2010Tomos Arrow
25 fields on record
The 2010 Tomos Arrow is a lightweight 49cc scooter ideal for commuters and new riders seeking economical urban mobility. Powered by a simple two-stroke single-cylinder engine, it delivers exceptional fuel efficiency of around 235 mpg while maintaining easy maneuverability. The Arrow is best known for its reliability and affordability as an entry-level scooter option.
- Capacity
- 49.0 ccm
- Engine
- Single, two-stroke
- Gearbox
- Not on record
Know it? Add it → - Dry weight
- 64.9 kg
- Seat height
- 800 mm
- Power
- 2.4 HP (1.8 kW)
What’s new for the 2010 Tomos Arrow
vs the 2009| Spec | 2009 | 2010 |
|---|---|---|
| Power | 3.1 HP (2.3 kW) | 2.4 HP (1.8 kW) |
| Rear suspension | Swing arm with single shock | Swingarm with single shock |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built purely for short urban hops, errands, and light commuting rather than any kind of performance riding.
- Built for
- A tiny, unpretentious 49cc runabout that prioritizes economy, simplicity, and effortless puttering over speed or excitement.
- Not ideal for
- Not suitable for highway travel, touring, carrying a passenger comfortably, or anyone seeking real power or off-road capability.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usRange and running costs
Worked out in your browser - nothing is sent to usBased on the maker's published fuel consumption and tank size. Real-world figures depend on how and where you ride, and the last litres of a tank are reserve. Prices shown greyed are examples - type your own.
Engine
- Capacity
- 49.0 ccm
- Power
- 2.4 HP (1.8 kW)
- CO2 Emissions
- 23 CO2 g/km
- Torque
- 4.7 Nm (0.5 kgf-m)
- Engine type
- Single, two-stroke
- Fuel consumption
- 1.00 litres/100 km (100.0 km/l)
- Power/weight ratio
- 0.0370 HP/kg (dry)
- Compression
- 10.0:1
- Cooling system
- Air
- Fuel system
- Carburettor
- Starting
- Electric
- Ignition
- CDI
Transmission
- Transmission type
- Automatic
Dimensions & weight
- Seat height
- 800 mm
- Dry weight
- 64.9 kg
- Fuel capacity
- 3.50 litres
- Reserve fuel capacity
- 0.80 litres
Chassis & suspension
- Front suspension
- Telescopic fork
- Rear suspension
- Swingarm with single shock
Brakes & wheels
- Front brakes
- Single disc
- Rear brakes
- Expanding brake (drum brake)
- Front tyre
- 120/70-12
- Rear tyre
- 120/70-12
Other
- Color options
- Blue
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2005 | 2006 | 2008 | 2009 | 2010 |
|---|---|---|---|---|---|
| Capacity | 49 cc | 49 cc | 49 cc | 49 cc | 49 cc |
| Dry weight | 65 kg | 65 kg | 65 kg | 65 kg | 65 kg |
| Seat height | 800 mm | 800 mm | 800 mm | 800 mm | 800 mm |
| Fuel capacity | 3.5 L | 3.5 L | 3.5 L | 3.5 L | 3.5 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Tomos Arrow?
The 2010 Tomos Arrow has a Capacity of 49.0 ccm (2.99 cubic inches).
What engine power does the Tomos Arrow have?
The 2010 Tomos Arrow has a Power of 2.4 HP (1.8 kW).
What is the torque of the Tomos Arrow?
The 2010 Tomos Arrow has a Torque of 4.7 Nm (0.5 kgf-m or 3.5 ft.lbs).
How much does the Tomos Arrow weigh?
The 2010 Tomos Arrow has a Dry weight of 64.9 kg (143.1 pounds).
