Harley-Davidson Freewheeler - 2026 Specifications and Reviews
The 2026 Harley-Davidson Freewheeler is a three-wheeled cruiser designed for riders seeking stability and commanding presence on the road. Powered by the Milwaukee-Eight 114 V-twin engine delivering 90 horsepower and 161.4 Nm of torque, it combines classic cruiser styling with modern performance. Best known for its unique trike configuration, comfortable seating, and effortless highway cruising capability.
General information | |
| Color Options | Vivid Black, Billiard Gray,Whiskey Fire, Black |
| Price | US$ 31999. MSRP depends on country, taxes, accessories, etc. |
| Category | Custom / cruiser |
| Model | Harley-Davidson Freewheeler |
| | |
Engine and Transmission Specifications | |
| Starting | Electric |
| Emission | 126.9 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Fuel Consumption | 5.47 litres/100 km (18.3 km/l or 43.00 mpg) |
| Clutch | Multi-plate with diaphragm spring in oil bath |
| Final Drive | Belt (final drive) |
| Gearbox | 6-speed |
| Cooling System | Oil & air |
| Fuel Control | Double Overhead Cams/Twin Cam (DOHC) |
| Induction | Injection. Electronic Sequential Port Fuel Injection |
| Bore x Stroke | 102.0 x 114.3 mm (4.0 x 4.5 inches) |
| Compression Ratio | 10.5:1 |
| Max Torque | 161.4 Nm (16.5 kgf-m or 119.0 ft.lbs) @ 2750 RPM |
| Max Power | 90.0 HP (65.7 kW)) @ 4750 RPM |
| Engine Details | Milwaukee-Eight™ 114 |
| Capacity: | 1868.0 ccm (113.99 cubic inches) |
| | |
Physical measures and capacities | |
| Fuel Capacity | 22.71 litres (6.00 US gallons) |
| Wheelbase | 1670 mm (65.7 inches) |
| Ground Clearance | 125 mm (4.9 inches) |
| Overall Width | 1405 mm (55.3 inches) |
| Overall Length | 2615 mm (103.0 inches) |
| Seat Height | 665 mm (26.2 inches) If adjustable, lowest setting. |
| Power/Weight Ratio | 0.1815 HP/kg |
| Wet Weight | 513.0 kg (1,131.0 pounds) |
| Dry Weight | 495.8 kg (1,093.0 pounds) |
Harley-Davidson Freewheeler dimensions and frame | |
| Wheels | Cast Aluminum. Dunlop® Harley-Davidson Series tires. |
| Rear Brakes | Expanding brake (drum brake). 2-piston caliper. ABS. |
| Front Brakes | Double disc. 4 piston caliper. ABS. |
| Rear Tyre | 215/45-R18 |
| Front Tyre | 130/60-B19 |
| Rear Suspension | Hand-adjustable emulsion rear suspension |
| Front Suspension | Telescopic fork, 49mm dual bending valve |
| Trail | 101 mm (4.0 inches) |
Other specs | |
| Maintenance | Find parts, fluids, filters, maintenance tools and service items on eBay |
| Update specs | Report missing specs or required updates. |
| Carrying Capacity | Trunk, 2 cu ft |
| Lighting | Dual halogen headlight 55-watt 625 lumen low beam, 65-watt 1,570 lumen high beam, Incandescent tail/stop, front signal lights and rear turn signals |
| Instruments | Speedometer, fuel gauges; display features odometer, trip A, trip B, range to empty, and gear indicator |
| Oil capacity | 4.70 litres (4.97 US quarts) |
| Rake (fork angle) | 26.0° |
| Exhaust system | Shorty slash down-style chrome finish mufflers |
| Driveline | Chain, 34/46 ratio primary drive |
| Engine type | V2, four-stroke |
| Model year | 2025 |
