2017Triumph Tiger Explorer Xca

★ 5.0

42 fields on record

The 2017 Triumph Tiger Explorer XCa is a middleweight adventure tourer designed for riders seeking long-distance touring capability with genuine off-road competence. Known for its accessible ergonomics, manageable weight, and switchable ABS, it balances street and trail performance with a 20-liter fuel tank enabling extended range. Ideal for adventure enthusiasts prioritizing comfort and versatility over extreme off-road prowess.

Capacity: 1215.0 ccm
Engine: In-line three-cylinder, four-stroke
Gearbox: 6-speed
Dry weight: 258.0 kg
Seat height: 837 mm
Power: 139.0 HP (101.5 kW) @ 9300 RPM

⇄ Compare with another bike ＋ Add to garage All model years

Other years 2016 2017

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail55%

Cornering65%

City riding55%

Daily riding75%

Touring95%

Two-up88%

Track35%

Best for: Built as a long-distance, go-anywhere touring machine that blends strong triple-cylinder performance with shaft-drive reliability and premium electronics.
Built for: A refined, torque-rich, electronically sophisticated adventure tourer that feels more like a luxury continent-crosser than a hardcore dirt machine.
Not ideal for: Not ideal for shorter or novice riders seeking a light, nimble bike for tight urban commuting or technical off-road trails.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 837mm, a rider of 68.9" with a 31" (estimated) inseam will reach the ground with balls of both feet on the 2017 Triumph Tiger Explorer Xca, with a moderate knee angle of around 90 degrees and a slightly forward riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 821-900 mm — Long Legs →

Find bikes that fit your height →

Range and running costs

Worked out in your browser - nothing is sent to us

Units

Currency

Fuel per litre

Riding a year

Based on the maker's published fuel consumption and tank size. Real-world figures depend on how and where you ride, and the last litres of a tank are reserve. Prices shown greyed are examples - type your own.

Full specifications

Engine

Capacity: 1215.0 ccm
Power: 139.0 HP (101.5 kW) @ 9300 RPM
CO2 Emissions: 114 CO2 g/km
Torque: 123.0 Nm (12.5 kgf-m) @ 6400 RPM
Engine type: In-line three-cylinder, four-stroke
Fuel consumption: 4.90 litres/100 km (20.4 km/l)
Power/weight ratio: 0.5388 HP/kg (dry)
Bore x stroke: 85.0 x 71.4 mm
Cooling system: Liquid
Fuel system: Injection
Starting: Electric
Valves per cylinder: 4

Transmission

Gearbox: 6-speed
Transmission type: Manual
Final drive: Shaft
Clutch: Wet, multi-plate hydraulically operated, torque assist

Dimensions & weight

Wheelbase: 1520 mm
Overall length: 2248 mm
Overall width: 885 mm
Overall height: 1400 mm
Seat height: 837 mm
Dry weight: 258.0 kg
Fuel capacity: 20.00 litres
Oil capacity: 4.00 litres
Ground clearance: Not on record - add it

Chassis & suspension

Frame: Tubular steel trellis frame. Single-sided, cast aluminium alloy swing arm with shaft drive.
Front suspension: WP 48 mm upside down forks, electronically adjustable damping,
Rear suspension: WP monoshock, electronically adjustable semi active damping,
Front wheel travel: 190 mm
Rear wheel travel: 193 mm
Rake (fork angle): 23.1°
Trail: 99 mm

Brakes & wheels

Front brakes: Double disc. Floating discs, radially mounted monobloc Brembo calipers, 4-piston, switchable ABS.
Front brakes diameter: 305 mm
Rear brakes: Single disc. Nissin 2-piston sliding caliper, Switchable ABS
Rear brakes diameter: 282 mm
ABS: Yes
Front tyre: 120/70-R19
Rear tyre: 170/60-R17

Other

Color options: Khaki green, white, blue
Warranty: 24
Comments: Windscreen. Auxiliary lights. Engine protection bars. Hand guards. Sump guard. Advanced On Board computer. Cruise Control. Semi Active Suspension. Electrically adjustable Touring screen.

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2016	2017
Capacity	1215 cc	1215 cc
Dry weight	258 kg	258 kg
Seat height	837 mm	837 mm
Fuel capacity	20 L	20 L

Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.

Rider Reviews

5.0

★★★★★

Rider rating

MotorcycleDB

The 2017 Triumph Tiger Explorer XCa is a top-of-the-line adventure motorcycle that offers an unbeatable combination of power, comfort, and technology. With a 1215cc inline-three engine, this bike delivers a smooth and powerful ride, whether you're cruising down the highway or tackling rough off-road terrain. The XCa model comes equipped with a host of advanced features, including cornering ABS, traction control, cruise control, and semi-active suspension, making it a versatile and capable option for any rider. Plus, with its spacious and comfortable seat, adjustable windscreen, and generous storage options, the Tiger Explorer XCa is a dream to ride on long journeys.

Overall, the 2017 Triumph Tiger Explorer XCa is a standout choice for riders looking for a high-performance adventure bike that can handle any type of riding. Its powerful engine, advanced technology, and comfortable design make it a top pick for anyone looking to conquer the open road or off-road trails. Whether you're a seasoned adventurer or a beginner looking to explore new horizons, the Tiger Explorer XCa is a reliable and capable companion for all of your two-wheeled escapades.

Own one? Add it to My Garage and write an owner review with an Owner badge.
