Dual-Sport Motorcycles
2005Yamaha XT125R
38 fields on record
The 2005 Yamaha XT 125 R is a lightweight enduro designed for novice riders and commuters seeking affordable off-road capability. Its air-cooled single-cylinder engine delivers modest power ideal for trail riding and urban exploration. The bike is renowned for its durability, simplicity and accessible handling characteristics that make it perfect for learning fundamental motorcycle skills.
- Capacity
- 124.0 ccm
- Engine
- Single
- Gearbox
- 5-speed
- Dry weight
- 118.0 kg
- Seat height
- 860 mm
- Power
- 12.5 HP (9.2 kW)
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built to be ridden on the road and on dirt tracks, making it a versatile do-it-all machine.
- Built for
- A dual-sport from Yamaha with a 124cc engine; its character is easy-going and economical, with 12 hp on tap.
- Not ideal for
- Not for riders wanting high-speed motorway comfort or track performance.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 124.0 ccm
- Power
- 12.5 HP (9.2 kW)
- Engine type
- Single
- Power/weight ratio
- 0.1059 HP/kg (dry)
- Bore x stroke
- 54.0 x 54.0 mm
- Compression
- 10.0:1
- Cooling system
- Air
- Fuel system
- Carburettor
- Starting
- Electric
- Ignition
- CDI
- Lubrication system
- Separate lubrication
- Torque
- Not on record - add it
Transmission
- Gearbox
- 5-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Wet, multiple disc
Dimensions & weight
- Wheelbase
- 1335 mm
- Overall length
- 1995 mm
- Overall width
- 840 mm
- Overall height
- 1125 mm
- Seat height
- 860 mm
- Dry weight
- 118.0 kg
- Wet weight
- 120.0 kg
- Fuel capacity
- 10.00 litres
- Ground clearance
- 220 mm
- Oil capacity
- 1.20 litres
Chassis & suspension
- Frame
- Diamond shaped
- Front suspension
- Hydraulic telescopic fork
- Rear suspension
- Monocross
- Front wheel travel
- 120 mm
- Rear wheel travel
- 200 mm
- Trail
- 114 mm
Brakes & wheels
- Front brakes
- Single disc
- Front brakes diameter
- 245 mm
- Rear brakes
- Single disc
- Rear brakes diameter
- 220 mm
- Front tyre
- 90/90-21
- Rear tyre
- 120/80-18
Specs last verified against published sources: .
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2005 | 2006 | 2007 | 2008 | 2009 |
|---|---|---|---|---|---|
| Capacity | 124 cc | 124 cc | 124 cc | 124 cc | 124 cc |
| Dry weight | 118 kg | 118 kg | 118 kg | 118 kg | 118 kg |
| Seat height | 860 mm | 860 mm | 860 mm | 860 mm | 860 mm |
| Fuel capacity | 10 L | 10 L | 10 L | 10 L | 9 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Yamaha XT125R?
The 2005 Yamaha XT125R has a Capacity of 124.0 ccm (7.57 cubic inches).
What engine power does the Yamaha XT125R have?
The 2005 Yamaha XT125R has a Power of 12.5 HP (9.2 kW).
How many gears does the Yamaha XT125R have?
The 2005 Yamaha XT125R has a Gearbox of 5-speed.
How much does the Yamaha XT125R weigh?
The 2005 Yamaha XT125R has a Dry weight of 118.0 kg (260.1 pounds).
