Dual-Sport Motorcycles
2016Suzuki DR-Z125
32 fields on record
The 2016 Suzuki DR-Z125 is a lightweight dual-sport designed for beginner and younger riders seeking off-road capability with on-road versatility. Known for its approachable ergonomics, reliable air-cooled engine, and sturdy steel frame, it excels as an entry-level adventure machine for trail exploration and casual riding.
- Capacity
- 124.0 ccm
- Engine
- Single, four-stroke
- Gearbox
- 5-speed
- Dry weight
- 79.0 kg
- Seat height
- 776 mm
- Power
- 15.0 HP (11.0 kW)
What’s new for the 2016 Suzuki DR-Z125
vs the 2015| Spec | 2015 | 2016 |
|---|---|---|
| Wheelbase | 1270 mm (50.0 inches) | 1245 mm (49.0 inches) |
Other years
2002
2003
2004
2005
2006
2007
2008
2009
2010
2011
2012
2013
2014
2015
2016
2017
2018
2019
2020
2021
2022
2023
2024
2025
2026
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- It's built as a light-duty trail and recreational minibike rather than a serious performance or commuting machine.
- Built for
- It has a simple, forgiving, kick-start character with modest power delivery suited to learning throttle and clutch control.
- Not ideal for
- It is not suitable for highway travel, long-distance touring, carrying a passenger, or riders seeking strong acceleration or high top speed.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 124.0 ccm
- Power
- 15.0 HP (11.0 kW)
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.1899 HP/kg (dry)
- Compression
- 9.5:1
- Cooling system
- Air
- Fuel system
- Carburettor
- Starting
- Kick
- Ignition
- CDI
- Valves per cylinder
- 2
- Lubrication system
- Wet sump
- Torque
- Not on record - add it
Transmission
- Gearbox
- 5-speed
- Transmission type
- Manual
- Final drive
- Chain
Dimensions & weight
- Wheelbase
- 1245 mm
- Overall length
- 1836 mm
- Overall width
- 770 mm
- Overall height
- 1085 mm
- Seat height
- 776 mm
- Dry weight
- 79.0 kg
- Wet weight
- 88.0 kg
- Fuel capacity
- 4.80 litres
- Ground clearance
- 260 mm
Chassis & suspension
- Frame
- High rigidity steel pipe
- Front suspension
- Telescopic, coil spring, oil damped
- Rear suspension
- Link type, coil spring, oil damped
Brakes & wheels
- Front brakes
- Expanding brake (drum brake)
- Rear brakes
- Expanding brake (drum brake)
- Front tyre
- 70/100-17
- Rear tyre
- 90/100-14
Other
- Color options
- Champion Yellow/Solid Black
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2002 | 2008 | 2014 | 2016 | 2020 | 2026 |
|---|---|---|---|---|---|---|
| Capacity | 124 cc | 124 cc | 124 cc | 124 cc | 124 cc | 124 cc |
| Dry weight | 80 kg | 79 kg | 79 kg | 79 kg | 79 kg | 79 kg |
| Seat height | 770 mm | 775 mm | 775 mm | 776 mm | 770 mm | 775 mm |
| Fuel capacity | 6.6 L | 6.6 L | 4.2 L | 4.8 L | 4.8 L | 4.8 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Suzuki DR-Z125?
The 2016 Suzuki DR-Z125 has a Capacity of 124.0 ccm (7.57 cubic inches).
What engine power does the Suzuki DR-Z125 have?
The 2016 Suzuki DR-Z125 has a Power of 15.0 HP (11.0 kW).
How many gears does the Suzuki DR-Z125 have?
The 2016 Suzuki DR-Z125 has a Gearbox of 5-speed.
How much does the Suzuki DR-Z125 weigh?
The 2016 Suzuki DR-Z125 has a Dry weight of 79.0 kg (174.2 pounds).
