Enduro Bikes
2005Honda CRF250X
39 fields on record
The 2005 Honda CRF 250 X is a lightweight enduro designed for riders seeking versatile off-road performance. Its compact 249cc single-cylinder engine and liquid cooling deliver reliable power for trail riding and light competition, while the 103.4kg dry weight ensures easy handling in technical terrain. Known for durability and user-friendly operation, it suits intermediate off-road enthusiasts.
- Capacity
- 249.0 ccm
- Engine
- Single, four-stroke
- Gearbox
- 5-speed
- Dry weight
- 103.4 kg
- Seat height
- 963 mm
- Power
- 24.9 HP (18.3 kW)
What’s new for the 2005 Honda CRF250X
vs the 2004| Spec | 2004 | 2005 |
|---|---|---|
| Front suspension | 47.0mm inverted Showa cartridge fork with 16-position rebound and 16-position compression damping adjustability. | 47.0mm inverted Showa cartridge fork with 16-position rebound and 16-position compression damping adjustability |
| Rear suspension | Pro-Link Showa single shock with spring preload, 17-position rebound damping adjustability, and compression damping adjustment separated into low-speed (13 positions) and high-speed (3.5 turns. | Pro-Link Showa single shock with spring-preload, 17-position rebound-damping adjustability, and compression-damping adjustment separated into low-speed (13 positions) and high-speed (3.5 turns) |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built for serious trail riding, enduro competition, and technical off-road terrain rather than street use.
- Built for
- A focused, no-frills off-road tool that rewards aggressive, skilled riding with excellent agility and suspension travel over rough terrain.
- Not ideal for
- Not a good fit for new riders, commuters, passengers, or anyone wanting a comfortable long-distance road machine.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 249.0 ccm
- Power
- 24.9 HP (18.3 kW)
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.2408 HP/kg (dry)
- Bore x stroke
- 78.0 x 52.2 mm
- Compression
- 12.5:1
- Cooling system
- Liquid
- Fuel system
- Carburettor
- Starting
- Electric & kick
- Ignition
- CD with electronic advance and lighting coil
- Valves per cylinder
- 4
- Lubrication system
- Twin-sump lubrication
- Torque
- Not on record - add it
Transmission
- Gearbox
- 5-speed
- Transmission type
- Manual
- Final drive
- Chain
Dimensions & weight
- Wheelbase
- 1488 mm
- Overall length
- 2174 mm
- Overall width
- 827 mm
- Overall height
- 1261 mm
- Seat height
- 963 mm
- Dry weight
- 103.4 kg
- Wet weight
- 114.8 kg
- Fuel capacity
- 8.30 litres
- Ground clearance
- 361 mm
Chassis & suspension
- Frame
- Semi-double cradle, aluminium twin-spar
- Front suspension
- 47.0mm inverted Showa cartridge fork with 16-position rebound and 16-position compression damping adjustability
- Rear suspension
- Pro-Link Showa single shock with spring-preload, 17-position rebound-damping adjustability, and compression-damping adjustment separated into low-speed (13 positions) and high-speed (3.5 turns)
- Front wheel travel
- 315 mm
- Rear wheel travel
- 315 mm
- Rake (fork angle)
- 27.5°
- Trail
- 120 mm
Brakes & wheels
- Front brakes
- Single disc
- Front brakes diameter
- 240 mm
- Rear brakes
- Single disc
- Rear brakes diameter
- 240 mm
- Front tyre
- 80/70-21
- Rear tyre
- 100/90-18
Other
- Color options
- Red
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2004 | 2005 | 2008 | 2012 | 2015 | 2019 |
|---|---|---|---|---|---|---|
| Capacity | 249 cc | 249 cc | 249 cc | 249 cc | 249 cc | 249 cc |
| Dry weight | 103 kg | 103 kg | — | — | 115 kg | 115 kg |
| Seat height | 963 mm | 963 mm | 958 mm | 958 mm | 958 mm | 958 mm |
| Fuel capacity | 8.3 L | 8.3 L | 7.2 L | 7.2 L | 7.2 L | 7.2 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Honda CRF250X?
The 2005 Honda CRF250X has a Capacity of 249.0 ccm (15.19 cubic inches).
What engine power does the Honda CRF250X have?
The 2005 Honda CRF250X has a Power of 24.9 HP (18.3 kW).
How many gears does the Honda CRF250X have?
The 2005 Honda CRF250X has a Gearbox of 5-speed.
How much does the Honda CRF250X weigh?
The 2005 Honda CRF250X has a Dry weight of 103.4 kg (228.0 pounds).
