2007KTM 690 Supermoto
40 fields on record
The 2007 KTM 690 Supermoto is a lightweight, agile super motard built for riders seeking nimble urban performance and playful handling. Its potent 653cc single-cylinder engine delivers 63 horsepower with a carburetted setup, making it ideal for both street riding and off-road adventure. Known for its responsive character and compact dimensions, it excels as an accessible entry point into supermoto riding.
- Capacity
- 654.0 ccm
- Engine
- Single, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 152.0 kg
- Seat height
- 875 mm
- Power
- 62.8 HP (46.8 kW) @ 7500 RPM
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built for aggressive backroad carving, supermoto track days, and tight technical riding rather than covering long distances.
- Built for
- A sharp, punchy, and playful single that rewards precise inputs with razor-like agility and strong torque delivery low in the rev range.
- Not ideal for
- Not a good fit for riders seeking a plush, stable long-distance tourer or a relaxed, low-effort commuter experience.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 654.0 ccm
- Power
- 62.8 HP (46.8 kW) @ 7500 RPM
- EPA Certificate No.
- 7KTXC0.65SPM-005
- EPA CO Emissions
- 7.2 CO g/km
- Torque
- 65.0 Nm (6.6 kgf-m)
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.4132 HP/kg (dry)
- Bore x stroke
- 102.0 x 80.0 mm
- Compression
- 11.7:1
- Cooling system
- Liquid
- Fuel system
- Injection
- Starting
- Electric & kick
- Ignition
- Kokusan DC-CDI
- Aspiration
- Naturally aspirated
- Valves per cylinder
- 4
- Lubrication system
- Pressure lubrication with 2 oil pumps
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- APTC multi-disc wet clutch, hydraulically operated
Dimensions & weight
- Wheelbase
- 1460 mm
- Seat height
- 875 mm
- Dry weight
- 152.0 kg
- Fuel capacity
- 13.20 litres
- Ground clearance
- 260 mm
Chassis & suspension
- Frame
- Chromoly trellis frame, powder-coated
- Front suspension
- WP USD
- Rear suspension
- WP monoshock with Pro Lever
- Front wheel travel
- 280 mm
- Rear wheel travel
- 310 mm
- Rake (fork angle)
- 26.0°
- Trail
- 112 mm
Brakes & wheels
- Front brakes
- Single disc
- Front brakes diameter
- 320 mm
- Rear brakes
- Single disc
- Rear brakes diameter
- 240 mm
- Front tyre
- 120/70-17
- Rear tyre
- 160/60-17
Other
- Color options
- Black, orange
Specs last verified against published sources: .
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2007 | 2008 | 2009 |
|---|---|---|---|
| Capacity | 654 cc | 654 cc | 654 cc |
| Dry weight | 152 kg | 152 kg | 154 kg |
| Seat height | 875 mm | 875 mm | 880 mm |
| Fuel capacity | 13.2 L | 13.2 L | 13.2 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the KTM 690 Supermoto?
The 2007 KTM 690 Supermoto has a Capacity of 654.0 ccm (39.91 cubic inches).
What engine power does the KTM 690 Supermoto have?
The 2007 KTM 690 Supermoto has a Power of 62.8 HP (46.8 kW) @ 7500 RPM.
How many gears does the KTM 690 Supermoto have?
The 2007 KTM 690 Supermoto has a Gearbox of 6-speed.
What is the torque of the KTM 690 Supermoto?
The 2007 KTM 690 Supermoto has a Torque of 65.0 Nm (6.6 kgf-m or 47.9 ft.lbs).
How much does the KTM 690 Supermoto weigh?
The 2007 KTM 690 Supermoto has a Dry weight of 152.0 kg (335.1 pounds).
