Sportbikes
2012NCR M4
30 fields on record
The 2012 NCR M4 is a lightweight Italian sport bike built around the potent Ducati 1100 EVO V-twin engine, producing 107 horsepower and 115 Nm of torque. Its titanium frame and subframe, combined with carbon fiber components, create an exceptionally nimble machine favored by experienced riders seeking pure performance and handling. Best known for its exotic materials and track-focused engineering, the M4 delivers sharp responsiveness and minimal weight.
- Capacity
- 1100.0 ccm
- Engine
- V-Twin, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 130.0 kg
- Seat height
- Not on record
Know it? Add it → - Power
- 107.0 HP (78.7 kW) @ 7500 RPM
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built as a rare Italian boutique track and canyon-carving weapon, prioritizing minimal weight and razor-sharp handling over practicality.
- Built for
- An exotic, artisanal superbike with featherweight titanium and carbon construction, delivering explosive power-to-weight and instant, race-derived responses.
- Not ideal for
- Not suitable for new riders, daily commuting, passengers, long-distance touring, or anyone seeking comfort or off-road capability.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Engine
- Capacity
- 1100.0 ccm
- Power
- 107.0 HP (78.7 kW) @ 7500 RPM
- Torque
- 115.0 Nm (11.7 kgf-m) @ 5100 RPM
- Engine type
- V-Twin, four-stroke
- Power/weight ratio
- 0.8231 HP/kg (dry)
- Compression
- 10.0:1
- Cooling system
- Oil & air
- Fuel system
- Injection
- Starting
- Electric
- Ignition
- Magneti Marelli high speed cpu with traction control and NCR designed military wiring and connectors.
- Valves per cylinder
- 4
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Wet, Multiple Disc
Dimensions & weight
- Wheelbase
- 1400 mm
- Dry weight
- 130.0 kg
- Fuel capacity
- 13.00 litres
- Seat height
- Not on record - add it
Chassis & suspension
- Frame
- NCR titanium frame weight 4.8 Kg (10.6 lbs). Subframe: NCR titanium subframe with Schedoni leather seat on a carbon fiber base.
- Front suspension
- Ohlins 43 mm upside-down fork with TiN surface treatment, adjustable off-set, radial calipers with NCR CORSE billet aluminum fork bottoms, tuned by NCR CORSE. Triple clamps made from billet AL 7075 with an adjustable offset of 24 to 32 mm in 2 mm incremen
- Rear suspension
- Fully adjustable Ohlins monoshock with eccentric adjustor. Tuned by NCR CORSE
- Rake (fork angle)
- 24.0°
Brakes & wheels
- Front brakes
- Double disc. WAVE discs, 4-piston 2-pad Brembo SBK radial caliper from billet.
- Front brakes diameter
- 300 mm
- Rear brakes
- Single disc. WAVE disc, 2-piston Brembo caliper from billet..
- Rear brakes diameter
- 200 mm
- Front tyre
- 120/70-R17
- Rear tyre
- 190/55-R17
Other
- Color options
- Clear coat. Custom paint available on request.
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2012 | 2014 | 2017 | 2019 | 2021 |
|---|---|---|---|---|---|
| Capacity | 1100 cc | 1100 cc | 1100 cc | 1100 cc | 1100 cc |
| Dry weight | 130 kg | 130 kg | 130 kg | 130 kg | 130 kg |
| Fuel capacity | 13 L | 13 L | 13 L | 13 L | 13 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the NCR M4?
The 2012 NCR M4 has a Capacity of 1100.0 ccm (67.13 cubic inches).
What engine power does the NCR M4 have?
The 2012 NCR M4 has a Power of 107.0 HP (78.7 kW) @ 7500 RPM.
How many gears does the NCR M4 have?
The 2012 NCR M4 has a Gearbox of 6-speed.
What is the torque of the NCR M4?
The 2012 NCR M4 has a Torque of 115.0 Nm (11.7 kgf-m or 84.8 ft.lbs) @ 5100 RPM.
How much does the NCR M4 weigh?
The 2012 NCR M4 has a Dry weight of 130.0 kg (286.6 pounds).
