Adventure Motorcycles

2017Triumph Tiger 800 XRX

★ 5.0

45 fields on record

The 2017 Triumph Tiger 800 XRx is an adventure-touring motorcycle designed for riders seeking genuine off-road capability combined with long-distance comfort. Known for its lightweight middleweight platform, responsive handling, and 180mm front suspension travel, it excels at tackling mixed terrain while remaining accessible to intermediate riders. The bike balances trail-ready credentials with practical everyday usability, making it ideal for exploratory riders who value versatility over extreme specialization.

Capacity: 800.0 ccm
Engine: In-line three-cylinder, four-stroke
Gearbox: 6-speed
Dry weight: 191.0 kg
Seat height: 810 mm
Power: 95.0 HP (69.3 kW) @ 9300 RPM

⇄ Compare with another bike ＋ Add to garage All model years

Other years 2015 2016 2017 2018 2019 2020

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail68%

Cornering70%

City riding65%

Daily riding78%

Touring85%

Two-up72%

Track40%

Best for: Best suited to long-distance adventure touring and mixed on/off-road riding rather than outright speed or track work.
Built for: A refined, torquey triple-cylinder adventure tourer that balances comfort, light off-road capability, and confident road manners.
Not ideal for: Not ideal for riders seeking sportbike-level acceleration or serious technical off-road performance.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 810mm, a rider of 68.9" with a 31" (estimated) inseam will reach the ground with both feet flat on the 2017 Triumph Tiger 800 XRX, with a cramped knee angle of around 85 degrees and a slightly forward riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 751-820 mm — Middle Ground →

Find bikes that fit your height →

Range and running costs

Worked out in your browser - nothing is sent to us

Units

Currency

Fuel per litre

Riding a year

Based on the maker's published fuel consumption and tank size. Real-world figures depend on how and where you ride, and the last litres of a tank are reserve. Prices shown greyed are examples - type your own.

Full specifications

Engine

Capacity: 800.0 ccm
Power: 95.0 HP (69.3 kW) @ 9300 RPM
CO2 Emissions: 133 CO2 g/km
Torque: 79.0 Nm (8.1 kgf-m) @ 7850 RPM
Engine type: In-line three-cylinder, four-stroke
Fuel consumption: 5.70 litres/100 km (17.5 km/l)
Power/weight ratio: 0.4974 HP/kg (dry)
Bore x stroke: 74.0 x 61.9 mm
Compression: 11.3:1
Cooling system: Liquid
Fuel system: Injection
Starting: Electric
Valves per cylinder: 4

Transmission

Gearbox: 6-speed
Transmission type: Manual
Final drive: Chain
Clutch: Wet. multi-plate

Dimensions & weight

Wheelbase: 1530 mm
Overall length: 2215 mm
Overall width: 795 mm
Overall height: 1350 mm
Seat height: 810 mm
Dry weight: 191.0 kg
Wet weight: 215.0 kg
Fuel capacity: 19.00 litres
Oil capacity: 3.70 litres
Carrying capacity: Top box, saddle bags
Ground clearance: Not on record - add it

Chassis & suspension

Frame: Tubular steel trellis. Twin-sided, cast aluminium alloy swingarm.
Front suspension: Showa 43mm upside down forks,
Rear suspension: Showa monoshock with hydraulically adjustable preload
Front wheel travel: 180 mm
Rear wheel travel: 170 mm
Rake (fork angle): 23.9°
Trail: 92 mm

Brakes & wheels

Front brakes: Double disc. Floating discs, Nissin 2-piston sliding calipers, Switchable ABS.
Front brakes diameter: 308 mm
Rear brakes: Single disc. Nissin single piston sliding caliper, Switchable ABS.
Rear brakes diameter: 255 mm
ABS: Yes
Front tyre: 100/90-19
Rear tyre: 150/70-17

Other

Color options: Phantom Black, Chrystal White, Caspian Blue
Warranty: 24
Comments: Windscreen. Traction control. Cruise control. Low seat version available.

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2015	2016	2017	2018	2019	2020
Capacity	800 cc	800 cc	800 cc	800 cc	800 cc	800 cc
Dry weight	190 kg	191 kg	191 kg	200 kg	200 kg	200 kg
Seat height	810 mm	810 mm	810 mm	810 mm	810 mm	810 mm
Fuel capacity	19 L	19 L	19 L	19 L	19 L	19 L

Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.

Rider Reviews

5.0

★★★★★

Rider rating

MotorcycleDB

The 2017 Triumph Tiger 800 XRx is a capable and versatile adventure motorcycle that offers a perfect balance of on-road performance and off-road capability. With its powerful 800cc three-cylinder engine, the Tiger 800 XRx delivers plenty of smooth and responsive power for tackling any terrain. The bike's comfortable riding position and adjustable suspension make it a pleasure to ride on long journeys, while its advanced electronics, including ABS and traction control, provide added safety and confidence on various road conditions. Whether you're commuting through city streets or exploring rugged trails, the Tiger 800 XRx is a reliable and fun option for riders of all skill levels.

Overall, the 2017 Triumph Tiger 800 XRx is a fantastic adventure motorcycle that offers a thrilling and comfortable riding experience. Its powerful engine, advanced electronics, and versatile performance make it a top choice for riders looking for a reliable and capable bike for both on-road and off-road adventures. With its premium features and superior engineering, the Tiger 800 XRx is a standout option in its class and a great choice for anyone looking to take their riding to the next level.
