Modenas CT100 - 2011 Specifications and Reviews

2011
4 stars Average rating: 4 from 1 votes
.

General information

Category:Scooter
Year:2011
Model:Modenas CT100

Engine and Transmission Specifications

Clutch:Centrifugal
Transmission type,final drive:Chain
Gearbox:4-speed
Cooling system:Air
Lubrication system:Forced Lubrication Wet
Fuel control:SOHC
Fuel system:Carburettor. Keihin PB18 x 1
Bore x stroke:50.0 x 49.5 mm (2.0 x 1.9 inches)
Compression:9.0:1
Engine type:Single cylinder, four-stroke
Capacity:97.20 ccm (5.93 cubic inches)


Brakes, suspension, Frame and wheels

Rear brakes diameter:110 mm (4.3 inches)
Rear brakes:Expanding brake (drum brake)
Front brakes diameter:110 mm (4.3 inches)
Front brakes:Expanding brake (drum brake)
Rear suspension:Trailing swing arm suspension
Front suspension:Telescopic fork

Physical measures and capacities

Oil capacity:0.90 litres (0.06 quarts)
Fuel capacity:5.50 litres (1.45 gallons)


Other specs

Comments:Chinese made bike.
Wheelbase:1,200 mm (47.2 inches)
Ground clearance:170 mm (6.7 inches)
Overall width:1,070 mm (42.1 inches)
Overall length:1,570 mm (61.8 inches)
Overall height:850 mm (33.5 inches)
Power/weight ratio:0.1710 HP/kg
Dry weight:98.0 kg (216.1 pounds)
Wheels:14 inch wheels
Rear Suspension:Aluminum, air-cell adjustable
Front Suspension:Aluminum, air-cell adjustable
Bore x Stroke:70.0 x 64.8 mm (2.8 x 2.6 inches)
Top speed:90.0 km/h (55.9 mph)
Power:16.76 Horsepower">HP (12.2 Kilowatt">kW)) @ 7000 Revolutions">RPM
Capacity:250.00 ccm (15.26 cubic inches)
Color options:Yellow, green, maroon, blue
Starter:Kick
