2017Honda CRF125F
40 fields on record
The 2017 Honda CRF125F is an entry-level dirt bike designed for young riders and beginners seeking a lightweight, manageable platform to learn off-road fundamentals. Known for its low 735 mm seat height, minimal weight of 88 kg, and forgiving characteristics, it excels as an accessible trainer that builds confidence and skills in novice riders.
- Capacity
- 124.9 ccm
- Engine
- Single, four-stroke
- Gearbox
- 4-speed
- Wet weight
- 88.0 kg
- Seat height
- 735 mm
- Power
- 8.9 HP (6.5 kW) @ 7500 RPM
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Off-road learning, trail riding, motocross practice
- Built for
- Simple, forgiving, and durable
- Not ideal for
- Road riding, touring, passengers, experienced racers wanting more power, highway use
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 124.9 ccm
- Power
- 8.9 HP (6.5 kW) @ 7500 RPM
- Torque
- 10.2 Nm (1.0 kgf-m) @ 4500 RPM
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.1011 HP/kg (wet)
- Bore x stroke
- 52.4 x 57.9 mm
- Compression
- 9.5:1
- Cooling system
- Air
- Fuel system
- Carburettor
- Starting
- Kick
- Ignition
- Capacitor Discharge
- Valves per cylinder
- 2
Transmission
- Gearbox
- 4-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Wet multi-plate
Dimensions & weight
- Wheelbase
- 1219 mm
- Overall length
- 1770 mm
- Overall width
- 740 mm
- Overall height
- 1010 mm
- Seat height
- 735 mm
- Wet weight
- 88.0 kg
- Fuel capacity
- 4.30 litres
- Ground clearance
- 219 mm
- Dry weight
- Not on record - add it
Chassis & suspension
- Frame
- Diamond, steel
- Front suspension
- 31mm telescopic fork
- Rear suspension
- Pro-Link single-shock
- Front wheel travel
- 275 mm
- Rear wheel travel
- 282 mm
- Rake (fork angle)
- 25.3°
- Trail
- 81 mm
Brakes & wheels
- Front brakes
- Single disc. Hydraulic.
- Front brakes diameter
- 220 mm
- Rear brakes
- Expanding brake (drum brake)
- Rear brakes diameter
- 125 mm
- Front tyre
- 70/100-17
- Rear tyre
- 90/100-14
Other
- Color options
- Red
- Comments
- Model ID: CRF125F
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2014 | 2017 | 2021 | 2024 | 2027 |
|---|---|---|---|---|---|
| Capacity | 125 cc | 125 cc | 125 cc | 125 cc | 125 cc |
| Seat height | 785 mm | 735 mm | 739 mm | 739 mm | 739 mm |
| Fuel capacity | 4.3 L | 4.3 L | 3.8 L | 3.8 L | 3.8 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Honda CRF125F?
The 2017 Honda CRF125F has a Capacity of 124.9 ccm (7.62 cubic inches).
What engine power does the Honda CRF125F have?
The 2017 Honda CRF125F has a Power of 8.9 HP (6.5 kW) @ 7500 RPM.
How many gears does the Honda CRF125F have?
The 2017 Honda CRF125F has a Gearbox of 4-speed.
What is the torque of the Honda CRF125F?
The 2017 Honda CRF125F has a Torque of 10.2 Nm (1.0 kgf-m or 7.5 ft.lbs) @ 4500 RPM.
How much does the Honda CRF125F weigh?
The 2017 Honda CRF125F has a Wet weight of 88.0 kg (194.0 pounds).
