Enduro Bikes
2017KTM 350 XC-F
34 fields on record
The 2017 KTM 350 XC-F is a four-stroke cross-country racer that blends the agility of a 250 with the power of a 450. Its liquid-cooled 349.7cc single makes 45 hp through a six-speed gearbox and chain. A very tall 992 mm seat, 105.7 kg dry weight and 9.5-litre tank suit long races.
- Capacity
- 349.7 ccm
- Engine
- Single, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 105.7 kg
- Seat height
- 992 mm
- Power
- 45.0 HP (33.1 kW)
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built primarily as a light, sharp-handling street naked bike for commuting, city riding, and spirited backroad fun rather than any off-road use.
- Built for
- A punchy, torquey single-cylinder engine paired with a lightweight steel trellis chassis gives it a playful, eager, and nimble personality suited to flicking through traffic and corners.
- Not ideal for
- This is not the right choice for riders seeking genuine off-road capability, long-distance touring comfort, or a passenger-friendly two-up machine.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 349.7 ccm
- Power
- 45.0 HP (33.1 kW)
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.4257 HP/kg (dry)
- Bore x stroke
- 88.0 x 57.5 mm
- Compression
- 13.2:1
- Cooling system
- Liquid
- Fuel system
- Injection
- Starting
- Electric & kick
- Ignition
- Contactless controlled fully electronic ignition with digital ignition adjustment
- Lubrication system
- Pressure circulation lubrication with two Eaton pumps
- Torque
- Not on record - add it
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- CSS Multidisc clutch in oil bath/hydraulically activated
Dimensions & weight
- Wheelbase
- 1495 mm
- Seat height
- 992 mm
- Dry weight
- 105.7 kg
- Fuel capacity
- 9.50 litres
- Ground clearance
- 376 mm
Chassis & suspension
- Frame
- Central tubular frame made from chrome molybdenum steel tubes
- Front suspension
- WP Suspension Up Side Down 4860 MXMA CC
- Rear suspension
- WP Suspension 5018 BAVP DCC
- Front wheel travel
- 300 mm
- Rear wheel travel
- 317 mm
- Rake (fork angle)
- 26.5°
Brakes & wheels
- Front brakes
- Single disc. Brake calipers on floating bearings
- Front brakes diameter
- 260 mm
- Rear brakes
- Single disc. Brake calipers on floating bearings
- Rear brakes diameter
- 220 mm
- Front tyre
- 80/100-21
- Rear tyre
- 100/90-19
Other
- Color options
- Orange/gray
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2012 | 2016 | 2017 | 2020 | 2023 | 2027 |
|---|---|---|---|---|---|---|
| Capacity | 350 cc | 350 cc | 350 cc | 350 cc | 350 cc | 350 cc |
| Dry weight | 108 kg | 106 kg | 106 kg | 106 kg | 103 kg | 104 kg |
| Seat height | 992 mm | 992 mm | 992 mm | 992 mm | 950 mm | 954 mm |
| Fuel capacity | 7.5 L | 9.5 L | 9.5 L | 9.5 L | 8.5 L | 8.5 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the KTM 350 XC-F?
The 2017 KTM 350 XC-F has a Capacity of 349.7 ccm (21.34 cubic inches).
What engine power does the KTM 350 XC-F have?
The 2017 KTM 350 XC-F has a Power of 45.0 HP (33.1 kW).
How many gears does the KTM 350 XC-F have?
The 2017 KTM 350 XC-F has a Gearbox of 6-speed.
How much does the KTM 350 XC-F weigh?
The 2017 KTM 350 XC-F has a Dry weight of 105.7 kg (233.0 pounds).
