Sportbikes
2016NCR M4 One Shot
32 fields on record
The 2016 NCR M4 One Shot is a lightweight superbike engineered for experienced track riders and collectors seeking ultimate performance. Producing 132 horsepower from a 126 kg chassis, it features extensive titanium fasteners, billet aluminum components, and fully adjustable Ohlins suspension tuned by NCR Corse. Best known for its meticulous craftsmanship and extreme weight savings, this Italian custom machine represents the pinnacle of hand-built motorcycle engineering.
- Capacity
- 1200.0 ccm
- Engine
- V-Twin, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 126.0 kg
- Seat height
- Not on record
Know it? Add it → - Power
- 132.0 HP (96.4 kW) @ 8700 RPM
What’s new for the 2016 NCR M4 One Shot
vs the 2015| Spec | 2015 | 2016 |
|---|---|---|
| Front brakes | Double disc. WAVE discs, radial Brembo Racing 4 piston caliper. | Double disc. WAVE discs, 4-piston 2-pad Brembo SBK radial caliper from billet. |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built as an ultra-exclusive, race-bred exotic, its purpose is pure track domination and collector-grade showcasing of no-compromise engineering rather than everyday transport.
- Built for
- It has the character of a scalpel-precise, featherweight superbike special, rewarding decisive inputs with immediate, race-car-like feedback.
- Not ideal for
- It is not for casual commuters, touring riders, or anyone seeking comfort, practicality, or a forgiving, low-stress ride.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Engine
- Capacity
- 1200.0 ccm
- Power
- 132.0 HP (96.4 kW) @ 8700 RPM
- Torque
- 143.0 Nm (14.6 kgf-m) @ 7000 RPM
- Engine type
- V-Twin, four-stroke
- Power/weight ratio
- 1.0476 HP/kg (dry)
- Compression
- 10.0:1
- Cooling system
- Oil & air
- Fuel system
- Injection
- Starting
- Electric
- Ignition
- Magneti Marelli high speed cpu with traction control and NCR designed military wiring and connectors.
- Valves per cylinder
- 4
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- NCR-EVR dry-type slipper clutch
Dimensions & weight
- Wheelbase
- 1400 mm
- Dry weight
- 126.0 kg
- Fuel capacity
- 13.00 litres
- Seat height
- Not on record - add it
Chassis & suspension
- Frame
- NCR titanium frame weight 4.8 Kg (10.6 lbs). Subframe: NCR titanium subframe with Schedoni leather seat on a carbon fiber base.
- Front suspension
- Ohlins 43 mm upside-down fork with TiN surface treatment, adjustable off-set, radial calipers with NCR CORSE billet aluminum fork bottoms, tuned by NCR CORSE. Triple clamps made from billet AL 7075 with an adjustable offset of 24 to 32 mm in 2 mm incremen
- Rear suspension
- Fully adjustable Ohlins monoshock with eccentric adjustor. Tuned by NCR CORSE
- Rake (fork angle)
- 24.0°
Brakes & wheels
- Front brakes
- Double disc. WAVE discs, 4-piston 2-pad Brembo SBK radial caliper from billet.
- Front brakes diameter
- 300 mm
- Rear brakes
- Single disc. WAVE disc, 2-piston Brembo caliper from billet..
- Rear brakes diameter
- 200 mm
- Front tyre
- 120/70-R17
- Rear tyre
- 190/55-R17
Other
- Color options
- Black. Custom paint available on request.
- Comments
- Completely using Poggipolini Titanium fasteners. Adjustable rear sets in AL 7075 and titanium, gas cap assembly in aluminum from billet, clip-ons in AL 7075 with titanium tubes, triple clamps from AL 7075 with adjustable offset from 24 to 3
- Comments
- Completely using Poggipolini Titanium fasteners. Adjustable rear sets in AL 7075 and titanium, gas cap assembly in aluminum from billet, clip-ons in AL 7075 with titanium tubes, triple clamps from AL 7075 with adjustable offset from 24 to 32 mm, Ohlins steering damper with billet mount in titanium, billet oil fill plug, front fairing stay in aluminum, NCR 32mm slave master machined from billet, titanium oil reservoirs. NCR custom oil cooler. Traction control
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2012 | 2014 | 2016 | 2017 | 2019 |
|---|---|---|---|---|---|
| Capacity | 1200 cc | 1200 cc | 1200 cc | 1200 cc | 1200 cc |
| Dry weight | 126 kg | 126 kg | 126 kg | 126 kg | 126 kg |
| Fuel capacity | 13 L | 13 L | 13 L | 13 L | 13 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the NCR M4 One Shot?
The 2016 NCR M4 One Shot has a Capacity of 1200.0 ccm (73.23 cubic inches).
What engine power does the NCR M4 One Shot have?
The 2016 NCR M4 One Shot has a Power of 132.0 HP (96.4 kW) @ 8700 RPM.
How many gears does the NCR M4 One Shot have?
The 2016 NCR M4 One Shot has a Gearbox of 6-speed.
What is the torque of the NCR M4 One Shot?
The 2016 NCR M4 One Shot has a Torque of 143.0 Nm (14.6 kgf-m or 105.5 ft.lbs) @ 7000 RPM.
How much does the NCR M4 One Shot weigh?
The 2016 NCR M4 One Shot has a Dry weight of 126.0 kg (277.8 pounds).
