2019SWM RS500R
44 fields on record
The 2019 SWM RS500R is a four-stroke enduro bike from the revived Italian brand SWM. Its liquid-cooled 501cc single drives through a six-speed gearbox and chain. A tall 963 mm seat, 112 kg dry weight and 7.2-litre tank suit experienced off-road riders.
- Capacity
- 501.0 ccm
- Engine
- Single, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 112.0 kg
- Seat height
- 963 mm
- Power
- 26.8 HP (20.0 kW) @ 7500 RPM
What’s new for the 2019 SWM RS500R
vs the 2018| Spec | 2018 | 2019 |
|---|---|---|
| Power | 55.1 HP (40.5 kW) | 26.8 HP (20.0 kW) @ 7500 RPM |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- This is a dedicated enduro machine built for trail riding, technical off-road terrain, and playful single-track work rather than pavement cruising.
- Built for
- It suits riders who enjoy raw, minimalist off-road machines that prioritize agility and terrain feedback over outright power or creature comforts.
- Not ideal for
- It is not a good fit for riders seeking highway comfort, long-distance touring capability, or a passenger-friendly two-up ride.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usRange and running costs
Worked out in your browser - nothing is sent to usBased on the published US (EPA-style) fuel economy estimate and tank size. Real-world figures depend on how and where you ride, and the last litres of a tank are reserve. Prices shown greyed are examples - type your own.
Engine
- Capacity
- 501.0 ccm
- Power
- 26.8 HP (20.0 kW) @ 7500 RPM
- CO2 Emissions
- 131 CO2 g/km
- EPA Est. Fuel Consumption
- 5.58 L/100km (42.2 US mpg)
- EPA CO Emissions
- 3.2 CO g/km
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.2393 HP/kg (dry)
- Bore x stroke
- 97.0 x 67.8 mm
- Compression
- 12.9:1
- Cooling system
- Liquid
- Fuel system
- Injection
- Starting
- Electric
- Ignition
- Electronic
- Aspiration
- Naturally aspirated
- Valves per cylinder
- 4
- Lubrication system
- Dry sump with two oil pump rotor and cartridge filter
- Torque
- Not on record - add it
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Wet, multiplate type; mecanical control
Dimensions & weight
- Wheelbase
- 1495 mm
- Overall length
- 2240 mm
- Overall width
- 820 mm
- Overall height
- 1285 mm
- Seat height
- 963 mm
- Dry weight
- 112.0 kg
- Fuel capacity
- 7.20 litres
- Ground clearance
- 300 mm
Chassis & suspension
- Frame
- Single beam double cradle main frame
- Front suspension
- Kayba Upside-Down fork
- Rear suspension
- Kayba ´Soft Damp´monoshock absorber with adjustment
- Front wheel travel
- 295 mm
- Rear wheel travel
- 296 mm
- Trail
- 106 mm
Brakes & wheels
- Front brakes
- Single disc
- Front brakes diameter
- 260 mm
- Rear brakes
- Single disc
- Rear brakes diameter
- 240 mm
- Front tyre
- 90/90-21
- Rear tyre
- 140/80-18
Other
- Color options
- Red/white/yellow/black
- Comments
- SWM is short for Speedy Working Motors in Italy. Cooperated with Chinese Shineray.
- Fuel Tank Material
- Plastic
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2016 | 2018 | 2019 | 2023 | 2024 |
|---|---|---|---|---|---|
| Capacity | 501 cc | 501 cc | 501 cc | 501 cc | 501 cc |
| Dry weight | 112 kg | 112 kg | 112 kg | 116 kg | 116 kg |
| Seat height | 963 mm | 963 mm | 963 mm | 955 mm | 955 mm |
| Fuel capacity | 7.2 L | 7.2 L | 7.2 L | 7.5 L | 7.5 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the SWM RS500R?
The 2019 SWM RS500R has a Capacity of 501.0 ccm (30.57 cubic inches).
What engine power does the SWM RS500R have?
The 2019 SWM RS500R has a Power of 26.8 HP (20.0 kW) @ 7500 RPM.
How many gears does the SWM RS500R have?
The 2019 SWM RS500R has a Gearbox of 6-speed.
How much does the SWM RS500R weigh?
The 2019 SWM RS500R has a Dry weight of 112.0 kg (246.9 pounds).
