2008Harley-Davidson FXSTC Softail Custom

★ 5.0

29 fields on record

The 2008 Harley-Davidson FXSTC Softail Custom is a classic cruiser designed for riders seeking authentic style and comfortable cruising. Its 96-cubic-inch V-Twin engine delivers commanding torque for effortless highway performance, while the iconic hardtail appearance combines with hidden rear suspension for a smooth ride. Best known for blending timeless Harley aesthetics with modern fuel injection reliability.

Capacity: 1573.3 ccm
Engine: V-Twin, four-stroke
Gearbox: 6-speed
Dry weight: 304.8 kg
Seat height: 719 mm
Power: 75.0 HP (55.2 kW)

⇄ Compare with another bike ＋ Add to garage All model years

What’s new for the 2008 Harley-Davidson FXSTC Softail Custom

vs the 2007

Spec	2007	2008
Torque	119.2 Nm (12.2 kgf-m or 87.9 ft.lbs)	117.0 Nm (11.9 kgf-m or 86.3 ft.lbs)
Front brakes	Single disc	Single disc. 4-piston calipers
Rear brakes	Single disc	Single disc. 2-piston torque-free calipers
Wheelbase	1638 mm (64.5 inches)	1699 mm (66.9 inches)

Other years 1999 2000 2001 2002 2003 2004 2005 2006 2007 2008 2009 2010

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail5%

Cornering30%

City riding45%

Daily riding50%

Touring45%

Two-up40%

Track5%

Best for: Built for stylish boulevard cruising and image-driven custom looks rather than outright speed or long-distance touring comfort.
Built for: A laid-back, torque-rich big-twin cruiser that rewards relaxed throttle-rolling rides over aggressive cornering or high-rpm thrills.
Not ideal for: Not a good fit for riders wanting agile cornering, off-road capability, or a sporty, high-speed riding experience.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 719mm, a rider of 68.9" with a 31" (estimated) inseam will reach the ground with both feet flat on the 2008 Harley-Davidson FXSTC Softail Custom, with a cramped knee angle of around 80 degrees and an upright riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 750 mm or under — Short Kings →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 1573.3 ccm
Power: 75.0 HP (55.2 kW)
Torque: 117.0 Nm (11.9 kgf-m)
Engine type: V-Twin, four-stroke
Power/weight ratio: 0.2461 HP/kg (dry)
Bore x stroke: 95.3 x 111.3 mm
Compression: 9.2:1
Cooling system: Air
Fuel system: Injection
Starting: Electric

Transmission

Gearbox: 6-speed
Transmission type: Manual
Final drive: Belt
Clutch: Multi-plate with diaphragm spring in oil bath

Dimensions & weight

Wheelbase: 1699 mm
Overall length: 2400 mm
Seat height: 719 mm
Dry weight: 304.8 kg
Wet weight: 318.9 kg
Fuel capacity: 18.90 litres
Ground clearance: 130 mm

Chassis & suspension

Rake (fork angle): 32.0°
Trail: 127 mm

Brakes & wheels

Front brakes: Single disc. 4-piston calipers
Rear brakes: Single disc. 2-piston torque-free calipers
Front tyre: 130/90-B16
Rear tyre: 200/55-R17

Other

Color options: Vivid Black, Black Pearl, Dark Blue Pearl (New), Candy Red Sunglo (New) Two-Tone Pacific Blue Pearl/Vivid Black, Two-Tone Crimson Red Sunglo/Candy Red Sunglo (New), 105th Anniversary Copper Pearl/Vivid Black, Purple Haze (Custom), Copperhead Pearl and Re

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	1999	2002	2005	2007	2008	2010
Capacity	1340 cc	1450 cc	1450 cc	1573 cc	1573 cc	1584 cc
Dry weight	—	—	—	305 kg	305 kg	304 kg
Seat height	—	—	—	719 mm	719 mm	670 mm
Fuel capacity	19.7 L	19.7 L	19.7 L	18.9 L	18.9 L	19.7 L
