General information | |
| Category: | Scooter |
| Year: | 2011 |
| Model: | Modenas CT100 |
Engine and Transmission Specifications | |
| Clutch: | Centrifugal |
| Transmission type,final drive: | Chain |
| Gearbox: | 4-speed |
| Cooling system: | Air |
| Lubrication system: | Forced Lubrication Wet |
| Fuel control: | SOHC |
| Fuel system: | Carburettor. Keihin PB18 x 1 |
| Bore x stroke: | 50.0 x 49.5 mm (2.0 x 1.9 inches) |
| Compression: | 9.0:1 |
| Engine type: | Single cylinder, four-stroke |
| Capacity: | 97.20 ccm (5.93 cubic inches) |
Brakes, suspension, Frame and wheels | |
| Rear brakes diameter: | 110 mm (4.3 inches) |
| Rear brakes: | Expanding brake (drum brake) |
| Front brakes diameter: | 110 mm (4.3 inches) |
| Front brakes: | Expanding brake (drum brake) |
| Rear suspension: | Trailing swing arm suspension |
| Front suspension: | Telescopic fork |
Physical measures and capacities | |
| Oil capacity: | 0.90 litres (0.06 quarts) |
| Fuel capacity: | 5.50 litres (1.45 gallons) |
Other specs | |
| Comments: | Chinese made bike. |
| Wheelbase: | 1,200 mm (47.2 inches) |
| Ground clearance: | 170 mm (6.7 inches) |
| Overall width: | 1,070 mm (42.1 inches) |
| Overall length: | 1,570 mm (61.8 inches) |
| Overall height: | 850 mm (33.5 inches) |
| Power/weight ratio: | 0.1710 HP/kg |
| Dry weight: | 98.0 kg (216.1 pounds) |
| Wheels: | 14 inch wheels |
| Rear Suspension: | Aluminum, air-cell adjustable |
| Front Suspension: | Aluminum, air-cell adjustable |
| Bore x Stroke: | 70.0 x 64.8 mm (2.8 x 2.6 inches) |
| Top speed: | 90.0 km/h (55.9 mph) |
| Power: | 16.76 Horsepower">HP (12.2 Kilowatt">kW)) @ 7000 Revolutions">RPM |
| Capacity: | 250.00 ccm (15.26 cubic inches) |
| Color options: | Yellow, green, maroon, blue |
| Starter: | Kick |
