Sportbikes
2020Honda CBR500R
47 fields on record
The 2020 Honda CBR500R is an accessible middleweight sportbike designed for novice and intermediate riders seeking affordable performance. Known for its manageable 190 kg weight, comfortable ergonomics, and reliable 471cc parallel-twin engine, it excels as an excellent stepping stone into sport riding without demanding expertise or premium pricing.
- Capacity
- 471.0 ccm
- Engine
- Parallel Twin, four-stroke
- Gearbox
- 6-speed
- Wet weight
- 191.0 kg
- Seat height
- 785 mm
- Power
- 46.9 HP (34.3 kW) @ 8600 RPM
What’s new for the 2020 Honda CBR500R
vs the 2019| Spec | 2019 | 2020 |
|---|---|---|
| Dry weight | 192.0 kg (423.3 pounds) | not listed |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- It's built primarily as a versatile everyday and commuting machine that can also handle occasional weekend backroad rides.
- Built for
- The parallel twin delivers smooth, predictable power with a friendly, non-intimidating demeanor rather than outright excitement.
- Not ideal for
- This isn't the right choice for riders chasing top-tier performance, long-distance touring comfort, or any serious off-road capability.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usRange and running costs
Worked out in your browser - nothing is sent to usBased on the published US (EPA-style) fuel economy estimate and tank size. Real-world figures depend on how and where you ride, and the last litres of a tank are reserve. Prices shown greyed are examples - type your own.
Engine
- Capacity
- 471.0 ccm
- Power
- 46.9 HP (34.3 kW) @ 8600 RPM
- CO2 Emissions
- 78 CO2 g/km
- EPA Certificate No.
- LHNXC0.47CSB-012
- EPA Est. Fuel Consumption
- 3.32 L/100km (70.8 US mpg)
- EPA CO Emissions
- 1.1 CO g/km
- Torque
- 43.0 Nm (4.4 kgf-m) @ 6500 RPM
- Engine type
- Parallel Twin, four-stroke
- Power/weight ratio
- 0.2455 HP/kg (wet)
- Bore x stroke
- 67.0 x 66.8 mm
- Compression
- 10.7:1
- Cooling system
- Liquid
- Fuel system
- Injection
- Starting
- Electric
- Ignition
- Full transistorized
- Aspiration
- Naturally aspirated
- Valves per cylinder
- 4
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Assist/Slipper clutch
Dimensions & weight
- Wheelbase
- 1410 mm
- Overall length
- 2080 mm
- Overall width
- 755 mm
- Overall height
- 1145 mm
- Seat height
- 785 mm
- Wet weight
- 191.0 kg
- Fuel capacity
- 17.00 litres
- Ground clearance
- 130 mm
- Oil capacity
- 3.20 litres
- Dry weight
- Not on record - add it
Chassis & suspension
- Frame
- Steel tube frame
- Front suspension
- 41mm fork
- Rear suspension
- Pro-Link single shock with nine-position spring preload adjustability
- Front wheel travel
- 109 mm
- Rear wheel travel
- 119 mm
- Rake (fork angle)
- 25.5°
- Trail
- 102 mm
Brakes & wheels
- Front brakes
- Double disc. Wave disc. Two-piston calipers.
- Front brakes diameter
- 320 mm
- Rear brakes
- Single disc. Wave disc. Single-piston caliper.
- Rear brakes diameter
- 240 mm
- Front tyre
- 120/70-R17
- Rear tyre
- 160/60-17
Other
- Color options
- Grand Prix Red, Matte Gray Metallic
- Comments
- Model ID: CBR500R.
- Fuel Tank Material
- Metal
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2013 | 2016 | 2020 | 2023 | 2026 |
|---|---|---|---|---|---|
| Capacity | 471 cc | 471 cc | 471 cc | 471 cc | 471 cc |
| Dry weight | 192 kg | 192 kg | — | — | — |
| Seat height | 785 mm | 785 mm | 785 mm | 785 mm | 790 mm |
| Fuel capacity | 15.5 L | 15.5 L | 17 L | 17.1 L | 17 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Honda CBR500R?
The 2020 Honda CBR500R has a Capacity of 471.0 ccm (28.74 cubic inches).
What engine power does the Honda CBR500R have?
The 2020 Honda CBR500R has a Power of 46.9 HP (34.3 kW) @ 8600 RPM.
How many gears does the Honda CBR500R have?
The 2020 Honda CBR500R has a Gearbox of 6-speed.
What is the torque of the Honda CBR500R?
The 2020 Honda CBR500R has a Torque of 43.0 Nm (4.4 kgf-m or 31.7 ft.lbs) @ 6500 RPM.
How much does the Honda CBR500R weigh?
The 2020 Honda CBR500R has a Wet weight of 191.0 kg (421.1 pounds).
Shop this bike
Affiliate linksWe may earn a commission from qualifying eBay or Amazon purchases made through these links. As an Amazon Associate I earn from qualifying purchases.
The 2020 Honda CBR500R is a fantastic entry-level sportbike for riders looking for a blend of performance and practicality. With its aggressive styling, responsive handling, and smooth power delivery, this motorcycle offers an exhilarating riding experience for beginners and experienced riders alike. The 471cc parallel-twin engine provides plenty of torque and power for thrilling acceleration, while the comfortable riding position and adjustable suspension make for a smooth and enjoyable ride. Whether you're commuting in the city or hitting the open road, the CBR500R offers a versatile and fun riding experience.
Overall, the 2020 Honda CBR500R is a great choice for riders who want a capable and stylish sportbike that doesn't sacrifice comfort or practicality. With its reliable performance, modern features, and affordable price point, this motorcycle is a strong contender in the competitive entry-level sportbike market. Whether you're a new rider or a seasoned enthusiast, the CBR500R offers a well-rounded package that is sure to impress.
