Enduro Bikes
2020KTM 690 Enduro R
47 fields on record
The 2020 KTM 690 Enduro R is a lightweight single-cylinder adventure bike designed for riders seeking nimble off-road capability and on-road versatility. Known for its exceptional maneuverability, minimal weight, and impressive ground clearance, it excels on technical terrain while remaining practical for commuting. The wire-spoked wheels and long-travel suspension deliver excellent traction across varied surfaces.
- Capacity
- 693.0 ccm
- Engine
- Single, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 146.0 kg
- Seat height
- 910 mm
- Power
- 73.8 HP (53.8 kW)
What’s new for the 2020 KTM 690 Enduro R
vs the 2019| Spec | 2019 | 2020 |
|---|---|---|
| Power | 67.0 HP (48.9 kW) | 73.8 HP (53.8 kW) |
| Torque | 73.5 Nm (7.5 kgf-m or 54.2 ft.lbs) @ 6500 RPM | 73.5 Nm (7.5 kgf-m or 54.2 ft.lbs) |
| Wet weight | 159.0 kg (350.5 pounds) | 152.0 kg (335.1 pounds) |
| Compression | 12.7:1 | 11.8:1 |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built primarily as a big-bore enduro weapon for serious off-road riding, trail exploration, and technical terrain, with light road use as a secondary role.
- Built for
- A raw, torquey big single with a lightweight chassis rewards decisive, engaged riding and punishes hesitation, giving it a focused, no-nonsense personality.
- Not ideal for
- Not a good fit for riders wanting plush comfort, pillion-friendly touring, or a low-effort commuter experience.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usRange and running costs
Worked out in your browser - nothing is sent to usBased on the maker's published fuel consumption and tank size. Real-world figures depend on how and where you ride, and the last litres of a tank are reserve. Prices shown greyed are examples - type your own.
Engine
- Capacity
- 693.0 ccm
- Power
- 73.8 HP (53.8 kW)
- CO2 Emissions
- 103 CO2 g/km
- EPA Certificate No.
- LKTXC0.69ESM-007-R01
- EPA Est. Fuel Consumption
- 4.39 L/100km (53.6 US mpg)
- EPA CO Emissions
- 1.1 CO g/km
- Torque
- 73.5 Nm (7.5 kgf-m)
- Engine type
- Single, four-stroke
- Fuel consumption
- 3.90 litres/100 km (25.6 km/l)
- Power/weight ratio
- 0.5055 HP/kg (dry)
- Bore x stroke
- 105.0 x 80.0 mm
- Compression
- 11.8:1
- Cooling system
- Liquid
- Fuel system
- Injection
- Starting
- Electric
- Ignition
- Keihin EMS with RBW, twin ignition
- Aspiration
- Naturally aspirated
- Valves per cylinder
- 4
- Lubrication system
- Forced oil lubrication with 2 oil pumps
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- PASC slipper clutch, hydraulically actuated
Dimensions & weight
- Wheelbase
- 1504 mm
- Seat height
- 910 mm
- Dry weight
- 146.0 kg
- Wet weight
- 152.0 kg
- Fuel capacity
- 13.50 litres
- Ground clearance
- 270 mm
Chassis & suspension
- Frame
- Chrome-moly tubular space frame, powder-coated
- Front suspension
- WP USD Ø 48 mm
- Rear suspension
- WP shock absorber with Pro-Lever linkage
- Front wheel travel
- 250 mm
- Rear wheel travel
- 250 mm
- Rake (fork angle)
- 27.0°
- Trail
- 115 mm
Brakes & wheels
- Front brakes
- Single disc. Brembo twin-piston floating calliper. Optional ABS.
- Front brakes diameter
- 300 mm
- Rear brakes
- Single disc. Brembo single-piston floating calliper. Optional ABS.
- Rear brakes diameter
- 240 mm
- ABS
- Optional
- Front tyre
- 90/90-21
- Rear tyre
- 140/80-18
Other
- Color options
- Orange/black/white
- Comments
- .
- Fuel Tank Material
- Plastic
Specs last verified against published sources: .
