2013KTM 690 Enduro R
43 fields on record
The 2013 KTM 690 Enduro R is a lightweight single-cylinder enduro motorcycle designed for adventure riders seeking a nimble, fuel-efficient machine capable of both on-road and off-road exploration. Known for its tractable 690cc four-stroke engine and superior handling, it excels as a versatile middleweight for riders transitioning to adventure touring or serious dual-sport riding. The bike's compact tubular steel frame and quality WP suspension provide excellent terrain versatility and everyday practicality.
- Capacity
- 690.0 ccm
- Engine
- Single, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 142.0 kg
- Seat height
- 935 mm
- Power
- 65.7 HP (49.0 kW) @ 7000 RPM
What’s new for the 2013 KTM 690 Enduro R
vs the 2012| Spec | 2012 | 2013 |
|---|---|---|
| Engine capacity | 654.0 ccm (39.91 cubic inches) | 690.0 ccm (42.11 cubic inches) |
| Power | 65.7 HP (48.3 kW) | 65.7 HP (49.0 kW) @ 7000 RPM |
| Torque | 64.0 Nm (6.5 kgf-m or 47.2 ft.lbs) @ 6000 RPM | not listed |
| Front suspension | WP USD 48 mm (1.89 in) | WP Suspension 4860 D48/26 MA |
| Rear suspension | WPSuspension4618 with ProLever linkage | WP Suspension 4618 with Pro Lever linkage |
| Front brakes | Single disc | Single disc. Floating disc. Two-piston calipers. |
| Rear brakes | Single disc | Single disc. Floating disc. Single-piston caliper. |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built primarily as a big-bore enduro weapon for serious off-road riding, trail exploration, and technical terrain, with light road use as a secondary role.
- Built for
- A raw, torquey big single with a lightweight chassis rewards decisive, engaged riding and punishes hesitation, giving it a focused, no-nonsense personality.
- Not ideal for
- Not a good fit for riders wanting plush comfort, pillion-friendly touring, or a low-effort commuter experience.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usRange and running costs
Worked out in your browser - nothing is sent to usBased on the published US (EPA-style) fuel economy estimate and tank size. Real-world figures depend on how and where you ride, and the last litres of a tank are reserve. Prices shown greyed are examples - type your own.
Engine
- Capacity
- 690.0 ccm
- Power
- 65.7 HP (49.0 kW) @ 7000 RPM
- CO2 Emissions
- 134 CO2 g/km
- EPA Certificate No.
- DKTXC0.69SPM-004
- EPA Est. Fuel Consumption
- 5.71 L/100km (41.2 US mpg)
- EPA CO Emissions
- 3.2 CO g/km
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.4627 HP/kg (dry)
- Bore x stroke
- 102.0 x 84.5 mm
- Compression
- 11.8:1
- Cooling system
- Liquid
- Fuel system
- Injection
- Starting
- Electric & kick
- Ignition
- Keihin EMS with RBW, twin ignition
- Aspiration
- Naturally aspirated
- Valves per cylinder
- 4
- Lubrication system
- Pressure circulation lubrication with two rotor pumps
- Torque
- Not on record - add it
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Multidisc clutch in oil bath/hydraulically activated
Dimensions & weight
- Wheelbase
- 1504 mm
- Seat height
- 935 mm
- Dry weight
- 142.0 kg
- Wet weight
- 152.0 kg
- Fuel capacity
- 12.00 litres
- Ground clearance
- 280 mm
Chassis & suspension
- Frame
- Tubular space frame made from chrome molybdenum steel, powder-coated
- Front suspension
- WP Suspension 4860 D48/26 MA
- Rear suspension
- WP Suspension 4618 with Pro Lever linkage
- Front wheel travel
- 250 mm
- Rear wheel travel
- 250 mm
- Rake (fork angle)
- 27.0°
- Trail
- 115 mm
Brakes & wheels
- Front brakes
- Single disc. Floating disc. Two-piston calipers.
- Front brakes diameter
- 300 mm
- Rear brakes
- Single disc. Floating disc. Single-piston caliper.
- Rear brakes diameter
- 240 mm
- Front tyre
- 90/90-21
- Rear tyre
- 140/80-18
Other
- Color options
- Orange/gray/white
- Fuel Tank Material
- Plastic
Specs last verified against published sources: .
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2012 | 2013 | 2016 | 2019 | 2023 | 2027 |
|---|---|---|---|---|---|---|
| Capacity | 654 cc | 690 cc | 690 cc | 690 cc | 693 cc | 693 cc |
| Dry weight | 142 kg | 142 kg | 143 kg | 146 kg | 146 kg | 152 kg |
| Seat height | 935 mm | 935 mm | 910 mm | 910 mm | 929 mm | 935 mm |
| Fuel capacity | 12 L | 12 L | 12 L | 13.5 L | 13.5 L | 13.3 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the KTM 690 Enduro R?
The 2013 KTM 690 Enduro R has a Capacity of 690.0 ccm (42.11 cubic inches).
What engine power does the KTM 690 Enduro R have?
The 2013 KTM 690 Enduro R has a Power of 65.7 HP (49.0 kW) @ 7000 RPM.
How many gears does the KTM 690 Enduro R have?
The 2013 KTM 690 Enduro R has a Gearbox of 6-speed.
How much does the KTM 690 Enduro R weigh?
The 2013 KTM 690 Enduro R has a Dry weight of 142.0 kg (313.1 pounds).
