Adventure Motorcycles

2017Triumph Tiger Explorer Xcx

★ 5.0

42 fields on record

The 2017 Triumph Tiger Explorer XCx is a versatile middleweight adventure tourer designed for riders seeking genuine off-road capability without excessive weight. Its 1215cc parallel-twin engine delivers moderate power paired with long-travel suspension and 20-litre fuel capacity for extended exploration on mixed terrain. Best known for balanced handling and adventure touring practicality, it appeals to explorers prioritizing accessibility and real-world adventure over extreme performance.

Capacity: 1215.0 ccm
Engine: In-line three-cylinder, four-stroke
Gearbox: 6-speed
Dry weight: 253.0 kg
Seat height: 837 mm
Power: 139.0 HP (101.5 kW) @ 9300 RPM

⇄ Compare with another bike ＋ Add to garage All model years

Other years 2016 2017

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail62%

Cornering65%

City riding55%

Daily riding75%

Touring95%

Two-up88%

Track40%

Best for: Built primarily as a long-distance adventure tourer that prioritizes comfort, range, and stability over outright sportiness or hardcore off-road ability.
Built for: A refined, torquey triple-powered adventure machine that blends confident highway cruising with capable light-duty off-road manners and premium electronic rider aids.
Not ideal for: Not the right choice for riders seeking a lightweight, flickable machine for tight city streets or serious technical off-road trails.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 837mm, a rider of 68.9" with a 31" (estimated) inseam will reach the ground with balls of both feet on the 2017 Triumph Tiger Explorer Xcx, with a moderate knee angle of around 90 degrees and a slightly forward riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 821-900 mm — Long Legs →

Find bikes that fit your height →

Range and running costs

Worked out in your browser - nothing is sent to us

Units

Currency

Fuel per litre

Riding a year

Based on the maker's published fuel consumption and tank size. Real-world figures depend on how and where you ride, and the last litres of a tank are reserve. Prices shown greyed are examples - type your own.

Full specifications

Engine

Capacity: 1215.0 ccm
Power: 139.0 HP (101.5 kW) @ 9300 RPM
CO2 Emissions: 114 CO2 g/km
Torque: 123.0 Nm (12.5 kgf-m) @ 6400 RPM
Engine type: In-line three-cylinder, four-stroke
Fuel consumption: 4.90 litres/100 km (20.4 km/l)
Power/weight ratio: 0.5494 HP/kg (dry)
Bore x stroke: 85.0 x 71.4 mm
Cooling system: Liquid
Fuel system: Injection
Starting: Electric
Valves per cylinder: 4

Transmission

Gearbox: 6-speed
Transmission type: Manual
Final drive: Shaft
Clutch: Wet, multi-plate hydraulically operated, torque assist

Dimensions & weight

Wheelbase: 1520 mm
Overall length: 2248 mm
Overall width: 885 mm
Overall height: 1400 mm
Seat height: 837 mm
Dry weight: 253.0 kg
Fuel capacity: 20.00 litres
Oil capacity: 4.00 litres
Ground clearance: Not on record - add it

Chassis & suspension

Frame: Tubular steel trellis frame. Single-sided, cast aluminium alloy swing arm with shaft drive.
Front suspension: WP 48 mm upside down forks, electronically adjustable damping,
Rear suspension: WP monoshock, electronically adjustable semi active damping,
Front wheel travel: 190 mm
Rear wheel travel: 193 mm
Rake (fork angle): 23.1°
Trail: 99 mm

Brakes & wheels

Front brakes: Double disc. Floating discs, radially mounted monobloc Brembo calipers, 4-piston, switchable ABS.
Front brakes diameter: 305 mm
Rear brakes: Single disc. Nissin 2-piston sliding caliper, Switchable ABS
Rear brakes diameter: 282 mm
ABS: Yes
Front tyre: 120/70-R19
Rear tyre: 170/60-R17

Other

Color options: Black, white, blue
Warranty: 24
Comments: Windscreen. Auxiliary lights. Engine protection bars. Hand guards. Sump guard. Advanced On Board computer. Cruise Control. Semi Active Suspension.

Specs last verified against published sources: October 2026.

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2016	2017
Capacity	1215 cc	1215 cc
Dry weight	253 kg	253 kg
Seat height	837 mm	837 mm
Fuel capacity	20 L	20 L

Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.

Rider Reviews

5.0

★★★★★

Rider rating

MotorcycleDB

The 2017 Triumph Tiger Explorer XCx is a powerful and versatile adventure motorcycle that is perfect for off-road adventures and long-distance touring. Equipped with a 1215cc inline-three engine, the XCx delivers smooth and responsive power delivery with plenty of low-end torque. The electronic suspension system and advanced rider aids, such as traction control and cruise control, provide a comfortable and confident ride in various riding conditions. The bike also comes with a spacious pannier system, making it an ideal choice for riders looking to travel with luggage.

Overall, the 2017 Triumph Tiger Explorer XCx is a top-notch adventure bike with impressive performance and practical features for riders seeking both on and off-road capabilities. Its advanced technology and comfortable ride make it a standout choice in the adventure touring segment. With its powerful engine, electronic suspension, and generous luggage capacity, the XCx is an excellent option for riders looking to take their adventures to the next level.
