2009Honda DN-01

45 fields on record

The 2009 Honda DN-01 is a futuristic cruiser designed for riders seeking innovative styling and ease of use. Its 680cc V-twin engine paired with an automatic transmission makes it ideal for casual riders who prefer low-maintenance comfort over traditional manual shifting. Best known for its distinctive design and accessible riding experience, the DN-01 bridges cruiser culture with modern technology.

Capacity: 680.0 ccm
Engine: V-Twin, four-stroke
Gearbox: 6-speed
Dry weight: 213.0 kg
Seat height: 691 mm
Power: 74.8 HP (55.0 kW)

⇄ Compare with another bike ＋ Add to garage All model years

Other years 2006 2007 2008 2009 2010 2011 2012 2013 2014

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail5%

Cornering45%

City riding68%

Daily riding72%

Touring60%

Two-up60%

Track20%

Best for: It's built as a comfortable, low-maintenance all-rounder for relaxed street riding rather than outright performance or adventure use.
Built for: The DN-01 has a quirky, cruiser-meets-sportbike personality, favoring smooth, torque-driven cruising over aggressive performance.
Not ideal for: It's not for riders seeking high-speed thrills, sharp cornering agility, or any off-road capability.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 691mm, a rider of 68.9" with a 31" (estimated) inseam will reach the ground with both feet flat on the 2009 Honda DN-01, with a cramped knee angle of around 75 degrees and an upright riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 750 mm or under — Short Kings →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 680.0 ccm
Power: 74.8 HP (55.0 kW)
EPA Certificate No.: 9HNXC0.68AFA-017
EPA CO Emissions: 0.8 CO g/km
Engine type: V-Twin, four-stroke
Power/weight ratio: 0.3512 HP/kg (dry)
Bore x stroke: 81.0 x 66.0 mm
Compression: 10.0:1
Cooling system: Liquid
Fuel system: Injection
Starting: Electric
Ignition: Digital transistorized with electronic advance
Aspiration: Naturally aspirated
Valves per cylinder: 4
Lubrication system: Wet sump

Transmission

Gearbox: 6-speed
Transmission type: Automatic
Final drive: Shaft
Clutch: Automatic, HFT with internal hydraulic control

Dimensions & weight

Wheelbase: 1605 mm
Overall length: 2090 mm
Overall width: 775 mm
Overall height: 1103 mm
Seat height: 691 mm
Dry weight: 213.0 kg
Wet weight: 269.9 kg
Fuel capacity: 15.10 litres
Ground clearance: 130 mm
Reserve fuel capacity: 3.00 litres

Chassis & suspension

Frame: Steel pipe double-cradle frame with bolt-on seat rail
Front suspension: 41mm telescopic fork
Rear suspension: Pro Arm single-side swingarm with single shock, seven-position spring preload adjustability
Front wheel travel: 107 mm
Rear wheel travel: 119 mm
Rake (fork angle): 28.5°
Trail: 114 mm

Brakes & wheels

Front brakes: Double disc
Front brakes diameter: 296 mm
Rear brakes: Single disc
Rear brakes diameter: 276 mm
Front tyre: 130/70-ZR17
Rear tyre: 190/50-ZR17

Other

Color options: Candy Dark Red, Black
Fuel Tank Material: Metal; Plastic

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2006	2008	2009	2010	2012	2014
Capacity	680 cc	680 cc	680 cc	680 cc	680 cc	680 cc
Dry weight	213 kg	213 kg	213 kg	213 kg	213 kg	213 kg
Seat height	691 mm	691 mm	691 mm	691 mm	691 mm	691 mm
Fuel capacity	15.1 L	15.1 L	15.1 L	15.1 L	15.1 L	15 L
