BMW R 1200 GS Adventure - 2015 Specifications and Reviews
General information | |
| Category: | Enduro / offroad |
| Year: | 2015 |
| Model: | BMW R 1200 GS Adventure |
Engine and Transmission Specifications | |
| Emission details: | Closed-loop 3-way catalytic converter, emission standard EU-3 |
| Greenhouse gases: | 99.8 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Fuel consumption: | 4.30 litres/100 km (23.3 km/l or 54.70 mpg) |
| Driveline: | Constant mesh |
| Clutch: | Oil lubricated clutch, hydraulically operated |
| Transmission type,final drive: | Shaft drive (cardan) |
| Gearbox: | 6-speed |
| Cooling system: | Oil & air |
| Fuel control: | Double Overhead Cams/Twin Cam (DOHC) |
| Fuel system: | Injection. Electronic intake pipe injection |
| Valves per cylinder: | 4 |
| Bore x Stroke: | 101.0 x 73.0 mm (4.0 x 2.9 inches) |
| Compression: | 12.5:1 |
| Torque: | 125.00 Nm (12.7 kgf-m or 92.2 ft.lbs) @ 6500 Revolutions">RPM |
| Power: | 125.00 Horsepower">HP (91.2 Kilowatt">kW)) @ 7750 Revolutions">RPM |
| Engine type: | Two cylinder boxer, four-stroke |
| Capacity: | 1170.00 ccm (71.39 cubic inches) |
Brakes, suspension, Frame and wheels | |
| Wheels: | Cross-spoke wheels |
| Rear brakes diameter: | 275 mm (10.8 inches) |
| Rear brakes: | Single disc. ABS. Floating disc. Two-piston calipers. |
| Front brakes diameter: | 305 mm (12.0 inches) |
| Front brakes: | Double disc. ABS. Floating discs. Four-piston calipers. |
| Rear tyre: | 170/60-R17 |
| Front tyre: | 120/70-R19 |
| Rear wheel travel: | 220 mm (8.7 inches) |
| Rear Suspension: | Cast aluminium single-sided swing arm with BMW Motorrad Paralever; WAD strut (travel-related damping), spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable at handwheel |
| Front wheel travel: | 210 mm (8.3 inches) |
| Front Suspension: | BMW Motorrad Telelever; stanchion diameter 37 mm, central spring strut |
| Trail: | 93 mm (3.6 inches) |
| Rake (fork angle): | 24.5° |
| Frame type: | Two-section frame consisting of front and rear sections, load- bearing engine-gearbox unit |
Physical measures and capacities | |
| Reserve fuel capacity: | 4.00 litres (1.06 gallons) |
| Fuel capacity: | 30.00 litres (7.93 gallons) |
| Wheelbase: | 1,510 mm (59.4 inches) |
| Overall width: | 980 mm (38.6 inches) |
| Overall length: | 2,255 mm (88.8 inches) |
| Overall height: | 1,450 mm (57.1 inches) |
| Seat height: | 890 mm (35.0 inches) If adjustable, lowest setting. |
| Power/weight ratio: | 0.5457 HP/kg |
| Weight incl. oil, gas, etc: | 260.0 kg (573.2 pounds) |
| Dry weight: | 229.1 kg (505.0 pounds) |
Other specs | |
| Comments: | Windscreen. |
| Electrical: | 12 V / 11.8 Ah, maintenance-free battery. |
| Starter: | Electric |
| Color options: | White, blue, olive |
