Moto Guzzi Norge GT 8V - 2017 Specifications and Reviews

Not Rated stars Average rating: Not Rated from 0 votes

General information

Category:Sport touring
Model:Moto Guzzi Norge GT 8V

Engine and Transmission Specifications

Exhaust system:Stainless steel with central equalizer and with 3-way catalytic converter with two Lambda probes
Emission details:Euro 3
Driveline:CARC compact reactive cardan shaft drive system; double cardan joint and floating bevel gear set, drive ratio 12/44 = 1 : 3.666
Clutch:Dry plate
Transmission type,final drive:Shaft drive (cardan)
Cooling system:Air
Fuel control:Overhead Valves (OHV)
Fuel system:Injection. Magneti Marelli IAW5A, and #945;-n type; 2 45 mm throttle bodies, Weber IWP 162 injectors, Lambda control, twin spark ignition
Valves per cylinder:4
Bore x Stroke:95.0 x 81.2 mm (3.7 x 3.2 inches)
Torque:104.00 Nm (10.6 kgf-m or 76.7 ft.lbs) @ 5500 Revolutions">RPM
Power:102.00 Horsepower">HP (74.5 Kilowatt">kW)) @ 7000 Revolutions">RPM
Engine details:90° V-Twin,
Engine type:V2, four-stroke

Brakes, suspension, Frame and wheels

Wheels:Three spokes, light alloy wheels, gravity casting
Rear brakes diameter:282 mm (11.1 inches)
Rear brakes:Single disc. ABS. Stainless steel fixed disc, floating calliper with 2 parallel pistons - ABS
Front brakes diameter:320 mm (12.6 inches)
Front brakes:Double disc. ABS. Stainless steel floating discs and callipers with 4 horizontally opposed pistons - ABS
Rear tyre:180/55-ZR17
Front tyre:120/70-ZR17
Rear wheel travel:140 mm (5.5 inches)
Rear Suspension:Single arm suspension with progressive linkage, rear shock absorber adjustable in rebound and pre-load (hydraulic)
Front wheel travel:120 mm (4.7 inches)
Front Suspension:Telescopic hydraulic fork with 45 mm stanchions and adjustable spring preload
Frame type:Tubular cradle, high tensile steel

Physical measures and capacities

Reserve fuel capacity:3.79 litres (1.00 gallons)
Fuel capacity:23.00 litres (6.08 gallons)
Wheelbase:1,495 mm (58.9 inches)
Ground clearance:185 mm (7.3 inches)
Overall width:870 mm (34.3 inches)
Overall length:2,195 mm (86.4 inches)
Overall height:1,125 mm (44.3 inches)
Seat height:810 mm (31.9 inches) If adjustable, lowest setting.
Power/weight ratio:0.3969 HP/kg
Dry weight:257.0 kg (566.6 pounds)

Other specs

Carrying capacity:Hard saddle bags
Color options:White
