capability. Its 249cc liquid-cooled single-cylinder engine delivers eager power ideal for navigating tight city streets and tackling varied terrain. Known for its versatile character and forgiving nature, it suits novice to intermediate riders wanting a fun, practical all-rounder.
- Capacity
- 249.4 ccm
- Engine
- Single, four-stroke
- Gearbox
- Not on record
Know it? Add it → - Dry weight
- 113.0 kg
- Seat height
- 940 mm
- Power
- 23.6 HP (17.4 kW) @ 7000 RPM
What’s new for the 2009 CCM X-Tr250
vs the 2008| Spec | 2008 | 2009 |
|---|---|---|
| Seat height | 925 mm (36.4 inches) | 940 mm (37.0 inches) |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Designed for flickable, playful street and light off-road riding rather than outright speed or long-distance travel.
- Built for
- A nimble, lightweight supermotard that rewards aggressive, engaged riding through corners and tight urban streets with quick direction changes.
- Not ideal for
- Not a good fit for riders wanting sustained highway speed, passenger comfort, or long-range touring capability.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 249.4 ccm
- Power
- 23.6 HP (17.4 kW) @ 7000 RPM
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.2088 HP/kg (dry)
- Bore x stroke
- 70.0 x 64.8 mm
- Compression
- 10.8:1
- Cooling system
- Liquid
- Fuel system
- Carburettor
- Starting
- Electric & kick
- Ignition
- Electronic ignition (CDI)
- Valves per cylinder
- 2
- Lubrication system
- Pressure pump feed
- Torque
- Not on record - add it
Transmission
- Final drive
- Chain
Dimensions & weight
- Wheelbase
- 1505 mm
- Seat height
- 940 mm
- Dry weight
- 113.0 kg
- Wet weight
- 124.0 kg
- Fuel capacity
- 8.60 litres
- Ground clearance
- 280 mm
Chassis & suspension
- Front suspension
- Usd 41mm adjustable rebound / compression/ preload
- Rear suspension
- Rebound / compression / preload
- Front wheel travel
- 300 mm
- Rear wheel travel
- 300 mm
Brakes & wheels
- Front brakes
- Single disc
- Rear brakes
- Single disc
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2008 | 2009 | 2010 |
|---|---|---|---|
| Capacity | 248 cc | 249 cc | 249 cc |
| Dry weight | 113 kg | 113 kg | 113 kg |
| Seat height | 925 mm | 940 mm | 925 mm |
| Fuel capacity | 8.6 L | 8.6 L | 8.6 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the CCM X-Tr250?
The 2009 CCM X-Tr250 has a Capacity of 249.4 ccm (15.22 cubic inches).
What engine power does the CCM X-Tr250 have?
The 2009 CCM X-Tr250 has a Power of 23.6 HP (17.4 kW) @ 7000 RPM.
How much does the CCM X-Tr250 weigh?
The 2009 CCM X-Tr250 has a Dry weight of 113.0 kg (249.1 pounds).
