2013Yamaha TDM 900

★ 1.8

45 fields on record

The 2013 Yamaha TDM 900 is a versatile middleweight sport-tourer designed for riders seeking a balanced blend of performance and practicality. Its 897cc parallel-twin engine delivers smooth, linear power with strong midrange torque, making it equally comfortable on twisty roads and long highway commutes. Known for its reliability and user-friendly character, the TDM 900 appeals to experienced riders wanting capable all-around transportation without excessive aggression.

Capacity: 897.0 ccm
Engine: Parallel Twin, four-stroke
Gearbox: 6-speed
Dry weight: 199.0 kg
Seat height: 825 mm
Power: 85.0 HP (62.5 kW) @ 7500 RPM

⇄ Compare with another bike ＋ Add to garage All model years

Other years 2002 2003 2004 2005 2006 2007 2008 2009 2010 2011 2012 2013

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail30%

Cornering75%

City riding65%

Daily riding78%

Touring80%

Two-up70%

Track40%

Best for: Built as a versatile do-it-all machine, equally happy commuting, carving backroads, or loading up for a multi-day tour.
Built for: A grounded, torque-rich parallel-twin allrounder with a Deltabox frame that rewards confident, relaxed cornering over outright aggression.
Not ideal for: Not the right choice for riders chasing track-day lap times or serious off-road capability, as its road-biased tyres and modest ground clearance limit rough terrain use.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 825mm, a rider of 175cm with a 79cm (estimated) inseam will reach the ground with balls of both feet on the 2013 Yamaha TDM 900, with a moderate knee angle of around 90 degrees and a slightly forward riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 821-900 mm — Long Legs →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 897.0 ccm
Power: 85.0 HP (62.5 kW) @ 7500 RPM
Torque: 88.8 Nm (9.1 kgf-m) @ 6000 RPM
Engine type: Parallel Twin, four-stroke
Power/weight ratio: 0.4271 HP/kg (dry)
Bore x stroke: 92.0 x 67.5 mm
Compression: 10.4:1
Cooling system: Liquid
Fuel system: Injection
Starting: Electric
Ignition: TCI
Valves per cylinder: 5
Lubrication system: Dry sump

Transmission

Gearbox: 6-speed
Transmission type: Manual
Final drive: Chain
Clutch: Wet, multiple-disc coil spring

Dimensions & weight

Wheelbase: 1485 mm
Overall length: 2180 mm
Overall width: 800 mm
Overall height: 1290 mm
Seat height: 825 mm
Dry weight: 199.0 kg
Wet weight: 223.0 kg
Fuel capacity: 20.00 litres
Ground clearance: 160 mm
Oil capacity: 4.70 litres
Carrying capacity: luggage rack for touring

Chassis & suspension

Frame: Aluminium Deltabox, Diamond Shaped
Front suspension: Telescopic forks
Rear suspension: Swingarm (link suspension)
Front wheel travel: 150 mm
Rear wheel travel: 133 mm
Rake (fork angle): 25.0°
Trail: 114 mm

Brakes & wheels

Front brakes: Double disc. Hydraulic. Optional ABS.
Front brakes diameter: 298 mm
Rear brakes: Single disc. Hydraulic. Optional ABS.
Rear brakes diameter: 245 mm
ABS: Optional
Front tyre: 120/70-ZR18
Rear tyre: 160/60-ZR17

Other

Color options: Midnight black, Gun metallic
Comments: ABS brakes adds 3 kg weight.

Specs last verified against published sources: October 2026.

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2002	2005	2008	2010	2013
Capacity	897 cc	897 cc	897 cc	897 cc	897 cc
Dry weight	190 kg	190 kg	192 kg	196 kg	199 kg
Seat height	825 mm	825 mm	825 mm	825 mm	825 mm
Fuel capacity	20 L	—	20 L	20 L	20 L
