Motocross Bikes
2010KTM 125 SX
34 fields on record
The 2010 KTM 125 SX is a lightweight two-stroke enduro bike designed for young riders and beginners seeking an agile, nimble off-road machine. Its compact 125cc engine and responsive handling make it ideal for tight trail work and technical terrain. Known for its reliability and easy maintenance, the 125 SX remains a popular choice for entry-level motocross and enduro competition.
- Capacity
- 124.8 ccm
- Engine
- Single, two-stroke
- Gearbox
- 6-speed
- Dry weight
- 90.8 kg
- Seat height
- 985 mm
- Power
- 15.0 HP (11.0 kW)
Other years
2003
2004
2005
2006
2007
2008
2009
2010
2011
2012
2013
2014
2015
2016
2017
2018
2019
2020
2021
2022
2023
2025
2026
2027
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built purely for closed-course motocross racing, it excels at jumps, berms, and rapid direction changes on dirt tracks rather than any street use.
- Built for
- Light, explosive, and razor-sharp in handling, it rewards aggressive riding with a peaky two-stroke power band and minimal weight to manage.
- Not ideal for
- It is not suitable for commuting, highway travel, passengers, or riders seeking comfort, storage, or a forgiving low-end power delivery.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 124.8 ccm
- Power
- 15.0 HP (11.0 kW)
- Engine type
- Single, two-stroke
- Power/weight ratio
- 0.1652 HP/kg (dry)
- Bore x stroke
- 54.0 x 54.5 mm
- Cooling system
- Liquid
- Fuel system
- Carburettor
- Starting
- Kick
- Ignition
- Kokusan
- Lubrication system
- Mixture oil lubrication 1:40
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Wet multi-disc clutch, operated hydraulically
Dimensions & weight
- Wheelbase
- 1471 mm
- Seat height
- 985 mm
- Dry weight
- 90.8 kg
- Fuel capacity
- 8.00 litres
- Ground clearance
- 390 mm
Chassis & suspension
- Frame
- Central double-cradle-type 25CrMo4
- Front suspension
- WP USD, 43 mm
- Rear suspension
- WP PDS shock absorber
- Front wheel travel
- 300 mm
- Rear wheel travel
- 335 mm
- Rake (fork angle)
- 27.0°
- Trail
- 120 mm
Brakes & wheels
- Front brakes
- Single disc
- Front brakes diameter
- 260 mm
- Rear brakes
- Single disc
- Rear brakes diameter
- 220 mm
- Front tyre
- 80/100-21
- Rear tyre
- 100/90-19
Other
- Color options
- Orange
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2003 | 2009 | 2010 | 2015 | 2020 | 2027 |
|---|---|---|---|---|---|---|
| Capacity | 125 cc | 125 cc | 125 cc | 125 cc | 125 cc | 125 cc |
| Dry weight | 94 kg | 91 kg | 91 kg | 91 kg | 88 kg | 92 kg |
| Seat height | 925 mm | 985 mm | 985 mm | 992 mm | 950 mm | 958 mm |
| Fuel capacity | 7.5 L | 8 L | 8 L | 7.5 L | 7.5 L | 7.2 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the KTM 125 SX?
The 2010 KTM 125 SX has a Capacity of 124.8 ccm (7.62 cubic inches).
What engine power does the KTM 125 SX have?
The 2010 KTM 125 SX has a Power of 15.0 HP (11.0 kW).
How many gears does the KTM 125 SX have?
The 2010 KTM 125 SX has a Gearbox of 6-speed.
How much does the KTM 125 SX weigh?
The 2010 KTM 125 SX has a Dry weight of 90.8 kg (200.2 pounds).
