Harley-Davidson VRSCDX Night Rod Special - 2011 Specifications and Reviews

Not Rated stars Average rating: Not Rated from 0 votes
.

General information

CategoryCustom / cruiser
Year2011
ModelHarley-Davidson VRSCDX Night Rod Special

Engine and Transmission Specifications

Exhaust systemBrushed, straight-shot exhaust with dual mufflers,
DrivelinePrimary Drive: Gear, 117/64 ratio. Final Drive: Belt, 72/28 ratio
Clutch9-plate, wet, Assist and Slip
Transmission type,final driveBelt
Gearbox5-speed
Cooling systemLiquid
Lubrication systemWet-sump, integrated with powertrain crankcase
Fuel systemInjection. Electronic Sequential Port Fuel Injection (ESPFI)
Valves per cylinder4
Bore x stroke105.0 x 72.0 mm (4.1 x 2.8 inches)
Compression11.5:1
Torque115.00 Nm (11.7 kgf-m or 84.8 ft.lbs) @ 7000
Engine detailsLiquid-cooled, Revolution, 60° V-Twin. Overhead cam, 4 valves per cylinder, solid tappet with shim-under-bucket lash adjustment.
Engine typeV2, four-stroke
Capacity:1250.00 ccm (76.28 cubic inches)

Brakes, suspension, Frame and wheels

WheelsBlack, Slotted Disc Cast Aluminum
Rear brakes diameter300 mm (11.8 inches)
Rear brakesSingle disc. 4-piston. Uniform expansion rotor.
Front brakes diameter300 mm (11.8 inches)
Front brakesDouble disc. 4-piston. Patented, one-piece floating rotor.
Rear tyre dimensions240/40-R18
Front tyre dimensions120/70-ZR19
Rear suspension travel102 mm (4.0 inches)
Rear suspensionPreload adjustable
Front suspension travel102 mm (4.0 inches)
Front suspensionWide, 49mm custom fork
Trail114 mm (4.5 inches)
Rake (fork angle)34.0°
Frame typeSteel perimeter upper frame with hydroformed main rails and bolt-on lower frame rails; MIG welded



Physical measures and capacities

Oil capacity4.40 litres (0.29 quarts)
Fuel capacity18.90 litres (4.99 gallons)
Wheelbase1,715 mm (67.5 inches)
Ground clearance140 mm (5.5 inches)
Overall length2,460 mm (96.9 inches)
Seat height690 mm (27.2 inches) If adjustable, lowest setting.
Dry weight293.0 kg (646.0 pounds)

Other specs

Carrying capacityFront and rear rack
Wheelbase1,490 mm (58.7 inches)
Overall width1,180 mm (46.5 inches)
Overall height1,230 mm (48.4 inches)
Power/weight ratio0.1114 HP/kg
Rear tyre25/10-12
Front tyre25/8-12
Rear SuspensionGas shocks with pre-load adjustment
Front SuspensionIndependent double A-arm
IgnitionCDI
Fuel controlSingle Overhead Cams (SOHC)
Bore x Stroke96.0 x 82.0 mm (3.8 x 3.2 inches)
Compression10.2:1
Torque46.90 Nm (4.8 kgf-m or 34.6 ft.lbs)
Power37.55 Horsepower">HP (27.4 Kilowatt">kW))
Capacity:594.00 ccm (36.25 cubic inches)
ModelGoes G 625i Max
Color optionsBrilliant Silver Pearl/Black Racing Stripe with Ghost Flames, Chrome Yellow/Black Racing Stripe with Ghost Flames, Sedona Orange/Black Racing Stripe with Ghost Flames, Black Denim/Sedona Orange Racing Stripe
Factory warranty24 months
ElectricalSealed, maintenance-free, 12V, 19-amp/hour, 270 cca battery. Charging: Three-Phase, 38-amp system
Light55-watt low beam, 60-watt high beam
InstrumentsElectronic speedometer with odometer, time-of-day clock on odometer, dual tripmeter, fuel gauge with low fuel warning light and countdown feature, low oil pressure indicator light, engine diagnostics readout, LED indicator lights, tachometer
StarterElectric
