Dual-Sport Motorcycles
2009Yamaha XT125R
40 fields on record
The 2009 Yamaha XT125R is a lightweight enduro bike ideal for beginners and riders seeking affordable off-road capability. Known for its reliable single-cylinder engine and practical dual electric and kick starting system, it delivers accessible performance for both trail riding and commuting duties.
- Capacity
- 124.0 ccm
- Engine
- Single
- Gearbox
- 5-speed
- Dry weight
- 118.0 kg
- Seat height
- 860 mm
- Power
- 9.8 HP (7.2 kW)
What’s new for the 2009 Yamaha XT125R
vs the 2008| Spec | 2008 | 2009 |
|---|---|---|
| Power | 9.8 HP (7.2 kW) @ 8500 RPM | 9.8 HP (7.2 kW) |
| Torque | 9.5 Nm (1.0 kgf-m or 7.0 ft.lbs) | 10.1 Nm (1.0 kgf-m or 7.4 ft.lbs) |
| Fuel capacity | 10.00 litres (2.64 US gallons) | 9.00 litres (2.38 US gallons) |
| Front suspension | Hydraulic telescopic forks | Telescopic forks |
| Rear suspension | Monocross | Swingarm |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Designed as a small-capacity enduro-styled learner bike, it suits light trail exploration, commuting, and general low-speed fun rather than performance riding.
- Built for
- It has a friendly, approachable, non-intimidating character with modest power delivery and simple, forgiving handling.
- Not ideal for
- It is not suited to riders wanting highway speeds, long-distance touring comfort, or serious two-up passenger use.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 124.0 ccm
- Power
- 9.8 HP (7.2 kW)
- Torque
- 10.1 Nm (1.0 kgf-m)
- Engine type
- Single
- Power/weight ratio
- 0.0831 HP/kg (dry)
- Bore x stroke
- 54.0 x 54.0 mm
- Compression
- 10.0:1
- Cooling system
- Air
- Fuel system
- Carburettor
- Starting
- Electric
- Ignition
- CDI
- Lubrication system
- Wet sump
Transmission
- Gearbox
- 5-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Wet, multiple disc
Dimensions & weight
- Wheelbase
- 1335 mm
- Overall length
- 2110 mm
- Overall width
- 800 mm
- Overall height
- 1140 mm
- Seat height
- 860 mm
- Dry weight
- 118.0 kg
- Wet weight
- 120.0 kg
- Fuel capacity
- 9.00 litres
- Ground clearance
- 220 mm
- Oil capacity
- 1.20 litres
Chassis & suspension
- Frame
- Diamond shaped
- Front suspension
- Telescopic forks
- Rear suspension
- Swingarm
- Front wheel travel
- 170 mm
- Rear wheel travel
- 190 mm
- Trail
- 114 mm
Brakes & wheels
- Front brakes
- Single disc
- Front brakes diameter
- 245 mm
- Rear brakes
- Single disc
- Rear brakes diameter
- 220 mm
- Front tyre
- 90/90-S21
- Rear tyre
- 120/80-S18
Other
- Color options
- Blue, black
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2005 | 2006 | 2007 | 2008 | 2009 |
|---|---|---|---|---|---|
| Capacity | 124 cc | 124 cc | 124 cc | 124 cc | 124 cc |
| Dry weight | 118 kg | 118 kg | 118 kg | 118 kg | 118 kg |
| Seat height | 860 mm | 860 mm | 860 mm | 860 mm | 860 mm |
| Fuel capacity | 10 L | 10 L | 10 L | 10 L | 9 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Yamaha XT125R?
The 2009 Yamaha XT125R has a Capacity of 124.0 ccm (7.57 cubic inches).
What engine power does the Yamaha XT125R have?
The 2009 Yamaha XT125R has a Power of 9.8 HP (7.2 kW).
How many gears does the Yamaha XT125R have?
The 2009 Yamaha XT125R has a Gearbox of 5-speed.
What is the torque of the Yamaha XT125R?
The 2009 Yamaha XT125R has a Torque of 10.1 Nm (1.0 kgf-m or 7.4 ft.lbs).
How much does the Yamaha XT125R weigh?
The 2009 Yamaha XT125R has a Dry weight of 118.0 kg (260.1 pounds).
