Enduro Bikes
2017KTM 350 EXC-F
41 fields on record
The 2017 KTM 350 EXC-F is a lightweight enduro bike ideal for riders seeking versatility across mixed terrain. Known for its agile handling and responsive performance, this machine excels in technical trail riding and cross-country adventures. The WP suspension components and compact 104 kg chassis deliver precise control whether navigating tight single-track or covering longer distances.
- Capacity
- 350.0 ccm
- Engine
- Single, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 104.0 kg
- Seat height
- 960 mm
- Power
- 39.3 HP (29.3 kW) @ 9500 RPM
What’s new for the 2017 KTM 350 EXC-F
vs the 2016| Spec | 2016 | 2017 |
|---|---|---|
| Power | 45.6 HP (34.0 kW) @ 9500 RPM | 39.3 HP (29.3 kW) @ 9500 RPM |
| Dry weight | 107.2 kg (236.3 pounds) | 104.0 kg (229.3 pounds) |
| Seat height | 970 mm (38.2 inches) | 960 mm (37.8 inches) |
| Fuel capacity | 9.00 litres (2.38 US gallons) | 8.50 litres (2.25 US gallons) |
| Rear suspension | WP PDS shock absorber | WP Xplor PDS shock absorber |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built for serious enduro and technical off-road riding, including trails, woods, and competitive terrain rather than road use.
- Built for
- A focused, race-bred enduro machine prioritizing agility, suspension travel, and light weight over comfort or outright speed.
- Not ideal for
- This is not a good fit for shorter riders, road commuters, passengers, or anyone wanting a plush touring or highway-capable motorcycle.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usRange and running costs
Worked out in your browser - nothing is sent to usBased on the published US (EPA-style) fuel economy estimate and tank size. Real-world figures depend on how and where you ride, and the last litres of a tank are reserve. Prices shown greyed are examples - type your own.
Engine
- Capacity
- 350.0 ccm
- Power
- 39.3 HP (29.3 kW) @ 9500 RPM
- CO2 Emissions
- 102 CO2 g/km
- EPA Certificate No.
- HKTXC.350EXF-007
- EPA Est. Fuel Consumption
- 4.34 L/100km (54.2 US mpg)
- EPA CO Emissions
- 9.7 CO g/km
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.3779 HP/kg (dry)
- Bore x stroke
- 88.0 x 57.5 mm
- Compression
- 13.7:1
- Cooling system
- Liquid
- Fuel system
- Injection
- Starting
- Electric & kick
- Ignition
- Keihin EMS
- Aspiration
- Naturally aspirated
- Valves per cylinder
- 4
- Lubrication system
- Forced oil lubrication with 2 Eaton pumps
- Torque
- Not on record - add it
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Wet, DDS multi-disc clutch, Brembo hydraulics
Dimensions & weight
- Wheelbase
- 1482 mm
- Seat height
- 960 mm
- Dry weight
- 104.0 kg
- Fuel capacity
- 8.50 litres
- Ground clearance
- 355 mm
Chassis & suspension
- Frame
- Chrome-molybdenum steel central-tube frame
- Front suspension
- WP USD Ø 48 mm
- Rear suspension
- WP Xplor PDS shock absorber
- Front wheel travel
- 300 mm
- Rear wheel travel
- 310 mm
- Rake (fork angle)
- 26.5°
Brakes & wheels
- Front brakes
- Single disc. Brake calipers on floating bearings
- Front brakes diameter
- 260 mm
- Rear brakes
- Single disc. Brake calipers on floating bearings
- Rear brakes diameter
- 220 mm
- Front tyre
- 80/100-21
- Rear tyre
- 110/90-19
Other
- Color options
- Orange/white/black
- Fuel Tank Material
- Plastic
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2012 | 2016 | 2017 | 2020 | 2023 | 2027 |
|---|---|---|---|---|---|---|
| Capacity | 350 cc | 350 cc | 350 cc | 350 cc | 350 cc | 350 cc |
| Dry weight | 109 kg | 107 kg | 104 kg | 104 kg | 104 kg | 107 kg |
| Seat height | 970 mm | 970 mm | 960 mm | 960 mm | 960 mm | 963 mm |
| Fuel capacity | 7.5 L | 9 L | 8.5 L | 9.2 L | 9.2 L | 8.5 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the KTM 350 EXC-F?
The 2017 KTM 350 EXC-F has a Capacity of 350.0 ccm (21.36 cubic inches).
What engine power does the KTM 350 EXC-F have?
The 2017 KTM 350 EXC-F has a Power of 39.3 HP (29.3 kW) @ 9500 RPM.
How many gears does the KTM 350 EXC-F have?
The 2017 KTM 350 EXC-F has a Gearbox of 6-speed.
How much does the KTM 350 EXC-F weigh?
The 2017 KTM 350 EXC-F has a Dry weight of 104.0 kg (229.3 pounds).
