2016Triumph Tiger 800 XRT

★ 5.0

41 fields on record

The 2016 Triumph Tiger 800 XRT is a mid-range adventure tourer designed for riders seeking genuine off-road capability with on-road comfort. Known for its agile handling, accessible ergonomics, and comprehensive features like traction control and heated grips, it excels at blending long-distance touring with trail exploration. Its efficient 800cc engine delivers impressive fuel economy while the robust trellis frame and quality Showa suspension provide confidence across varied terrain.

Capacity: 800.0 ccm
Engine: In-line three-cylinder, four-stroke
Gearbox: 6-speed
Dry weight: 190.0 kg
Seat height: 810 mm
Power: 95.0 HP (69.3 kW) @ 9300 RPM

⇄ Compare with another bike ＋ Add to garage All model years

Other years 2016 2017 2018 2019 2020

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail62%

Cornering70%

City riding65%

Daily riding78%

Touring85%

Two-up72%

Track40%

Best for: Built primarily as a versatile adventure-touring bike that handles mixed on-road and light off-road duty with ease.
Built for: A refined, torquey triple-cylinder engine gives it a smooth, characterful power delivery that rewards relaxed, confident riding over outright aggression.
Not ideal for: Not ideal for riders seeking a lightweight city runabout or a track-focused sportbike, as its size and touring focus work against sharp, quick handling.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 810mm, a rider of 68.9" with a 31" (estimated) inseam will reach the ground with both feet flat on the 2016 Triumph Tiger 800 XRT, with a cramped knee angle of around 85 degrees and a slightly forward riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 751-820 mm — Middle Ground →

Find bikes that fit your height →

Range and running costs

Worked out in your browser - nothing is sent to us

Units

Currency

Fuel per litre

Riding a year

Based on the maker's published fuel consumption and tank size. Real-world figures depend on how and where you ride, and the last litres of a tank are reserve. Prices shown greyed are examples - type your own.

Full specifications

Engine

Capacity: 800.0 ccm
Power: 95.0 HP (69.3 kW) @ 9300 RPM
CO2 Emissions: 85 CO2 g/km
Torque: 79.0 Nm (8.1 kgf-m) @ 7850 RPM
Engine type: In-line three-cylinder, four-stroke
Fuel consumption: 3.70 litres/100 km (27.0 km/l)
Power/weight ratio: 0.5000 HP/kg (dry)
Bore x stroke: 74.0 x 61.9 mm
Compression: 11.3:1
Cooling system: Liquid
Fuel system: Injection
Starting: Electric
Valves per cylinder: 4

Transmission

Gearbox: 6-speed
Transmission type: Manual
Final drive: Chain
Clutch: Wet. multi-plate

Dimensions & weight

Wheelbase: 1545 mm
Overall length: 2215 mm
Overall width: 795 mm
Overall height: 1350 mm
Seat height: 810 mm
Dry weight: 190.0 kg
Fuel capacity: 19.00 litres
Oil capacity: 3.70 litres
Ground clearance: Not on record - add it

Chassis & suspension

Frame: Tubular steel trellis frame
Front suspension: Showa 43mm upside down forks,
Rear suspension: Showa monoshock with hydraulically adjustable preload
Rake (fork angle): 23.9°
Trail: 92 mm

Brakes & wheels

Front brakes: Double disc. Floating discs, Nissin 2-piston sliding calipers, Switchable ABS.
Front brakes diameter: 308 mm
Rear brakes: Single disc. Nissin single piston sliding caliper, Switchable ABS.
Rear brakes diameter: 255 mm
ABS: Yes
Front tyre: 2.50-19
Rear tyre: 4.50-17

Other

Color options: Intense Orange
Warranty: 24
Comments: Windscreen. Traction Control. Cruise control. Heated grips. Heated rider and passenger seat.

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2016	2017	2018	2019	2020
Capacity	800 cc	800 cc	800 cc	800 cc	800 cc
Dry weight	190 kg	190 kg	202 kg	202 kg	202 kg
Seat height	810 mm	810 mm	810 mm	810 mm	810 mm
Fuel capacity	19 L	19 L	19 L	19 L	19 L
