Naked Motorcycles
2023Yamaha XSR700 Legacy
41 fields on record
The 2023 Yamaha XSR700 Legacy is a modern retro-styled middleweight that appeals to riders seeking classic aesthetics with contemporary performance and reliability. Powered by Yamaha's proven 689cc CP2 twin-cylinder engine producing nearly 74 horsepower, it delivers nimble handling and approachable power ideal for both new and experienced riders. Best known for blending vintage charm with cutting-edge technology, the XSR700 excels as an accessible, versatile platform for everyday commuting and spirited weekend rides.
- Capacity
- 689.0 ccm
- Engine
- Parallel Twin, four-stroke
- Gearbox
- 6-speed
- Wet weight
- 190.0 kg
- Seat height
- 855 mm
- Power
- 73.8 HP (53.8 kW) @ 8750 RPM
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built purely for closed-course motocross racing, not for street use, commuting, or touring.
- Built for
- A lightweight, high-revving single-cylinder race weapon designed for maximum agility, jumps, and rapid direction changes on dirt tracks.
- Not ideal for
- Not suitable for new riders, passengers, daily commuting, or anyone seeking road comfort and touring capability.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usRange and running costs
Worked out in your browser - nothing is sent to usBased on the maker's published fuel consumption and tank size. Real-world figures depend on how and where you ride, and the last litres of a tank are reserve. Prices shown greyed are examples - type your own.
Engine
- Capacity
- 689.0 ccm
- Power
- 73.8 HP (53.8 kW) @ 8750 RPM
- Torque
- 67.0 Nm (6.8 kgf-m) @ 6500 RPM
- Engine type
- Parallel Twin, four-stroke
- Fuel consumption
- 4.30 litres/100 km (23.3 km/l)
- Power/weight ratio
- 0.3884 HP/kg (wet)
- Bore x stroke
- 80.0 x 68.6 mm
- Compression
- 11.5:1
- Cooling system
- Liquid
- Fuel system
- Injection
- Starting
- Electric
- Ignition
- TCI
- Valves per cylinder
- 4
- Lubrication system
- Wet sump
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Clutch
- Wet, Multiple Disc
Dimensions & weight
- Wheelbase
- 1405 mm
- Overall length
- 2075 mm
- Overall width
- 865 mm
- Overall height
- 1120 mm
- Seat height
- 855 mm
- Wet weight
- 190.0 kg
- Fuel capacity
- 14.00 litres
- Ground clearance
- 140 mm
- Oil capacity
- 3.00 litres
- Dry weight
- Not on record - add it
Chassis & suspension
- Frame
- Tubular backbone, diamond
- Front suspension
- 41mm telescopic fork
- Rear suspension
- Single shock, adjustable preload
- Front wheel travel
- 130 mm
- Rear wheel travel
- 130 mm
- Rake (fork angle)
- 24.5°
- Trail
- 90 mm
Brakes & wheels
- Front brakes
- Double disc. Hydraulic. ABS.
- Front brakes diameter
- 282 mm
- Rear brakes
- Single disc. Hydraulic single disc
- ABS
- Yes
- Front tyre
- 120/70-ZR17
- Rear tyre
- 180/55-ZR17
Other
- Color options
- Speedblock Silver
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2023 | 2024 |
|---|---|---|
| Capacity | 689 cc | 689 cc |
| Seat height | 855 mm | 855 mm |
| Fuel capacity | 14 L | 14 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Yamaha XSR700 Legacy?
The 2023 Yamaha XSR700 Legacy has a Capacity of 689.0 ccm (42.05 cubic inches).
What engine power does the Yamaha XSR700 Legacy have?
The 2023 Yamaha XSR700 Legacy has a Power of 73.8 HP (53.8 kW) @ 8750 RPM.
How many gears does the Yamaha XSR700 Legacy have?
The 2023 Yamaha XSR700 Legacy has a Gearbox of 6-speed.
What is the torque of the Yamaha XSR700 Legacy?
The 2023 Yamaha XSR700 Legacy has a Torque of 67.0 Nm (6.8 kgf-m or 49.4 ft.lbs) @ 6500 RPM.
How much does the Yamaha XSR700 Legacy weigh?
The 2023 Yamaha XSR700 Legacy has a Wet weight of 190.0 kg (418.9 pounds).
