2016Yamaha Star VMAX

Rate this bike

41 fields on record

The 2016 Yamaha Star VMAX is a muscle cruiser designed for riders seeking aggressive styling and raw power. Known for its distinctive futuristic design and potent V4 engine, it delivers commanding cruiser performance with sport-oriented handling. Best suited for experienced riders who value bold aesthetics and dynamic riding experiences.

Capacity: 1671.6 ccm
Engine: V four, four-stroke
Gearbox: 5-speed
Wet weight: 309.8 kg
Seat height: 775 mm
Power: 200.0 HP (146.0 kW) @ 9000 RPM

⇄ Compare with another bike ＋ Add to garage All model years

What’s new for the 2016 Yamaha Star VMAX

vs the 2015

Spec	2015	2016
Torque	167.0 Nm (17.0 kgf-m or 123.2 ft.lbs)	167.0 Nm (17.0 kgf-m or 123.2 ft.lbs) @ 6500 RPM
Front brakes	Double disc. Wave-style brake discs. ABS.	Double disc. Six-piston calipers. Radially mounted.
Rear brakes	Single disc. Wave-style brake discs. ABS.	Single disc. Single-piston caliper.

Other years 2012 2013 2014 2015 2016

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail5%

Cornering65%

City riding45%

Daily riding50%

Touring40%

Two-up40%

Track55%

Best for: Built as a power-cruiser muscle bike, its purpose is straight-line thrills, aggressive acceleration, and dominating presence rather than efficient transportation.
Built for: The VMAX has a bold, unapologetic, muscle-car character, favoring raw acceleration and visual aggression over refinement or versatility.
Not ideal for: This is not for new riders, off-road use, long-distance touring comfort seekers, or anyone wanting a light, nimble, easy-to-park motorcycle.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 775mm, a rider of 68.9" with a 31" (estimated) inseam will reach the ground with both feet flat on the 2016 Yamaha Star VMAX, with a cramped knee angle of around 85 degrees and an upright riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 751-820 mm — Middle Ground →

Find bikes that fit your height →

Range and running costs

Worked out in your browser - nothing is sent to us

Units

Currency

Fuel per litre

Riding a year

Based on the maker's published fuel consumption and tank size. Real-world figures depend on how and where you ride, and the last litres of a tank are reserve. Prices shown greyed are examples - type your own.

Full specifications

Engine

Capacity: 1671.6 ccm
Power: 200.0 HP (146.0 kW) @ 9000 RPM
CO2 Emissions: 202 CO2 g/km
Torque: 167.0 Nm (17.0 kgf-m) @ 6500 RPM
Engine type: V four, four-stroke
Fuel consumption: 8.70 litres/100 km (11.5 km/l)
Power/weight ratio: 0.6456 HP/kg (wet)
Bore x stroke: 90.0 x 66.0 mm
Compression: 11.3:1
Cooling system: Liquid
Fuel system: Injection
Starting: Electric
Ignition: TCI
Valves per cylinder: 4
Lubrication system: Dry-sump

Transmission

Gearbox: 5-speed
Transmission type: Manual
Final drive: Shaft

Dimensions & weight

Wheelbase: 1699 mm
Overall length: 2395 mm
Overall width: 820 mm
Overall height: 1191 mm
Seat height: 775 mm
Wet weight: 309.8 kg
Fuel capacity: 15.10 litres
Dry weight: Not on record - add it

Chassis & suspension

Frame: Cast aluminum main frame
Front suspension: 52mm telescopic cartridge fork w/oxidized titanium coating. Fully adjustable preload, compression and rebound
Rear suspension: Single shock w/remote reservoir and remote adjustable for preload, compression and rebound
Front wheel travel: 119 mm
Rear wheel travel: 148 mm
Rake (fork angle): 31.0°
Trail: 147 mm
