2005Honda GL1800 Gold Wing

Rate this bike

41 fields on record

The 2005 Honda GL 1800 Gold Wing is the ultimate full-featured touring motorcycle, engineered for riders seeking long-distance comfort and performance. Its powerful 1832cc six-cylinder engine delivers smooth acceleration and highway-cruising stability, while advanced features like programmed fuel injection and digital ignition make it the benchmark for luxury touring bikes. A factory ABS option was also available.

Capacity: 1832.0 ccm
Engine: Boxer, four-stroke
Gearbox: 5-speed
Dry weight: 359.2 kg
Seat height: 739 mm
Power: 118.0 HP (86.8 kW) @ 5500 RPM

⇄ Compare with another bike ＋ Add to garage All model years

What’s new for the 2005 Honda GL1800 Gold Wing

vs the 2004

Spec	2004	2005
Rear suspension	Pro-Arm single-side swingarm with Pro-Link single shock with computer controlled spring-preload adjustment with two memory presets.	Pro-Arm single-side swingarm with Pro-Link single shock with computer controlled spring-preload adjustment with two memory presets
Front brakes	Double disc	Double disc. LBS 3-piston calipers
Rear brakes	Single disc	Single disc. LBS 3-piston calipers

Other years 2001 2002 2003 2004 2005 2011 2012 2013 2014 2016 2017 2018 2019 2020 2021 2022 2023 2024

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail5%

Cornering45%

City riding40%

Daily riding65%

Touring99%

Two-up97%

Track15%

Best for: Built for effortless long-distance highway touring with a passenger and luggage rather than sport riding or commuting.
Built for: A smooth, refined, and gadget-laden grand tourer that rewards a relaxed, unhurried riding style over aggressive cornering ambitions.
Not ideal for: Not a good fit for riders seeking a light, flickable bike for tight city streets, off-road trails, or track-day cornering thrills.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 739mm, a rider of 68.9" with a 31" (estimated) inseam will reach the ground with both feet flat on the 2005 Honda GL1800 Gold Wing, with a cramped knee angle of around 80 degrees and an upright riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 750 mm or under — Short Kings →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 1832.0 ccm
Power: 118.0 HP (86.8 kW) @ 5500 RPM
Torque: 167.0 Nm (17.0 kgf-m)
Engine type: Boxer, four-stroke
Power/weight ratio: 0.3285 HP/kg (dry)
Bore x stroke: 74.0 x 71.0 mm
Compression: 9.8:1
Cooling system: Liquid
Fuel system: Injection
Starting: Electric
Ignition: Computer-controlled digital with three-dimensional mapping
Valves per cylinder: 2

Transmission

Gearbox: 5-speed
Transmission type: Manual
Final drive: Shaft
Clutch: Multi-plate with diaphragm spring in oil bath

Dimensions & weight

Wheelbase: 1692 mm
Overall length: 2632 mm
Overall width: 946 mm
Seat height: 739 mm
Dry weight: 359.2 kg
Wet weight: 406.0 kg
Fuel capacity: 25.00 litres
Ground clearance: 125 mm
Oil capacity: 5.60 litres

Chassis & suspension

Frame: 1832cc liquid-cooled horizontally opposed six-cylinder
Front suspension: 45.0mm cartridge fork with anti-dive system
Rear suspension: Pro-Arm single-side swingarm with Pro-Link single shock with computer controlled spring-preload adjustment with two memory presets
Front wheel travel: 140 mm
Rear wheel travel: 104 mm
Rake (fork angle): 29.3°
Trail: 109 mm

Brakes & wheels

Front brakes: Double disc. LBS 3-piston calipers
Front brakes diameter: 296 mm
Rear brakes: Single disc. LBS 3-piston calipers
Rear brakes diameter: 316 mm
ABS: Optional
Front tyre: 130/70-R18
Rear tyre: 180/60-R16

Other

Color options: Metallic Silver, Pearl Yellow, Bright Blue Metallic, Candy Black Cherry, Dark Gray Metallic, White

Specs last verified against published sources: October 2026.

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2001	2005	2016	2020	2024
Capacity	1832 cc	1832 cc	1832 cc	1833 cc	1833 cc
Dry weight	363 kg	359 kg	359 kg	359 kg	359 kg
Seat height	740 mm	739 mm	739 mm	745 mm	745 mm
Fuel capacity	25 L	25 L	25 L	21.1 L	21.1 L
