Enduro Bikes
2020Husqvarna FE501
37 fields on record
The 2020 Husqvarna FE 501 is a lightweight enduro bike designed for experienced off-road riders tackling technical terrain. Known for its potent 501cc engine and nimble handling, it excels in extreme cross-country and hard enduro competition. The 108.4 kg dry weight and advanced WP suspension deliver responsive performance across demanding landscapes.
- Capacity
- 510.9 ccm
- Engine
- Single, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 108.4 kg
- Seat height
- 970 mm
- Power
- 45.0 HP (33.6 kW)
What’s new for the 2020 Husqvarna FE501
vs the 2019| Spec | 2019 | 2020 |
|---|---|---|
| Dry weight | 111.0 kg (244.7 pounds) | 108.4 kg (239.0 pounds) |
| Fuel capacity | 8.50 litres (2.25 US gallons) | 8.20 litres (2.17 US gallons) |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built for technical enduro trails, tight woods, and competitive off-road riding rather than street use.
- Built for
- A sharp, high-strung dirt weapon that rewards aggressive, skilled inputs with razor-quick direction changes and strong power-to-weight feel.
- Not ideal for
- Not a good fit for beginners, commuters, or anyone wanting a plush, low, easy-going daily or touring ride.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 510.9 ccm
- Power
- 45.0 HP (33.6 kW)
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.4151 HP/kg (dry)
- Bore x stroke
- 95.0 x 72.0 mm
- Compression
- 12.2:1
- Cooling system
- Liquid
- Fuel system
- Carburettor
- Starting
- Electric
- Ignition
- Keihin EMS
- Valves per cylinder
- 4
- Lubrication system
- Forced oil lubrication with 2 Eaton pumps
- Torque
- Not on record - add it
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Wet, DDS multi-disc clutch, Magura hydraulics
Dimensions & weight
- Wheelbase
- 1482 mm
- Overall length
- 2260 mm
- Seat height
- 970 mm
- Dry weight
- 108.4 kg
- Fuel capacity
- 8.20 litres
- Ground clearance
- 360 mm
Chassis & suspension
- Frame
- Central double-cradle-type 25CrMo4 steel
- Front suspension
- WP-USD Xplor 48 with preload adjuster
- Rear suspension
- WP shock absorber with linkage
- Front wheel travel
- 300 mm
- Rear wheel travel
- 300 mm
- Rake (fork angle)
- 26.5°
- Trail
- 107 mm
Brakes & wheels
- Front brakes
- Single disc. Magura twin-piston floating calliper
- Front brakes diameter
- 260 mm
- Rear brakes
- Single disc. Magura single-piston floating calliper
- Rear brakes diameter
- 200 mm
- Front tyre
- 90/90-21
- Rear tyre
- 140/80-18
Other
- Color options
- White/blue/yellow
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2014 | 2017 | 2020 | 2022 | 2024 |
|---|---|---|---|---|---|
| Capacity | 510 cc | 510 cc | 511 cc | 511 cc | 511 cc |
| Dry weight | 114 kg | 111 kg | 108 kg | 108 kg | 111 kg |
| Seat height | 970 mm | 970 mm | 970 mm | 950 mm | 952 mm |
| Fuel capacity | 9.5 L | 8.5 L | 8.2 L | 9 L | 8 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Husqvarna FE501?
The 2020 Husqvarna FE501 has a Capacity of 510.9 ccm (31.18 cubic inches).
What engine power does the Husqvarna FE501 have?
The 2020 Husqvarna FE501 has a Power of 45.0 HP (33.6 kW).
How many gears does the Husqvarna FE501 have?
The 2020 Husqvarna FE501 has a Gearbox of 6-speed.
How much does the Husqvarna FE501 weigh?
The 2020 Husqvarna FE501 has a Dry weight of 108.4 kg (239.0 pounds).
Shop this bike
Affiliate linksWe may earn a commission from qualifying eBay or Amazon purchases made through these links. As an Amazon Associate I earn from qualifying purchases.
The 2020 Husqvarna FE 501 motorcycle is a powerful and versatile off-road machine. With its 510.9cc four-stroke engine, it delivers excellent performance for both trail riding and motocross. The bike's lightweight and agile design make it easy to handle on a variety of terrains, while its advanced suspension system provides a smooth and controlled ride. Whether you're a seasoned rider or a beginner looking for a reliable and capable bike, the FE 501 is a top choice for off-road enthusiasts.
Overall, the 2020 Husqvarna FE 501 offers impressive power, agility, and versatility for off-road riding. Its advanced features and durable construction make it a standout option in the competitive field of enduro motorcycles. If you're looking for a high-performing and reliable bike for your off-road adventures, the FE 501 is definitely worth considering.
