Enduro Bikes
2020KTM 500 EXC-F Six Days
41 fields on record
The 2020 KTM 500 EXC-F Six Days is a premium enduro machine built for experienced off-road riders seeking competition-level performance and durability. Known for its lightweight construction at 106kg and advanced WP suspension, it excels in demanding terrain and long-distance rally events. The electric starter and generous fuel capacity make it practical for extended adventures while maintaining aggressive trail capability.
- Capacity
- 510.9 ccm
- Engine
- Single, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 106.0 kg
- Seat height
- 960 mm
- Power
- 52.0 HP (38.2 kW)
What’s new for the 2020 KTM 500 EXC-F Six Days
vs the 2019| Spec | 2019 | 2020 |
|---|---|---|
| Fuel capacity | 8.50 litres (2.25 US gallons) | 9.00 litres (2.38 US gallons) |
| Front suspension | WP-USD Xplor 48 with preload adjuster | not listed |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built for hard enduro, cross-country racing, and technical trail riding where a light, powerful 500cc four-stroke thrives.
- Built for
- A raw, race-focused thumper that rewards aggressive input with explosive torque, razor-sharp agility, and total commitment to dirt riding.
- Not ideal for
- Not a good fit for commuters, passengers, long highway tours, or riders wanting plush comfort and low-effort ergonomics.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usRange and running costs
Worked out in your browser - nothing is sent to usBased on the maker's published fuel consumption and tank size. Real-world figures depend on how and where you ride, and the last litres of a tank are reserve. Prices shown greyed are examples - type your own.
Engine
- Capacity
- 510.9 ccm
- Power
- 52.0 HP (38.2 kW)
- CO2 Emissions
- 103 CO2 g/km
- EPA Certificate No.
- LKTXC.511SLE-004
- EPA Est. Fuel Consumption
- 4.40 L/100km (53.5 US mpg)
- EPA CO Emissions
- 7.5 CO g/km
- Engine type
- Single, four-stroke
- Fuel consumption
- 3.60 litres/100 km (27.8 km/l)
- Power/weight ratio
- 0.4906 HP/kg (dry)
- Bore x stroke
- 95.0 x 72.0 mm
- Compression
- 12.8:1
- Cooling system
- Liquid
- Fuel system
- Injection
- Starting
- Electric
- Ignition
- Keihin EMS
- Aspiration
- Naturally aspirated
- Valves per cylinder
- 4
- Lubrication system
- Pressure circulation lubrication with two rotary pumps
- Torque
- Not on record - add it
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Wet, DDS multi-disc clutch, Brembo hydraulics
Dimensions & weight
- Wheelbase
- 1482 mm
- Seat height
- 960 mm
- Dry weight
- 106.0 kg
- Fuel capacity
- 9.00 litres
- Ground clearance
- 355 mm
Chassis & suspension
- Frame
- Central-tube frame with double-cradle
- Rear suspension
- WP Xplor PDS shock absorber
- Front wheel travel
- 300 mm
- Rear wheel travel
- 310 mm
- Rake (fork angle)
- 26.5°
Brakes & wheels
- Front brakes
- Single disc. Brake calipers on floating bearings
- Front brakes diameter
- 260 mm
- Rear brakes
- Single disc. Brake calipers on floating bearings
- Rear brakes diameter
- 220 mm
- Front tyre
- 90/90-21
- Rear tyre
- 140/80-18
Other
- Color options
- Orange/white/red/blue
- Fuel Tank Material
- Plastic
Specs last verified against published sources: .
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2018 | 2020 | 2023 | 2025 | 2027 |
|---|---|---|---|---|---|
| Capacity | 510 cc | 511 cc | 511 cc | 511 cc | 511 cc |
| Dry weight | 107 kg | 106 kg | 106 kg | 108 kg | 115 kg |
| Seat height | 960 mm | 960 mm | 960 mm | 963 mm | 963 mm |
| Fuel capacity | 8.5 L | 9 L | 9.2 L | 8.5 L | 8.5 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the KTM 500 EXC-F Six Days?
The 2020 KTM 500 EXC-F Six Days has a Capacity of 510.9 ccm (31.18 cubic inches).
What engine power does the KTM 500 EXC-F Six Days have?
The 2020 KTM 500 EXC-F Six Days has a Power of 52.0 HP (38.2 kW).
How many gears does the KTM 500 EXC-F Six Days have?
The 2020 KTM 500 EXC-F Six Days has a Gearbox of 6-speed.
How much does the KTM 500 EXC-F Six Days weigh?
The 2020 KTM 500 EXC-F Six Days has a Dry weight of 106.0 kg (233.7 pounds).
Shop this bike
Affiliate linksWe may earn a commission from qualifying eBay or Amazon purchases made through these links. As an Amazon Associate I earn from qualifying purchases.
The 2020 KTM 500 EXC-F Six Days motorcycle is a powerful and versatile off-road bike that delivers impressive performance and handling. With its 510cc engine, this machine is capable of conquering any terrain with ease, making it the ideal choice for riders who seek adventure and thrill. The Six Days edition also comes with special features such as a larger fuel tank, stronger wheels, and a high-performance exhaust, making it a top choice for hardcore off-road enthusiasts.
In addition to its impressive off-road capabilities, the 2020 KTM 500 EXC-F Six Days motorcycle also boasts a sleek and eye-catching design that is sure to turn heads. With its bold graphics and aggressive styling, this bike exudes confidence and power, making it a standout choice in the world of off-road motorcycles. Overall, the KTM 500 EXC-F Six Days motorcycle offers a winning combination of performance, style, and durability, making it a top contender in its class.
