Supermotos
2016Suzuki DR-Z400SM
37 fields on record
The 2016 Suzuki DR-Z400SM is a lightweight supermoto designed for urban riders seeking agility and fun on paved roads. Its 398cc single-cylinder engine delivers accessible power with excellent maneuverability, while the compact dimensions and 260mm ground clearance make it ideal for city commuting and spirited street riding. Best known for its nimble handling and reliability, it appeals to beginners and experienced riders alike.
- Capacity
- 398.0 ccm
- Engine
- Single, four-stroke
- Gearbox
- 5-speed
- Dry weight
- 134.0 kg
- Seat height
- 890 mm
- Power
- 40.0 HP (29.4 kW)
Other years
2005
2006
2007
2008
2009
2010
2011
2012
2013
2014
2015
2016
2017
2018
2019
2020
2021
2022
2023
2024
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- A street supermoto built for carving city streets, backroad hairpins and kart-track laps. Wheelies, stoppies and flickable fun over outright speed.
- Built for
- A playful, energetic single-cylinder motard-light, torquy and endlessly flickable. All about grins per mile rather than top-end thrills.
- Not ideal for
- Not for highway commuters, tourers or two-up riders-tiny 10L tank, buzzy single, no wind protection and a seat too tall for short inseams.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 398.0 ccm
- Power
- 40.0 HP (29.4 kW)
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.2985 HP/kg (dry)
- Bore x stroke
- 90.0 x 62.6 mm
- Compression
- 11.3:1
- Cooling system
- Liquid
- Fuel system
- Carburettor
- Starting
- Electric
- Ignition
- CDI
- Valves per cylinder
- 4
- Lubrication system
- Dry sump
- Torque
- Not on record - add it
Transmission
- Gearbox
- 5-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Multi-plate, wet type, manual release
Dimensions & weight
- Wheelbase
- 1460 mm
- Overall length
- 2225 mm
- Overall width
- 855 mm
- Overall height
- 1200 mm
- Seat height
- 890 mm
- Dry weight
- 134.0 kg
- Wet weight
- 146.0 kg
- Fuel capacity
- 9.80 litres
- Ground clearance
- 260 mm
Chassis & suspension
- Frame
- Chrome-moly steel frame
- Front suspension
- Inverted telescopic, coil spring, oil damped
- Rear suspension
- Link type, coil spring, oil damped
Brakes & wheels
- Front brakes
- Single disc
- Front brakes diameter
- 300 mm
- Rear brakes
- Single disc
- Rear brakes diameter
- 240 mm
- Front tyre
- 120/70-17
- Rear tyre
- 140/70-17
Other
- Color options
- Solid Special White/Solid Black
- Warranty
- 12
Specs last verified against published sources: .
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2005 | 2010 | 2015 | 2016 | 2019 | 2024 |
|---|---|---|---|---|---|---|
| Capacity | 398 cc | 396 cc | 398 cc | 398 cc | 398 cc | 398 cc |
| Dry weight | 134 kg | 134 kg | 134 kg | 134 kg | 134 kg | 134 kg |
| Seat height | 890 mm | 890 mm | 890 mm | 890 mm | 890 mm | 890 mm |
| Fuel capacity | 10 L | 10 L | 9.8 L | 9.8 L | 10 L | 10 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Suzuki DR-Z400SM?
The 2016 Suzuki DR-Z400SM has a Capacity of 398.0 ccm (24.29 cubic inches).
What engine power does the Suzuki DR-Z400SM have?
The 2016 Suzuki DR-Z400SM has a Power of 40.0 HP (29.4 kW).
How many gears does the Suzuki DR-Z400SM have?
The 2016 Suzuki DR-Z400SM has a Gearbox of 5-speed.
How much does the Suzuki DR-Z400SM weigh?
The 2016 Suzuki DR-Z400SM has a Dry weight of 134.0 kg (295.4 pounds).
