Concept
2022Norton V4SV Superbike
32 fields on record
The 2022 Norton V4SV is a prototype superbike powered by a distinctive 1200cc 72-degree V4 engine producing 185 horsepower, designed for experienced riders seeking British engineering excellence and high-performance handling. Known for its innovative compact engine design featuring titanium inlet valves and chain-driven cams, the V4SV targets purists who appreciate mechanical sophistication and traditional Norton heritage combined with modern technology.
- Capacity
- 1200.0 ccm
- Engine
- V four, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 193.0 kg
- Seat height
- 836 mm
- Power
- 185.0 HP (135.0 kW) @ 12500 RPM
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built as a track-focused, boutique halo superbike prioritizing outright speed, cornering precision, and exclusivity over practicality.
- Built for
- A rare, hand-built, exotic V4 flagship for enthusiasts who want cutting-edge performance, premium components, and bragging rights over mainstream Japanese or European superbikes.
- Not ideal for
- Not suitable for new riders, commuters, pillion-carrying duties, or anyone seeking comfort, storage, or long-distance touring capability.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Engine
- Capacity
- 1200.0 ccm
- Power
- 185.0 HP (135.0 kW) @ 12500 RPM
- CO2 Emissions
- 5 CO2 g/km
- Torque
- 125.0 Nm (12.7 kgf-m) @ 9000 RPM
- Engine type
- V four, four-stroke
- Power/weight ratio
- 0.9585 HP/kg (dry)
- Bore x stroke
- 82.0 x 56.8 mm
- Compression
- 13.6:1
- Cooling system
- Liquid
- Fuel system
- Injection
- Starting
- Electric
- Valves per cylinder
- 4
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Slipper clutch
Dimensions & weight
- Wheelbase
- 1434 mm
- Seat height
- 836 mm
- Dry weight
- 193.0 kg
- Fuel capacity
- 15.00 litres
Chassis & suspension
- Frame
- Aluminium tubular chassis. Aerospace 5-axis CNC machined outriggers and headstock. Frame is hand TIG welded.
- Front suspension
- Ohlins NIX30 system front fork. Fully adjustable.
- Rear suspension
- Ohlins TTXGP Norton bespoke fully adjustable rear shock.
- Rake (fork angle)
- 23.9°
Brakes & wheels
- Front brakes
- Double disc. Radially mounted Brembo monobloc calipers. Brembo discs, and Brembo master cylinder.
- Front brakes diameter
- 330 mm
- Rear brakes
- Single disc. Brembo caliper and master-cylinder.
- Front tyre
- 3.50-17
- Rear tyre
- 6.00-17
Other
- Color options
- Manx silver/red, Carbon black/grey
- Comments
- Prototype, specs my be changed. Carbon fibre fuel tank and body panels. Traction-control, wheelie control, launch control and cruise control. Wet, Road and Sport ride modes.
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2022 | 2023 |
|---|---|---|
| Capacity | 1200 cc | 1200 cc |
| Dry weight | 193 kg | 193 kg |
| Seat height | 836 mm | 836 mm |
| Fuel capacity | 15 L | 15 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Norton V4SV Superbike?
The 2022 Norton V4SV Superbike has a Capacity of 1200.0 ccm (73.23 cubic inches).
What engine power does the Norton V4SV Superbike have?
The 2022 Norton V4SV Superbike has a Power of 185.0 HP (135.0 kW) @ 12500 RPM.
How many gears does the Norton V4SV Superbike have?
The 2022 Norton V4SV Superbike has a Gearbox of 6-speed.
What is the torque of the Norton V4SV Superbike?
The 2022 Norton V4SV Superbike has a Torque of 125.0 Nm (12.7 kgf-m or 92.2 ft.lbs) @ 9000 RPM.
How much does the Norton V4SV Superbike weigh?
The 2022 Norton V4SV Superbike has a Dry weight of 193.0 kg (425.5 pounds).
Shop this bike
Affiliate linksWe may earn a commission from qualifying eBay or Amazon purchases made through these links. As an Amazon Associate I earn from qualifying purchases.
The 2022 Norton V4SV Superbike is a high-performance motorcycle that delivers an exhilarating ride for enthusiasts. With its powerful V4 engine, advanced technology, and sleek design, the V4SV offers an impressive combination of speed, agility, and style. Whether you're hitting the open road or taking on the track, this superbike provides a thrilling experience that will leave you craving more.
Norton's attention to detail and commitment to performance is evident in every aspect of the V4SV. From its precision engineering to its cutting-edge features, this motorcycle is a true standout in its class. With its top-of-the-line components and exceptional handling, the 2022 Norton V4SV Superbike is a force to be reckoned with for riders who demand nothing but the best.
