Adventure Motorcycles
2006KTM 950 Adventure Black
37 fields on record
The 2006 KTM 950 Adventure Black is a heavyweight adventure bike designed for experienced riders seeking serious off-road capability combined with long-distance touring comfort. Its 942cc twin-cylinder engine delivers robust 96.5 horsepower and excellent low-end torque, making it renowned for conquering challenging terrain while maintaining highway-ready performance. This model excels for riders tackling expedition-style adventures across diverse landscapes.
- Capacity
- 942.0 ccm
- Engine
- V-Twin
- Gearbox
- 6-speed
- Dry weight
- 198.0 kg
- Seat height
- 860 mm
- Power
- 96.6 HP (71.0 kW) @ 8000 RPM
What’s new for the 2006 KTM 950 Adventure Black
vs the 2005| Spec | 2005 | 2006 |
|---|---|---|
| Front suspension | WP-USD 48 mm (1.89´) | WP-USD 48 mm (1.89 inches) |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built for long-distance dual-sport adventure riding that mixes highway miles with serious off-road capability.
- Built for
- A rugged, torquey V-twin adventure machine that rewards a rider seeking rally-inspired off-road prowess over outright road refinement.
- Not ideal for
- Not ideal for shorter riders, strict city commuters, or anyone wanting a light, low-maintenance beginner-friendly bike.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 942.0 ccm
- Power
- 96.6 HP (71.0 kW) @ 8000 RPM
- Torque
- 95.0 Nm (9.7 kgf-m)
- Engine type
- V-Twin
- Power/weight ratio
- 0.4879 HP/kg (dry)
- Bore x stroke
- 100.0 x 60.0 mm
- Compression
- 11.5:1
- Cooling system
- Liquid
- Fuel system
- Carburettor
- Starting
- Electric
- Ignition
- Denso battery ignition
- Lubrication system
- Pressure lubrication
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Wet multi-disc clutch, operated hydraulically
Dimensions & weight
- Wheelbase
- 1570 mm
- Overall width
- 950 mm
- Overall height
- 950 mm
- Seat height
- 860 mm
- Dry weight
- 198.0 kg
- Fuel capacity
- 22.00 litres
- Ground clearance
- 261 mm
Chassis & suspension
- Frame
- Tubular chromoly space frame, powder-coated
- Front suspension
- WP-USD 48 mm (1.89 inches)
- Rear suspension
- WP-PDS suspension strut with hydr. spring preload
- Front wheel travel
- 300 mm
- Rear wheel travel
- 335 mm
- Rake (fork angle)
- 26.6°
- Trail
- 119 mm
Brakes & wheels
- Front brakes
- Double disc
- Front brakes diameter
- 300 mm
- Rear brakes
- Single disc
- Rear brakes diameter
- 240 mm
- Front tyre
- 90/90-21
- Rear tyre
- 150/70-18
Specs last verified against published sources: .
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2005 | 2006 |
|---|---|---|
| Capacity | 942 cc | 942 cc |
| Dry weight | 198 kg | 198 kg |
| Seat height | 860 mm | 860 mm |
| Fuel capacity | 22 L | 22 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Safety Recalls
⚠ 1 recall may applySERVICE BRAKES, HYDRAULIC:FOUNDATION COMPONENTS:MASTER CYLINDERFeb 2007 · 07V065000
ON CERTAIN 950 MOTORCYCLES, THE REAR BRAKE MAY FEEL SPONGY OR SOFT WHEN APPLYING THE BRAKE. THIS COULD LEAD TO IMPROPER REAR BRAKING.
Risk: IMPROPER REAR BRAKING COULD RESULT IN A CRASH.
Remedy: KTM DEALERS WILL REPLACE THE REAR BRAKE SYSTEM COMPONENTS. THE RECALL BEGAN ON MARCH 1, 2007. OWNERS MAY CONTACT KTM AT 1-440-985-3553.
These recalls cover some 2006 bikes of this model. Whether one applies to a specific bike, and whether the repair has already been done, depends on its VIN — check your VIN with NHTSA or ask a dealer.
Source: NHTSA. View all KTM recalls →
Rider Reviews
Common questions
What is the engine size of the KTM 950 Adventure Black?
The 2006 KTM 950 Adventure Black has a Capacity of 942.0 ccm (57.48 cubic inches).
What engine power does the KTM 950 Adventure Black have?
The 2006 KTM 950 Adventure Black has a Power of 96.6 HP (71.0 kW) @ 8000 RPM.
How many gears does the KTM 950 Adventure Black have?
The 2006 KTM 950 Adventure Black has a Gearbox of 6-speed.
What is the torque of the KTM 950 Adventure Black?
The 2006 KTM 950 Adventure Black has a Torque of 95.0 Nm (9.7 kgf-m or 70.1 ft.lbs).
How much does the KTM 950 Adventure Black weigh?
The 2006 KTM 950 Adventure Black has a Dry weight of 198.0 kg (436.5 pounds).
