Naked Motorcycles
2003Cagiva V-Raptor 650
30 fields on record
The 2003 Cagiva V-Raptor 650 is a middleweight naked bike powered by a 645cc V-twin engine producing 70 horsepower. It appeals to riders seeking an agile, accessible machine with Italian styling and manageable performance. Known for its lightweight frame and responsive handling, it offers an engaging riding experience for both novice and experienced enthusiasts.
- Capacity
- 645.0 ccm
- Engine
- V-Twin, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 185.0 kg
- Seat height
- 805 mm
- Power
- 70.0 HP (51.5 kW) @ 9000 RPM
What’s new for the 2003 Cagiva V-Raptor 650
vs the 2002| Spec | 2002 | 2003 |
|---|---|---|
| Power | 73.0 HP (53.7 kW) | 70.0 HP (51.5 kW) @ 9000 RPM |
| Torque | 64.0 Nm (6.5 kgf-m or 47.2 ft.lbs) @ 7400 RPM | 63.6 Nm (6.5 kgf-m or 46.9 ft.lbs) |
| Dry weight | 183.0 kg (403.4 pounds) | 185.0 kg (407.9 pounds) |
| Front brakes | Dual disc | not listed |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Designed for spirited street riding and twisty backroads where its light weight and torquey V-twin can be enjoyed.
- Built for
- Has the raw, gritty personality typical of an Italian V-twin naked, favoring feel and feedback over outright refinement.
- Not ideal for
- Not a good fit for riders seeking long-distance touring comfort, pillion-friendly cruising, or any off-road capability.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 645.0 ccm
- Power
- 70.0 HP (51.5 kW) @ 9000 RPM
- Torque
- 63.6 Nm (6.5 kgf-m)
- Engine type
- V-Twin, four-stroke
- Power/weight ratio
- 0.3784 HP/kg (dry)
- Bore x stroke
- 81.0 x 62.6 mm
- Compression
- 11.5:1
- Cooling system
- Liquid
- Fuel system
- Carburettor
- Starting
- Electric
- Valves per cylinder
- 4
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
Dimensions & weight
- Wheelbase
- 1432 mm
- Seat height
- 805 mm
- Dry weight
- 185.0 kg
- Fuel capacity
- 19.30 litres
Chassis & suspension
- Frame
- High strength steel tubular frame
- Front suspension
- Upside Down fully adjustable hydraulic fork
- Rear suspension
- Progressive single shock with atjustable rebound - compression damping and spring preload. Double sided swingarm.
- Front wheel travel
- 120 mm
- Rear wheel travel
- 138 mm
Brakes & wheels
- Front brakes diameter
- 298 mm
- Rear brakes
- Single disc
- Rear brakes diameter
- 220 mm
- Front tyre
- 120/70-17
- Rear tyre
- 160/60-17
Other
- Color options
- Silver, Red
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2001 | 2002 | 2003 | 2004 | 2005 | 2006 |
|---|---|---|---|---|---|---|
| Capacity | 645 cc | 645 cc | 645 cc | 645 cc | 644 cc | 644 cc |
| Dry weight | 185 kg | 183 kg | 185 kg | 185 kg | 180 kg | 180 kg |
| Seat height | 775 mm | 805 mm | 805 mm | 800 mm | 800 mm | 775 mm |
| Fuel capacity | 19 L | 19.3 L | 19.3 L | 19.3 L | 19.3 L | 19.3 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Cagiva V-Raptor 650?
The 2003 Cagiva V-Raptor 650 has a Capacity of 645.0 ccm (39.36 cubic inches).
What engine power does the Cagiva V-Raptor 650 have?
The 2003 Cagiva V-Raptor 650 has a Power of 70.0 HP (51.5 kW) @ 9000 RPM.
How many gears does the Cagiva V-Raptor 650 have?
The 2003 Cagiva V-Raptor 650 has a Gearbox of 6-speed.
What is the torque of the Cagiva V-Raptor 650?
The 2003 Cagiva V-Raptor 650 has a Torque of 63.6 Nm (6.5 kgf-m or 46.9 ft.lbs).
How much does the Cagiva V-Raptor 650 weigh?
The 2003 Cagiva V-Raptor 650 has a Dry weight of 185.0 kg (407.9 pounds).
