Cruisers
2010Honda DN-01
42 fields on record
The 2010 Honda DN-01 is a cruiser for riders who want laid-back style and a low, relaxed seat. Its 680cc liquid-cooled twin makes 74.8 hp, with a 691 mm seat, a 270 kg wet weight and a 15.1-litre tank.
- Capacity
- 680.0 ccm
- Engine
- V-Twin, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 213.0 kg
- Seat height
- 691 mm
- Power
- 74.8 HP (55.0 kW)
What’s new for the 2010 Honda DN-01
vs the 2009| Spec | 2009 | 2010 |
|---|---|---|
| Front suspension | 41mm telescopic fork | 41mm telescopic fork with 4.2 inches travel |
| Rear suspension | Pro Arm single-side swingarm with single shock, seven-position spring preload adjustability | Pro Arm single-side swingarm with single shock, seven-position spring preload adjustability; 4.7 inches travel |
| Front brakes | Double disc | Double disc. ABS and CBS with dual full-floating 296mm discs and three-piston calipers |
| Rear brakes | Single disc | Single disc. ABS and CBS with single 276mm disc and three-piston caliper |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- It's built as a comfortable, low-maintenance all-rounder for relaxed street riding rather than outright performance or adventure use.
- Built for
- The DN-01 has a quirky, cruiser-meets-sportbike personality, favoring smooth, torque-driven cruising over aggressive performance.
- Not ideal for
- It's not for riders seeking high-speed thrills, sharp cornering agility, or any off-road capability.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 680.0 ccm
- Power
- 74.8 HP (55.0 kW)
- Engine type
- V-Twin, four-stroke
- Power/weight ratio
- 0.3512 HP/kg (dry)
- Bore x stroke
- 81.0 x 66.0 mm
- Compression
- 10.0:1
- Cooling system
- Liquid
- Fuel system
- Injection
- Starting
- Electric
- Ignition
- Digital transistorized with electronic advance
- Valves per cylinder
- 4
- Lubrication system
- Wet sump
Transmission
- Gearbox
- 6-speed
- Transmission type
- Automatic
- Final drive
- Shaft
- Clutch
- Automatic, HFT with internal hydraulic control
Dimensions & weight
- Wheelbase
- 1605 mm
- Overall length
- 2090 mm
- Overall width
- 775 mm
- Overall height
- 1103 mm
- Seat height
- 691 mm
- Dry weight
- 213.0 kg
- Wet weight
- 269.9 kg
- Fuel capacity
- 15.10 litres
- Ground clearance
- 130 mm
- Reserve fuel capacity
- 3.00 litres
Chassis & suspension
- Frame
- Steel pipe double-cradle frame with bolt-on seat rail
- Front suspension
- 41mm telescopic fork with 4.2 inches travel
- Rear suspension
- Pro Arm single-side swingarm with single shock, seven-position spring preload adjustability; 4.7 inches travel
- Front wheel travel
- 107 mm
- Rear wheel travel
- 119 mm
- Rake (fork angle)
- 28.5°
- Trail
- 114 mm
Brakes & wheels
- Front brakes
- Double disc. ABS and CBS with dual full-floating 296mm discs and three-piston calipers
- Front brakes diameter
- 296 mm
- Rear brakes
- Single disc. ABS and CBS with single 276mm disc and three-piston caliper
- Rear brakes diameter
- 276 mm
- ABS
- Yes
- Front tyre
- 130/70-ZR17
- Rear tyre
- 190/50-ZR17
Other
- Color options
- Candy Dark Red, Black
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2006 | 2008 | 2010 | 2012 | 2014 |
|---|---|---|---|---|---|
| Capacity | 680 cc | 680 cc | 680 cc | 680 cc | 680 cc |
| Dry weight | 213 kg | 213 kg | 213 kg | 213 kg | 213 kg |
| Seat height | 691 mm | 691 mm | 691 mm | 691 mm | 691 mm |
| Fuel capacity | 15.1 L | 15.1 L | 15.1 L | 15.1 L | 15 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Honda DN-01?
The 2010 Honda DN-01 has a Capacity of 680.0 ccm (41.50 cubic inches).
What engine power does the Honda DN-01 have?
The 2010 Honda DN-01 has a Power of 74.8 HP (55.0 kW).
How many gears does the Honda DN-01 have?
The 2010 Honda DN-01 has a Gearbox of 6-speed.
How much does the Honda DN-01 weigh?
The 2010 Honda DN-01 has a Dry weight of 213.0 kg (469.6 pounds).
