2011KTM 125 SX

34 fields on record

The 2011 KTM 125 SX is a lightweight two-stroke enduro bike designed for young riders and beginners entering competitive offroad racing. Its 125cc liquid-cooled single-cylinder engine delivers sharp, responsive power characteristics ideal for learning fundamental motocross skills on varied terrain. Known for exceptional agility and ease of handling, this model established KTM's reputation for producing nimble, race-focused small-displacement machines.

Capacity: 124.8 ccm
Engine: Single, two-stroke
Gearbox: 6-speed
Dry weight: 88.8 kg
Seat height: 992 mm
Power: 15.0 HP (11.0 kW)

⇄ Compare with another bike ＋ Add to garage All model years

What’s new for the 2011 KTM 125 SX

vs the 2010

Spec	2010	2011
Dry weight	90.8 kg (200.2 pounds)	88.8 kg (195.8 pounds)
Fuel capacity	8.00 litres (2.11 US gallons)	7.50 litres (1.98 US gallons)
Front suspension	WP USD, 43 mm	WP USD 48 mm (1.89 in)

Other years 2003 2004 2005 2006 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018 2019 2020 2021 2022 2023 2025 2026 2027

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail96%

Cornering90%

City riding10%

Daily riding10%

Touring8%

Two-up5%

Track95%

Best for: Built purely for closed-course motocross racing, it excels at jumps, berms, and rapid direction changes on dirt tracks rather than any street use.
Built for: Light, explosive, and razor-sharp in handling, it rewards aggressive riding with a peaky two-stroke power band and minimal weight to manage.
Not ideal for: It is not suitable for commuting, highway travel, passengers, or riders seeking comfort, storage, or a forgiving low-end power delivery.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 992mm, a rider of 68.9" with a 31" (estimated) inseam will not reach the ground comfortably on the 2011 KTM 125 SX, with a moderate knee angle of around 90 degrees and an upright riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at over 900 mm — Sky High →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 124.8 ccm
Power: 15.0 HP (11.0 kW)
Engine type: Single, two-stroke
Power/weight ratio: 0.1689 HP/kg (dry)
Bore x stroke: 54.0 x 54.5 mm
Cooling system: Liquid
Fuel system: Carburettor
Starting: Kick
Ignition: Kokusan
Lubrication system: Mixture oil lubrication 1:40

Transmission

Gearbox: 6-speed
Transmission type: Manual
Final drive: Chain
Clutch: Wet mDouble disk clutch, operated hydraulically

Dimensions & weight

Wheelbase: 1480 mm
Seat height: 992 mm
Dry weight: 88.8 kg
Fuel capacity: 7.50 litres
Ground clearance: 385 mm

Chassis & suspension

Frame: Central double-cradle-type 25CrMo4. Subframe: Aluminium.
Front suspension: WP USD 48 mm (1.89 in)
Rear suspension: WP PDS shock absorber
Front wheel travel: 300 mm
Rear wheel travel: 335 mm
Rake (fork angle): 26.5°
Trail: 120 mm

Brakes & wheels

Front brakes: Single disc
Front brakes diameter: 260 mm
Rear brakes: Single disc
Rear brakes diameter: 220 mm
Front tyre: 80/100-21
Rear tyre: 100/90-19

Other

Color options: Orange/black/white

Specs last verified against published sources: October 2026.

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2003	2009	2011	2015	2020	2027
Capacity	125 cc	125 cc	125 cc	125 cc	125 cc	125 cc
Dry weight	94 kg	91 kg	89 kg	91 kg	88 kg	92 kg
Seat height	925 mm	985 mm	992 mm	992 mm	950 mm	958 mm
Fuel capacity	7.5 L	8 L	7.5 L	7.5 L	7.5 L	7.2 L
