Enduro Bikes
2012CCM XTR-4 500
31 fields on record
The 2012 CCM XTR-4 500 is an enduro bike for riders who want genuine off-road and trail performance. Its 498cc air-cooled single keeps things simple and dependable, with an 850 mm seat, a 144 kg dry weight and a 9-litre tank.
- Capacity
- 498.0 ccm
- Engine
- Single, four-stroke
- Gearbox
- Not on record
Know it? Add it → - Dry weight
- 144.0 kg
- Seat height
- 850 mm
- Power
- 49.8 HP (36.6 kW)
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built primarily for supermoto-style riding, mixing sharp tarmac cornering with light trail and dirt capability.
- Built for
- A raw, single-cylinder British-built machine that rewards an active, playful riding style over outright speed or refinement.
- Not ideal for
- This is not the right choice for riders wanting a comfortable, stable, long-distance touring or passenger-friendly motorcycle.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 498.0 ccm
- Power
- 49.8 HP (36.6 kW)
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.3458 HP/kg (dry)
- Bore x stroke
- 92.8 x 73.6 mm
- Compression
- 9.2:1
- Cooling system
- Air
- Fuel system
- Carburettor
- Starting
- Electric & kick
- Ignition
- Electronic ignition (CDI)
- Valves per cylinder
- 4
- Lubrication system
- Pressure pump feed
- Torque
- Not on record - add it
Transmission
- Final drive
- Chain
- Clutch
- Wet
Dimensions & weight
- Wheelbase
- 1535 mm
- Seat height
- 850 mm
- Dry weight
- 144.0 kg
- Fuel capacity
- 9.00 litres
- Ground clearance
- 280 mm
Chassis & suspension
- Frame
- Chrome molly
- Front suspension
- SPX race forks
- Rear suspension
- Rebound / compression / preload
- Front wheel travel
- 245 mm
- Rear wheel travel
- 250 mm
- Rake (fork angle)
- 28.0°
Brakes & wheels
- Front brakes
- Single disc. Hydraulic
- Rear brakes
- Single disc. Hydraulic
- Front tyre
- 2.50-21
- Rear tyre
- 3.00-18
Other
- Color options
- White/black/red
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2012 | 2013 |
|---|---|---|
| Capacity | 498 cc | 498 cc |
| Dry weight | 144 kg | 144 kg |
| Seat height | 850 mm | 850 mm |
| Fuel capacity | 9 L | 9 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the CCM XTR-4 500?
The 2012 CCM XTR-4 500 has a Capacity of 498.0 ccm (30.39 cubic inches).
What engine power does the CCM XTR-4 500 have?
The 2012 CCM XTR-4 500 has a Power of 49.8 HP (36.6 kW).
How much does the CCM XTR-4 500 weigh?
The 2012 CCM XTR-4 500 has a Dry weight of 144.0 kg (317.5 pounds).
