Naked Motorcycles
2016Kymco K-Pipe 125
36 fields on record
The 2016 Kymco K-Pipe 125 is a lightweight commuter scooter designed for budget-conscious riders seeking reliable urban transportation. Known for its fuel efficiency and simple air-cooled engine, this model excels as an affordable entry-level option for daily commuting. Its compact frame and modest 125cc displacement make it nimble in traffic while maintaining dependable performance for practical everyday riding.
- Capacity
- 124.0 ccm
- Engine
- Single, four-stroke
- Gearbox
- 4-speed
- Dry weight
- 119.8 kg
- Seat height
- 787 mm
- Power
- 6.7 HP (5.0 kW) @ 7000 RPM
What’s new for the 2016 Kymco K-Pipe 125
vs the 2015| Spec | 2015 | 2016 |
|---|---|---|
| Power | — | 6.7 HP (5.0 kW) @ 7000 RPM |
| Torque | — | 8.5 Nm (0.9 kgf-m or 6.3 ft.lbs) @ 6000 RPM |
| Dry weight | 103.0 kg (227.1 pounds) | 119.8 kg (264.1 pounds) |
| Front suspension | Telescopic fork | Telescopic Forks |
| Rear suspension | Monoshock | Mono Shock |
| Front brakes | Single disc | Double disc |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built for short urban hops, commuting, and casual cruising rather than any kind of serious speed or distance work.
- Built for
- A fun, minimalist, café-racer-styled small bike that prioritizes charm and manageability over performance.
- Not ideal for
- It is not suited to highway touring, two-up riding, or any rider seeking real power and speed.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usRange and running costs
Worked out in your browser - nothing is sent to usBased on the published US (EPA-style) fuel economy estimate and tank size. Real-world figures depend on how and where you ride, and the last litres of a tank are reserve. Prices shown greyed are examples - type your own.
Engine
- Capacity
- 124.0 ccm
- Power
- 6.7 HP (5.0 kW) @ 7000 RPM
- CO2 Emissions
- 50 CO2 g/km
- EPA Est. Fuel Consumption
- 2.12 L/100km (111.0 US mpg)
- EPA CO Emissions
- 4.1 CO g/km
- Torque
- 8.5 Nm (0.9 kgf-m) @ 6000 RPM
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.0559 HP/kg (dry)
- Bore x stroke
- 54.0 x 54.0 mm
- Compression
- 8.6:1
- Cooling system
- Air
- Fuel system
- Carburettor
- Starting
- Electric & kick
- Aspiration
- Naturally aspirated
- Valves per cylinder
- 4
Transmission
- Gearbox
- 4-speed
- Transmission type
- Manual
- Final drive
- Chain
Dimensions & weight
- Wheelbase
- 1290 mm
- Overall length
- 1950 mm
- Overall width
- 750 mm
- Overall height
- 800 mm
- Seat height
- 787 mm
- Dry weight
- 119.8 kg
- Fuel capacity
- 4.50 litres
Chassis & suspension
- Frame
- Tubular Steel
- Front suspension
- Telescopic Forks
- Rear suspension
- Mono Shock
Brakes & wheels
- Front brakes
- Double disc
- Front brakes diameter
- 276 mm
- Rear brakes
- Expanding brake (drum brake)
- Front tyre
- 2.75-17
- Rear tyre
- 3.50-17
Other
- Color options
- Matte Red, Pearl White, Black
- Comments
- Kymco is made by Kwang Yang Motor Company, Taiwan.
Specs last verified against published sources: .
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2013 | 2015 | 2016 | 2018 | 2020 | 2022 |
|---|---|---|---|---|---|---|
| Capacity | 125 cc | 125 cc | 124 cc | 124 cc | 124 cc | 124 cc |
| Dry weight | 103 kg | 103 kg | 120 kg | 120 kg | 111 kg | 102 kg |
| Seat height | 787 mm | 787 mm | 787 mm | 787 mm | 838 mm | 838 mm |
| Fuel capacity | 4.5 L | 4.5 L | 4.5 L | 4.5 L | 4.5 L | 4.5 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Kymco K-Pipe 125?
The 2016 Kymco K-Pipe 125 has a Capacity of 124.0 ccm (7.57 cubic inches).
What engine power does the Kymco K-Pipe 125 have?
The 2016 Kymco K-Pipe 125 has a Power of 6.7 HP (5.0 kW) @ 7000 RPM.
How many gears does the Kymco K-Pipe 125 have?
The 2016 Kymco K-Pipe 125 has a Gearbox of 4-speed.
What is the torque of the Kymco K-Pipe 125?
The 2016 Kymco K-Pipe 125 has a Torque of 8.5 Nm (0.9 kgf-m or 6.3 ft.lbs) @ 6000 RPM.
How much does the Kymco K-Pipe 125 weigh?
The 2016 Kymco K-Pipe 125 has a Dry weight of 119.8 kg (264.1 pounds).
