Concept
2022Curtiss 1 Electric
26 fields on record
The 2022 Curtiss 1 Electric is a prototype cruiser designed for riders seeking retro styling with cutting-edge electric performance. Powered by a 110 HP axial flux motor delivering 200 Nm of instant torque, it delivers aggressive acceleration with classic motorcycle aesthetics. Known for blending vintage cruiser design with modern electric propulsion and custom suspension tuning.
- Capacity
- Not on record
Know it? Add it → - Engine
- Not on record
Know it? Add it → - Gearbox
- Not on record
Know it? Add it → - Wet weight
- 192.8 kg
- Seat height
- 737 mm
- Power
- 110.0 HP (80.3 kW)
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Designed as a boutique, collector-grade showpiece and spirited street bike rather than a bike built for any single practical use case.
- Built for
- A rare, artisan-built electric machine that blends instant torque and striking custom design with boutique exclusivity.
- Not ideal for
- Not for riders seeking long-distance touring range, passenger capability, or off-road versatility.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Range and charging costs
Worked out in your browser - nothing is sent to usBased on the maker's claimed range and battery size. Real-world figures depend on how and where you ride, speed and temperature. Prices shown greyed are examples - type your own.
Engine
- Power
- 110.0 HP (80.3 kW)
- Torque
- 200.0 Nm (20.4 kgf-m)
- Power/weight ratio
- 0.5705 HP/kg (wet)
- Cooling system
- Liquid
- Starting
- Electric
- Battery Capacity
- 8.8 kWh
- Motor Type
- Axial flux YASA P400 motor
- Range
- 193 km (120 miles)
- Charge Time
- 2.0 hours
Transmission
- Transmission type
- Automatic
Dimensions & weight
- Wheelbase
- 1575 mm
- Overall length
- 2286 mm
- Overall width
- 686 mm
- Seat height
- 737 mm
- Wet weight
- 192.8 kg
- Ground clearance
- 203 mm
Chassis & suspension
- Front suspension
- Custom shocks by RaceTec
- Rear suspension
- Custom shocks by RaceTec
- Rake (fork angle)
- 27.0°
Brakes & wheels
- Front brakes
- Double disc
- Rear brakes
- Single disc
- Front tyre
- 130/80-19
- Rear tyre
- 140/80-19
Other
- Color options
- Black, custom color
- Comments
- 8.8 kWh battery. 2 hours 40 min charging. Range 120 miles city, 70 miles highway. Regenerative braking. Only 120 will be made.
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2022 | 2023 | 2024 | 2025 | 2026 |
|---|---|---|---|---|---|
| Seat height | 737 mm | 686 mm | 686 mm | 686 mm | 686 mm |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What engine power does the Curtiss 1 Electric have?
The 2022 Curtiss 1 Electric has a Power of 110.0 HP (80.3 kW).
What is the torque of the Curtiss 1 Electric?
The 2022 Curtiss 1 Electric has a Torque of 200.0 Nm (20.4 kgf-m or 147.5 ft.lbs).
How much does the Curtiss 1 Electric weigh?
The 2022 Curtiss 1 Electric has a Wet weight of 192.8 kg (425.1 pounds).
Shop this bike
Affiliate linksWe may earn a commission from qualifying eBay or Amazon purchases made through these links. As an Amazon Associate I earn from qualifying purchases.
The 2022 Curtiss 1 Electric is a stunning example of modern electric motorcycle design. With its sleek and futuristic appearance, this bike is sure to turn heads wherever it goes. The powerful electric motor provides impressive performance, making it a great option for anyone looking to reduce their carbon footprint without sacrificing speed and agility.
In addition to its impressive design and performance, the 2022 Curtiss 1 Electric also offers a comfortable and smooth ride, thanks to its advanced suspension system. The bike's advanced technology and eco-friendly power source make it a great choice for environmentally conscious riders. Overall, the 2022 Curtiss 1 Electric is a fantastic option for anyone in the market for a high-performance electric motorcycle that doesn't compromise on style or comfort.
