2017KTM 250 SX

Rate this bike

34 fields on record

The 2017 KTM 250 SX is a lightweight two-stroke motocross bike engineered for competitive riders and enthusiasts seeking aggressive off-road performance. Its 95.4 kg weight, premium WP suspension with 300mm travel both ends, and high-spec braking system deliver sharp handling and control on technical terrain. Known for its potent power delivery and race-ready character, the 250 SX excels in sand, loam, and mixed track conditions.

Capacity: 249.0 ccm
Engine: Single, two-stroke
Gearbox: 5-speed
Dry weight: 95.4 kg
Seat height: 992 mm
Power: 24.9 HP (18.3 kW)

⇄ Compare with another bike ＋ Add to garage All model years

Other years 2000 2001 2002 2003 2004 2005 2006 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018 2019 2020 2021 2022 2023 2024 2025 2026 2027

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail98%

Cornering90%

City riding5%

Daily riding5%

Touring8%

Two-up0%

Track85%

Best for: Built purely for motocross track riding and racing, not for street use or general transportation.
Built for: Sharp, explosive, and razor-agile, this bike rewards aggressive riding and precise throttle control with rapid acceleration bursts and flickable handling.
Not ideal for: This is not suitable for commuting, touring, carrying passengers, or riders seeking a comfortable, low-maintenance everyday motorcycle.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 992mm, a rider of 68.9" with a 31" (estimated) inseam will not reach the ground comfortably on the 2017 KTM 250 SX, with a moderate knee angle of around 90 degrees and an upright riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at over 900 mm — Sky High →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 249.0 ccm
Power: 24.9 HP (18.3 kW)
Engine type: Single, two-stroke
Power/weight ratio: 0.2610 HP/kg (dry)
Bore x stroke: 66.4 x 72.0 mm
Cooling system: Liquid
Fuel system: Carburettor
Starting: Kick
Ignition: Contactless, controlled, fully electronic ignition system with digital ignition timing adjustment, type Kokusan
Lubrication system: Mixture oil lubrication 1:60

Transmission

Gearbox: 5-speed
Transmission type: Manual
Final drive: Chain
Clutch: Wet, DDS multi-disc clutch, Brembo hydraulics

Dimensions & weight

Wheelbase: 1495 mm
Seat height: 992 mm
Dry weight: 95.4 kg
Fuel capacity: 7.00 litres
Ground clearance: 385 mm

Chassis & suspension

Frame: Chrome-molybdenum steel central-tube
Front suspension: WP USD closed cartridge Ø 48 mm
Rear suspension: WP shock absorber with linkage
Front wheel travel: 300 mm
Rear wheel travel: 300 mm
Rake (fork angle): 26.5°
Trail: 116 mm

Brakes & wheels

Front brakes: Single disc. Four-piston calipers.
Front brakes diameter: 260 mm
Rear brakes: Single disc. Two-piston calipers.
Rear brakes diameter: 220 mm
Front tyre: 80/100-21
Rear tyre: 110/90-19

Other

Color options: Orange/white/black

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2000	2007	2014	2017	2020	2027
Capacity	249 cc	249 cc	249 cc	249 cc	249 cc	249 cc
Dry weight	101 kg	98 kg	96 kg	95 kg	96 kg	96 kg
Seat height	925 mm	925 mm	992 mm	992 mm	950 mm	958 mm
Fuel capacity	7.5 L	7.5 L	7.5 L	7 L	7.5 L	7.2 L
