Dual-Sport Motorcycles
2010Kawasaki KLX125
39 fields on record
The 2010 Kawasaki KLX 125 is a lightweight enduro bike designed for beginner and young riders seeking an affordable entry into off-road riding. Its compact 125cc air-cooled four-stroke engine delivers modest torque with fuel injection reliability, while the five-speed manual gearbox provides manageable power delivery. Best known for its durability and low seat height, the KLX 125 excels as a learner-friendly trail bike.
- Capacity
- 124.0 ccm
- Engine
- Single, four-stroke
- Gearbox
- 5-speed
- Wet weight
- 113.0 kg
- Seat height
- 830 mm
- Power
- 15.0 HP (11.0 kW)
What’s new for the 2010 Kawasaki KLX125
vs the 2009| Spec | 2009 | 2010 |
|---|---|---|
| Power | — | 15.0 HP (11.0 kW) |
| Torque | — | 10.0 Nm (1.0 kgf-m or 7.4 ft.lbs) |
| Dry weight | 79.8 kg (175.9 pounds) | not listed |
| Seat height | 775 mm (30.5 inches) | 830 mm (32.7 inches) |
| Fuel capacity | 6.40 litres (1.69 US gallons) | 7.00 litres (1.85 US gallons) |
| Front suspension | Telescopic fork, 48mm | 33mm hydraulic telescopic fork |
| Rear suspension | Bottom-link, single shock | Uni-Track |
| Rear brakes | Expanding brake (drum brake) | Single disc |
| Wheelbase | 1245 mm (49.0 inches) | 1285 mm (50.6 inches) |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built to be ridden on the road and on dirt tracks, making it a versatile do-it-all machine.
- Built for
- A dual-sport from Kawasaki with a 124cc engine; its character is easy-going and economical, with 15 hp on tap.
- Not ideal for
- Not for riders wanting high-speed motorway comfort or track performance.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 124.0 ccm
- Power
- 15.0 HP (11.0 kW)
- Torque
- 10.0 Nm (1.0 kgf-m)
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.1327 HP/kg (wet)
- Bore x stroke
- 54.0 x 54.4 mm
- Compression
- 9.5:1
- Cooling system
- Air
- Fuel system
- Injection
- Starting
- Electric
- Ignition
- Digital DC-CDI
- Valves per cylinder
- 2
- Lubrication system
- Wet sump
Transmission
- Gearbox
- 5-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Wet multi-disc, manual
Dimensions & weight
- Wheelbase
- 1285 mm
- Overall length
- 1980 mm
- Overall width
- 770 mm
- Overall height
- 1090 mm
- Seat height
- 830 mm
- Wet weight
- 113.0 kg
- Fuel capacity
- 7.00 litres
- Ground clearance
- 257 mm
- Dry weight
- Not on record - add it
Chassis & suspension
- Frame
- Perimeter, steel
- Front suspension
- 33mm hydraulic telescopic fork
- Rear suspension
- Uni-Track
- Front wheel travel
- 175 mm
- Rear wheel travel
- 180 mm
- Rake (fork angle)
- 24.2°
- Trail
- 101 mm
Brakes & wheels
- Front brakes
- Expanding brake (drum brake)
- Front brakes diameter
- 240 mm
- Rear brakes
- Single disc
- Rear brakes diameter
- 186 mm
- Front tyre
- 70/100-19
- Rear tyre
- 90/100-16
Specs last verified against published sources: .
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2005 | 2008 | 2010 | 2011 | 2014 | 2017 |
|---|---|---|---|---|---|---|
| Capacity | 124 cc | 124 cc | 124 cc | 125 cc | 125 cc | 125 cc |
| Dry weight | 80 kg | 80 kg | — | — | — | — |
| Seat height | 775 mm | 775 mm | 830 mm | 830 mm | 830 mm | 830 mm |
| Fuel capacity | 6.4 L | 6.4 L | 7 L | 7 L | 7 L | 7 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Kawasaki KLX125?
The 2010 Kawasaki KLX125 has a Capacity of 124.0 ccm (7.57 cubic inches).
What engine power does the Kawasaki KLX125 have?
The 2010 Kawasaki KLX125 has a Power of 15.0 HP (11.0 kW).
How many gears does the Kawasaki KLX125 have?
The 2010 Kawasaki KLX125 has a Gearbox of 5-speed.
What is the torque of the Kawasaki KLX125?
The 2010 Kawasaki KLX125 has a Torque of 10.0 Nm (1.0 kgf-m or 7.4 ft.lbs).
How much does the Kawasaki KLX125 weigh?
The 2010 Kawasaki KLX125 has a Wet weight of 113.0 kg (249.1 pounds).
