Enduro Bikes
2018KTM 690 Enduro R
45 fields on record
The 2018 KTM 690 Enduro R is a lightweight single-cylinder adventure bike designed for riders seeking versatile on and off-road capability. Known for its manageable power delivery, agile handling, and genuine dual-purpose character, it excels in mixed terrain exploration. Advanced features like ride-by-wire throttle control and optional ABS appeal to adventure-focused riders prioritizing rider confidence and control.
- Capacity
- 690.0 ccm
- Engine
- Single, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 143.0 kg
- Seat height
- 910 mm
- Power
- 65.7 HP (49.0 kW) @ 7000 RPM
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built primarily as a big-bore enduro weapon for serious off-road riding, trail exploration, and technical terrain, with light road use as a secondary role.
- Built for
- A raw, torquey big single with a lightweight chassis rewards decisive, engaged riding and punishes hesitation, giving it a focused, no-nonsense personality.
- Not ideal for
- Not a good fit for riders wanting plush comfort, pillion-friendly touring, or a low-effort commuter experience.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usRange and running costs
Worked out in your browser - nothing is sent to usBased on the published US (EPA-style) fuel economy estimate and tank size. Real-world figures depend on how and where you ride, and the last litres of a tank are reserve. Prices shown greyed are examples - type your own.
Engine
- Capacity
- 690.0 ccm
- Power
- 65.7 HP (49.0 kW) @ 7000 RPM
- CO2 Emissions
- 95 CO2 g/km
- EPA Certificate No.
- JKTXC0.69LC4-004
- EPA Est. Fuel Consumption
- 4.03 L/100km (58.4 US mpg)
- EPA CO Emissions
- 4.6 CO g/km
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.4594 HP/kg (dry)
- Bore x stroke
- 102.0 x 84.5 mm
- Compression
- 11.8:1
- Cooling system
- Liquid
- Fuel system
- Injection
- Starting
- Electric
- Ignition
- Keihin EMS with RBW, twin ignition
- Aspiration
- Naturally aspirated
- Valves per cylinder
- 4
- Lubrication system
- Pressure circulation lubrication with two rotor pumps
- Torque
- Not on record - add it
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- APTC slipper clutch, hydraulically actuated
Dimensions & weight
- Wheelbase
- 1504 mm
- Seat height
- 910 mm
- Dry weight
- 143.0 kg
- Wet weight
- 152.0 kg
- Fuel capacity
- 12.00 litres
- Ground clearance
- 280 mm
Chassis & suspension
- Frame
- Chrome-moly tubular space frame, powder-coated
- Front suspension
- WP USD Ø 48 mm
- Rear suspension
- WP shock absorber with Pro-Lever linkage
- Front wheel travel
- 250 mm
- Rear wheel travel
- 250 mm
- Rake (fork angle)
- 27.0°
- Trail
- 115 mm
Brakes & wheels
- Front brakes
- Single disc. Brembo twin-piston floating calliper. Optional ABS.
- Front brakes diameter
- 300 mm
- Rear brakes
- Single disc. Brembo single-piston floating calliper. Optional ABS.
- Rear brakes diameter
- 240 mm
- ABS
- Optional
- Front tyre
- 90/90-21
- Rear tyre
- 140/80-18
Other
- Color options
- Orange/black/white
- Comments
- Cable-free 'ride-by-wire'system.
- Fuel Tank Material
- Plastic
Specs last verified against published sources: .
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2012 | 2016 | 2018 | 2019 | 2023 | 2027 |
|---|---|---|---|---|---|---|
| Capacity | 654 cc | 690 cc | 690 cc | 690 cc | 693 cc | 693 cc |
| Dry weight | 142 kg | 143 kg | 143 kg | 146 kg | 146 kg | 152 kg |
| Seat height | 935 mm | 910 mm | 910 mm | 910 mm | 929 mm | 935 mm |
| Fuel capacity | 12 L | 12 L | 12 L | 13.5 L | 13.5 L | 13.3 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the KTM 690 Enduro R?
The 2018 KTM 690 Enduro R has a Capacity of 690.0 ccm (42.11 cubic inches).
What engine power does the KTM 690 Enduro R have?
The 2018 KTM 690 Enduro R has a Power of 65.7 HP (49.0 kW) @ 7000 RPM.
How many gears does the KTM 690 Enduro R have?
The 2018 KTM 690 Enduro R has a Gearbox of 6-speed.
How much does the KTM 690 Enduro R weigh?
The 2018 KTM 690 Enduro R has a Dry weight of 143.0 kg (315.3 pounds).
Shop this bike
Affiliate linksWe may earn a commission from qualifying eBay or Amazon purchases made through these links. As an Amazon Associate I earn from qualifying purchases.
The 2018 KTM 690 Enduro R is a powerful and versatile motorcycle that delivers impressive performance both on and off-road. With its 693cc single-cylinder engine, this bike offers plenty of torque and power for tackling tough terrain. The lightweight chassis and agile handling make it easy to maneuver through tight trails, while the comfortable ergonomics and advanced suspension system provide a smooth ride over rough surfaces. Whether you're hitting the trails or cruising the streets, the KTM 690 Enduro R offers the perfect blend of performance, versatility, and durability.
If you're in the market for a reliable and high-performing dual-sport motorcycle, the 2018 KTM 690 Enduro R is definitely worth considering. Its impressive power, nimble handling, and rugged design make it a top choice for riders who want a bike that can handle a variety of riding conditions. With its well-rounded performance and advanced features, the KTM 690 Enduro R is a versatile and capable motorcycle that is sure to impress. Whether you're a seasoned off-road enthusiast or a casual rider looking for a fun and capable bike, the 2018 KTM 690 Enduro R has a lot to offer.