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2012 | 2016 | 2019 | 2020 | 2023 | 2027 |
|---|---|---|---|---|---|---|
| Capacity | 654 cc | 690 cc | 690 cc | 693 cc | 693 cc | 693 cc |
| Dry weight | 142 kg | 143 kg | 146 kg | 146 kg | 146 kg | 152 kg |
| Seat height | 935 mm | 910 mm | 910 mm | 910 mm | 929 mm | 935 mm |
| Fuel capacity | 12 L | 12 L | 13.5 L | 13.5 L | 13.5 L | 13.3 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Safety Recalls
⚠ 2 recalls may applyTIRES:TREAD/BELTAug 2022 · 22V588000
KTM North America, Inc. (KTM) is recalling certain 2019-2023 Husqvarna and KTM motorcycles with equipped with TKC80 tires. Please refer to KTM's recall report for specific model details. Cracks longer than 3/16 inch may develop in the tread grooves. As such, these vehicles fail to comply with the requirements of Federal Motor Vehicle Safety Standard number 119, "New Pneumatic Tires-Other Than Passenger Cars."
Risk: Cracks in the tread can lead to tread separation, increasing the risk of a crash.
Remedy: Dealers will replace the affected tires, free of charge. Owner notification letters were mailed September 16, 2022. Owners may contact KTM's customer service at 1-888-985-6090. KTM's numbers for this recall are KTB2208 and HTB2207.
POWER TRAIN:CLUTCH ASSEMBLY:SLAVE CYLINDEROct 2021 · 21V792000
KTM North America, Inc. (KTM) is recalling certain 2018-2020 690 Enduro R, Vitpilen 701, 701 Enduro, 701 Supermoto, 2019-2020 690 SMC R, Svartpilen, 2018-2019 690 Duke, and 2020 701 Enduro LR motorcycles. The bellow-style gasket on the clutch slave cylinder may have been damaged during manufacturing, which could cause the clutch to become inoperable and not disengage when the clutch lever is pulled in.
Risk: An inoperable clutch increases the risk of a crash.
Remedy: Dealers will inspect the clutch slave cylinder and replace it if necessary, free of charge. Owner notification letters are expected to be mailed December 3, 2021. Owners may contact KTM customer service at 1-888-985-6090. KTM's numbers for this recall are KTB2112 and HTB2110.
These recalls cover some 2020 bikes of this model. Whether one applies to a specific bike, and whether the repair has already been done, depends on its VIN — check your VIN with NHTSA or ask a dealer.
Source: NHTSA. View all KTM recalls →
Rider Reviews
Common questions
What is the engine size of the KTM 690 Enduro R?
The 2020 KTM 690 Enduro R has a Capacity of 693.0 ccm (42.29 cubic inches).
What engine power does the KTM 690 Enduro R have?
The 2020 KTM 690 Enduro R has a Power of 73.8 HP (53.8 kW).
How many gears does the KTM 690 Enduro R have?
The 2020 KTM 690 Enduro R has a Gearbox of 6-speed.
What is the torque of the KTM 690 Enduro R?
The 2020 KTM 690 Enduro R has a Torque of 73.5 Nm (7.5 kgf-m or 54.2 ft.lbs).
How much does the KTM 690 Enduro R weigh?
The 2020 KTM 690 Enduro R has a Dry weight of 146.0 kg (321.9 pounds).
Shop this bike
Affiliate linksWe may earn a commission from qualifying eBay or Amazon purchases made through these links. As an Amazon Associate I earn from qualifying purchases.
The 2020 KTM 690 Enduro R motorcycle is an impressive off-road machine that delivers impressive performance and capability. With a powerful 690cc single-cylinder engine, the Enduro R offers plenty of power for tackling rugged terrain. Its lightweight chassis and long-travel suspension make it well-suited for handling challenging off-road conditions, while also providing a comfortable ride on the street. Additionally, the bike comes equipped with advanced technology features such as ride-by-wire throttle and adjustable engine maps, allowing riders to tailor the bike's performance to their preferences.
Overall, the 2020 KTM 690 Enduro R motorcycle is a top choice for riders looking for a versatile and capable off-road machine. Its potent engine, advanced technology, and robust chassis make it an excellent option for exploring the great outdoors with confidence and control. Whether you're hitting the trails or cruising around town, the Enduro R delivers an exhilarating and enjoyable riding experience.
