Motocross Bikes
2016Honda CRF125FB
39 fields on record
The Honda CRF125FB is a beginner-friendly dirt bike ideal for young riders learning off-road skills. Its lightweight 125cc air-cooled engine delivers manageable power with a four-speed manual transmission, while the steel diamond frame and long suspension travel provide stability and comfort on trails and motocross terrain.
- Capacity
- 124.9 ccm
- Engine
- Single, four-stroke
- Gearbox
- 4-speed
- Wet weight
- 89.0 kg
- Seat height
- 785 mm
- Power
- 8.9 HP (6.5 kW) @ 7500 RPM
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Designed purely as a small-displacement trail and recreational off-road bike for youth and lightweight adults progressing beyond a pit bike.
- Built for
- A friendly, forgiving, low-intimidation trail bike with soft, predictable power and simple, durable mechanicals suited to learning terrain feel.
- Not ideal for
- This bike is not suitable for adult riders seeking speed, highway travel, touring comfort, or carrying a passenger.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 124.9 ccm
- Power
- 8.9 HP (6.5 kW) @ 7500 RPM
- Torque
- 10.2 Nm (1.0 kgf-m) @ 4500 RPM
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.1000 HP/kg (wet)
- Bore x stroke
- 52.4 x 57.9 mm
- Compression
- 9.5:1
- Cooling system
- Air
- Fuel system
- Carburettor
- Starting
- Electric & kick
- Ignition
- CDI
- Valves per cylinder
- 2
Transmission
- Gearbox
- 4-speed
- Transmission type
- Manual
- Final drive
- Chain
Dimensions & weight
- Wheelbase
- 1255 mm
- Overall length
- 1869 mm
- Overall width
- 740 mm
- Overall height
- 1075 mm
- Seat height
- 785 mm
- Wet weight
- 89.0 kg
- Fuel capacity
- 4.30 litres
- Ground clearance
- 265 mm
- Dry weight
- Not on record - add it
Chassis & suspension
- Frame
- Steel diamond backbone frame
- Front suspension
- 31mm telescopic fork
- Rear suspension
- Pro-Link single-shock
- Front wheel travel
- 133 mm
- Rear wheel travel
- 155 mm
- Rake (fork angle)
- 27.3°
- Trail
- 90 mm
Brakes & wheels
- Front brakes
- Single disc. Hydraulic.
- Front brakes diameter
- 220 mm
- Rear brakes
- Expanding brake (drum brake)
- Rear brakes diameter
- 95 mm
- Front tyre
- 70/100-19
- Rear tyre
- 90/100-16
Other
- Color options
- Red/white
- Comments
- Model ID: CRF125FB
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
Rider Reviews
Common questions
What is the engine size of the Honda CRF125FB?
The 2016 Honda CRF125FB has a Capacity of 124.9 ccm (7.62 cubic inches).
What engine power does the Honda CRF125FB have?
The 2016 Honda CRF125FB has a Power of 8.9 HP (6.5 kW) @ 7500 RPM.
How many gears does the Honda CRF125FB have?
The 2016 Honda CRF125FB has a Gearbox of 4-speed.
What is the torque of the Honda CRF125FB?
The 2016 Honda CRF125FB has a Torque of 10.2 Nm (1.0 kgf-m or 7.5 ft.lbs) @ 4500 RPM.
How much does the Honda CRF125FB weigh?
The 2016 Honda CRF125FB has a Wet weight of 89.0 kg (196.2 pounds).
