Enduro Bikes
2017Honda CRF230F
39 fields on record
The 2017 Honda CRF230F is an entry-level dirt bike designed for beginner and younger riders seeking a reliable, manageable platform for learning off-road skills. Known for its lightweight construction, forgiving handling, and fuel-efficient four-stroke engine, it combines accessibility with Honda's reputation for durability. Its electric start option and compact dimensions make it an ideal choice for riders building fundamental motorcycle competency.
- Capacity
- 223.0 ccm
- Engine
- Single, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 108.0 kg
- Seat height
- 866 mm
- Power
- 22.3 HP (16.4 kW)
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- A recreational trail and enduro bike built for relaxed off-road exploration, fire roads, and light single-track rather than racing.
- Built for
- Mild, dependable and unintimidating air-cooled thumper - soft, torquey and low-maintenance, prioritizing fun and reliability over outright performance.
- Not ideal for
- Not for speed seekers, highway commuters, two-up touring, or competitive motocross racers wanting sharp power and race-spec suspension.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 223.0 ccm
- Power
- 22.3 HP (16.4 kW)
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.2065 HP/kg (dry)
- Bore x stroke
- 65.5 x 66.2 mm
- Compression
- 9.0:1
- Cooling system
- Air
- Fuel system
- Carburettor
- Starting
- Electric & kick
- Ignition
- CDI
- Valves per cylinder
- 2
- Torque
- Not on record - add it
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
Dimensions & weight
- Wheelbase
- 1374 mm
- Overall length
- 2059 mm
- Overall width
- 801 mm
- Overall height
- 1190 mm
- Seat height
- 866 mm
- Dry weight
- 108.0 kg
- Wet weight
- 112.9 kg
- Fuel capacity
- 7.20 litres
- Ground clearance
- 297 mm
- Reserve fuel capacity
- 1.50 litres
Chassis & suspension
- Front suspension
- 37mm leading-axle Showa® fork; 9.5 inches travel
- Rear suspension
- Pro-Link® Showa single shock with spring-preload adjustability; 9.0 inches travel
- Front wheel travel
- 241 mm
- Rear wheel travel
- 229 mm
- Rake (fork angle)
- 27.3°
- Trail
- 112 mm
Brakes & wheels
- Front brakes
- Single disc
- Front brakes diameter
- 240 mm
- Rear brakes
- Expanding brake (drum brake)
- Front tyre
- 80/100-21
- Rear tyre
- 100/100-18
Other
- Color options
- Red
- Warranty
- 6
- Comments
- Model ID: CRF230F
Specs last verified against published sources: .
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2004 | 2008 | 2012 | 2015 | 2017 | 2019 |
|---|---|---|---|---|---|---|
| Capacity | 223 cc | 223 cc | 223 cc | 223 cc | 223 cc | 223 cc |
| Dry weight | 108 kg | 108 kg | 108 kg | 108 kg | 108 kg | 108 kg |
| Seat height | 866 mm | 866 mm | 866 mm | 866 mm | 866 mm | 878 mm |
| Fuel capacity | 8.3 L | 7.2 L | 7.2 L | 7.2 L | 7.2 L | 7 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Honda CRF230F?
The 2017 Honda CRF230F has a Capacity of 223.0 ccm (13.61 cubic inches).
What engine power does the Honda CRF230F have?
The 2017 Honda CRF230F has a Power of 22.3 HP (16.4 kW).
How many gears does the Honda CRF230F have?
The 2017 Honda CRF230F has a Gearbox of 6-speed.
How much does the Honda CRF230F weigh?
The 2017 Honda CRF230F has a Dry weight of 108.0 kg (238.1 pounds).
