Enduro Bikes
2004Honda CRF230F
37 fields on record
The 2004 Honda CRF 230 F is a lightweight enduro bike ideal for beginners and younger riders seeking an affordable entry into off-road riding. Its accessible seat height and manageable 223cc single-cylinder engine deliver predictable, user-friendly performance on trails and varied terrain. Known for reliability and low maintenance, it remains a popular choice for learning fundamental dirt biking skills.
- Capacity
- 223.0 ccm
- Engine
- Single, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 108.0 kg
- Seat height
- 866 mm
- Power
- 22.3 HP (16.4 kW)
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- It's a light, simple air-cooled trail bike built for casual off-road riding, fire roads, and recreational enduro use rather than speed or long-distance travel.
- Built for
- Forgiving, easygoing, and low-maintenance in nature, this bike rewards smooth, relaxed inputs over aggressive riding.
- Not ideal for
- It is not a good fit for riders wanting highway speed, extended touring comfort, or a passenger-friendly setup.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 223.0 ccm
- Power
- 22.3 HP (16.4 kW)
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.2065 HP/kg (dry)
- Bore x stroke
- 65.5 x 66.2 mm
- Compression
- 9.0:1
- Cooling system
- Air
- Fuel system
- Carburettor
- Starting
- Electric & kick
- Ignition
- CDI
- Valves per cylinder
- 2
- Torque
- Not on record - add it
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
Dimensions & weight
- Wheelbase
- 1374 mm
- Overall length
- 2059 mm
- Overall width
- 801 mm
- Overall height
- 1190 mm
- Seat height
- 866 mm
- Dry weight
- 108.0 kg
- Wet weight
- 112.9 kg
- Fuel capacity
- 8.30 litres
- Ground clearance
- 297 mm
- Reserve fuel capacity
- 1.50 litres
Chassis & suspension
- Front suspension
- 37mm leading-axle Showa fork
- Rear suspension
- Pro-Link Showa single-shock with spring-preload adjustability.
- Front wheel travel
- 241 mm
- Rear wheel travel
- 229 mm
- Rake (fork angle)
- 27.3°
- Trail
- 112 mm
Brakes & wheels
- Front brakes
- Single disc
- Front brakes diameter
- 240 mm
- Rear brakes
- Expanding brake (drum brake)
- Front tyre
- 80/100-21
- Rear tyre
- 100/100-18
Other
- Color options
- Red
Specs last verified against published sources: .
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2004 | 2008 | 2012 | 2015 | 2019 |
|---|---|---|---|---|---|
| Capacity | 223 cc | 223 cc | 223 cc | 223 cc | 223 cc |
| Dry weight | 108 kg | 108 kg | 108 kg | 108 kg | 108 kg |
| Seat height | 866 mm | 866 mm | 866 mm | 866 mm | 878 mm |
| Fuel capacity | 8.3 L | 7.2 L | 7.2 L | 7.2 L | 7 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Honda CRF230F?
The 2004 Honda CRF230F has a Capacity of 223.0 ccm (13.61 cubic inches).
What engine power does the Honda CRF230F have?
The 2004 Honda CRF230F has a Power of 22.3 HP (16.4 kW).
How many gears does the Honda CRF230F have?
The 2004 Honda CRF230F has a Gearbox of 6-speed.
How much does the Honda CRF230F weigh?
The 2004 Honda CRF230F has a Dry weight of 108.0 kg (238.1 pounds).
