Enduro Bikes
2016Honda CRF250X
41 fields on record
The 2016 Honda CRF250X is a lightweight dual-sport motorcycle designed for beginner to intermediate riders seeking adventure both on and off road. Known for its manageable seat height, excellent ground clearance, and reliable electric-start engine, it excels as an accessible entry point into adventure riding. The compact 250cc platform delivers approachable performance while maintaining the durability Honda is recognized for in its CRF lineup.
- Capacity
- 249.0 ccm
- Engine
- Single, four-stroke
- Gearbox
- 5-speed
- Dry weight
- 114.8 kg
- Seat height
- 958 mm
- Power
- 29.4 HP (21.4 kW) @ 9000 RPM
What’s new for the 2016 Honda CRF250X
vs the 2015| Spec | 2015 | 2016 |
|---|---|---|
| Power | 28.5 HP (21.3 kW) | 29.4 HP (21.4 kW) @ 9000 RPM |
| Torque | — | 24.2 Nm (2.5 kgf-m or 17.8 ft.lbs) @ 8000 RPM |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built purely for trail riding, technical enduro sections, and off-road competition rather than any road-going use.
- Built for
- A punchy, high-revving single-cylinder off-roader with long-travel adjustable Showa suspension that rewards aggressive, active riding over rough terrain.
- Not ideal for
- Not a good fit for riders wanting a comfortable street commuter, a highway tourer, or a machine that can easily carry a passenger.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 249.0 ccm
- Power
- 29.4 HP (21.4 kW) @ 9000 RPM
- Torque
- 24.2 Nm (2.5 kgf-m) @ 8000 RPM
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.2561 HP/kg (dry)
- Bore x stroke
- 78.0 x 52.2 mm
- Compression
- 12.9:1
- Cooling system
- Liquid
- Fuel system
- Carburettor
- Starting
- Electric & kick
- Ignition
- CD with electronic advance and lighting coil
- Valves per cylinder
- 4
- Lubrication system
- Twin-sump lubrication
Transmission
- Gearbox
- 5-speed
- Transmission type
- Manual
- Final drive
- Chain
Dimensions & weight
- Wheelbase
- 1481 mm
- Overall length
- 2174 mm
- Overall width
- 827 mm
- Overall height
- 1261 mm
- Seat height
- 958 mm
- Dry weight
- 114.8 kg
- Wet weight
- 115.2 kg
- Fuel capacity
- 7.20 litres
- Ground clearance
- 345 mm
Chassis & suspension
- Frame
- Semi-double cradle, aluminium twin-spar
- Front suspension
- 47mm inverted Showa® cartridge fork with 16-position rebound- and 16-position compression-damping adjustability; 12.4-inches travel
- Rear suspension
- Pro-Link® Showa® single shock with spring-preload, 17-position rebound-damping adjustability, and compression damping adjustment separated into low-speed (13 positions) and high-speed (3.5 turns); 12.3 inches travel
- Front wheel travel
- 315 mm
- Rear wheel travel
- 312 mm
- Rake (fork angle)
- 27.5°
- Trail
- 118 mm
Brakes & wheels
- Front brakes
- Single disc. Two-piston calipers.
- Front brakes diameter
- 240 mm
- Rear brakes
- Single disc
- Rear brakes diameter
- 240 mm
- Front tyre
- 80/100-21
- Rear tyre
- 100/100-18
Other
- Color options
- Red
- Comments
- Model ID: CRF250X.
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2004 | 2008 | 2012 | 2015 | 2016 | 2019 |
|---|---|---|---|---|---|---|
| Capacity | 249 cc | 249 cc | 249 cc | 249 cc | 249 cc | 249 cc |
| Dry weight | 103 kg | — | — | 115 kg | 115 kg | 115 kg |
| Seat height | 963 mm | 958 mm | 958 mm | 958 mm | 958 mm | 958 mm |
| Fuel capacity | 8.3 L | 7.2 L | 7.2 L | 7.2 L | 7.2 L | 7.2 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Honda CRF250X?
The 2016 Honda CRF250X has a Capacity of 249.0 ccm (15.19 cubic inches).
What engine power does the Honda CRF250X have?
The 2016 Honda CRF250X has a Power of 29.4 HP (21.4 kW) @ 9000 RPM.
How many gears does the Honda CRF250X have?
The 2016 Honda CRF250X has a Gearbox of 5-speed.
What is the torque of the Honda CRF250X?
The 2016 Honda CRF250X has a Torque of 24.2 Nm (2.5 kgf-m or 17.8 ft.lbs) @ 8000 RPM.
How much does the Honda CRF250X weigh?
The 2016 Honda CRF250X has a Dry weight of 114.8 kg (253.1 pounds).
